Aaeon SBC-411 Manuel utilisateur
SBC-411/411E
Half-size 486 All-in-One CPU Card
with Cache
StockCheck.com
FCC STATEMENT
THISDEVICECOMPLIESWITHPART15FCCRULES.OPERA-
TIONISSUBJECTTOTHEFOLLOWINGTWOCONDITIONS:
(1)THISDEVICEMAYNOTCAUSEHARMFULINTERFER-
ENCE.(2)THISDEVICEMUSTACCEPTANYINTERFERENCE
RECEIVEDINCLUDINGINTERFERENCETHATMAYCAUSE
UNDESIREDOPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS"A" DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASON-
ABLE PROTECTION AGAINTST HARMFUL INTERFER-
ENCEWHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENER-
ATES,USES, AND CAN RADIATE RADIO FREQENCY
ENERGYAND, IFNOT INSTATLLEDANDUSED IN ACCOR-
DANCEWITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICA-
TIONS.OPERATION OF THIS EQUIPMENT IN A RESIDEN-
TIALAREA IS LIKELY TO CAUSE HARMFUL INTERFER-
ENCE IN WHICH CASE THE USER WILL BE REQUIRED
TOCORRECT THE INTERFERENCE AT HIS OWN EX-
PENSE.
StockCheck.com
Copyright Notice
This document is copyrighted, 1998, by AAEON Technology Inc.
All rights are reserved. AAEON Technology Inc. reserves the right
to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of AAEON Technology Inc. Information provided in
this manual is intended to be accurate and reliable. However,
AAEON Technology Inc. assumes no responsibility for its use, nor
for any infringements upon the rights of third parties which may
result from its use.
Acknowledgements
ALI is a trademark of Acer Laboratories, Inc.
AMD is a trademark of Advanced Micro Devices, Inc.
AMI is a trademark of American Megatrends, Inc.
AutoCAD and AutoShade are trademarks of Autodesk, Inc.
CHIPS Logotype is a registered trademark; Chips 65550 is a
trademark of Chip and Technologies, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International
Business Machines Corporation.
Lotus, 1-2-3, and Symphony are trademarks of Lotus Development
Corp.
Microsoft Windows®and MS-DOS, are registered trademarks of
Microsoft Corp.
SMC is a trademark of Standard Microsystems Corporation.
TurboDLD Classic is a trademark of Panacea Inc.
UMC is a trademark of United Microelectronics Corporation.
WordPerfect is a trademark of WordPerfect Corporation.
VESA®is a registered trademark of Video Electronics Standards
Association.
All other product names or trademarks are properties of their
respective owners.
PartNo. 2007411001 SBC-411/411E A1 2nd Edition
Printed in Taiwan APRIL 1998
Written By : Steven Lin
StockCheck.com
Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 SBC-411/411ECPUcard
• 1 user manual (this book)
• 1 6-pin to 5-pin adapter for keyboard
• 1 3½" Hard disk drive (IDE) interface cable (40 pin)
• 1 Floppy disk drive interface cable (34 pin)
• 1 Parallel port adapter (26 pin) and COM port (10-9 Pin) adapter
kit
• 1 Serial port adapter (10 to 9 pin)
• PC/104 Module mounting supports
• 1Ethernet 8029Utility Driver Disk(for SBC-411Eonly)
• 1 bag of screws and miscellaneous parts
If any of these items are missing or damaged, contact your distribu-
tor or sales representative immediately.
Notice
DearCustomer,
Thank you for purchasing the SBC-411/411E board. The user
manual is designed to help you get the most out of the SBC-411/
411E,please read it thoroughly before you install and use the board.
The product that you have purchased comes with a one-year
warranty, but AAEON cannot be responsible for misuse of the
product. Therefore, we strongly urge that the first read the manual
before using the product.
To receive the lastest version of the user manual, please visit our
Web site at: Taiwan: www.aaeon.com.tw
U.S.A : www.aaeon.com
StockCheck.com
Contents
Chapter 1: General Information ................................... 1
Introduction ........................................................................... 2
Features.................................................................................. 3
Specifications ......................................................................... 4
Board layout........................................................................... 6
Card dimensions.................................................................... 7
Chapter 2: Installation .................................................. 9
Jumpers and connectors .................................................... 10
Locating jumpers and connectors .................................... 11
Setting jumpers ................................................................... 12
Safety precautions ..........................................................13
Installing DRAM (SIMMs) ............................................... 14
InstallingSIMMs .....................................................................14
Removing SIMMs ...................................................................14
IDE hard drive connector (CN1) ...................................... 15
Floppy drive connector (CN2) .......................................... 17
Connecting the floppy drive.....................................................17
Parallel port connector (CN3) ........................................... 18
Installing the retaining bracket.................................................18
Power connector (CN4)...................................................... 19
RS-232 connectors (CN5, CN6) ....................................... 19
PCI Ethernet connector (CN7)......................................... 20
Keybaord connectors (CN10, CN11)............................... 20
Power LED connector (J1)................................................ 21
IDE LED connector (J2).................................................... 21
Int/Ext Buzzer (J3) ............................................................. 21
Ethernet link/active signal LED (J4)(J5)........................ 22
Power LED and keylock (J6) ............................................ 22
CPU fan power connector (+5V)(J9)................................ 23
Reset switch (JP1).............................................................. 23
StockCheck.com
DOC address setting (JP2) ............................................... 24
Clear CMOS (JP3) ............................................................. 24
DsikOnChip socket (U10)................................................. 25
Chapter 3 : AMIBIOS Setup .......................................... 27
General information ............................................................ 28
Starting AMIBIOS setup ........................................................28
AMIBIOS main menu.............................................................28
Using a mouse with AMIBIOS setup .....................................29
Using the keyboard with AMIBIOS setup..............................29
Standard Setup..................................................................... 30
Advanced Setup................................................................... 32
Chipset Setup ...................................................................... 38
Power Management Setup................................................. 41
PCI/PnP Setup ..................................................................... 43
Peripheral Setup.................................................................. 47
Security ................................................................................. 49
Utility..................................................................................... 53
Default................................................................................... 54
Exiting AMIBIOS............................................................... 55
Chapter 4 : Flat Panel/CRT Controller Display Drivers
and Utilities ........................................................... 57
Ethernet software configuration ....................................... 58
Appendix A : Watchdog Timer Demo Program .......... 59
Programming the watchdog timer .................................... 60
Appendix B : Installing PC/104 Modules ...................... 61
Installing PC/104 modules................................................. 62
StockCheck.com
Chapter 1 General Information 1
1
General
Information
This chapter gives background informa-
tionon theSBC-411/411E.
Sections include:
• Card specifications
• Board layout
CHAPTER
StockCheck.com
2SBC-411/411E User Manual
Introduction
TheSBC-411/411Eis an all-in-one single board 486 computer with an on-
boardPCIEthernetinterface(SBC-411E). Itpacks all the functions of an
industrial computer and its display capabilities into a single, half-size card.
This means the SBC-411/411E is your absolute best solution for embedded
applications.
The onboard Ethernet Realtek RTL 8029AS PCI bus Ethernet controller
supports remote boot ROM functions (SBC-411E only).
TheSBC-411/411EsupportstheM-Systems DiskOnChip 2000 (optional)
which is a new generation of high performance single-chip Flash Disk. It
provides a Flash Disk (as a BIOS expansion) which doesn't require any
bus, slots, or connectors. It is also the optimal solution for Single Board
Computers because of its small size, easy integration, plug-and-play
functionality, and its low power consumption. The DiskOnChip is
available in capacities from 2MB to 72MB and fits in a standard 32-pin DIP
socket.
Another feature of the SBC-411/411E is the inclusion of a high speed, local
bus IDE controller. This controller supports (through ATA PIO) mode 3
and mode 4 hard disks, enabling data transfer rates in excess of 11 MB/
second. Up to four IDE devices can be connected, including large hard
disks, CD-ROM drives, tape backup drives, or other IDE devices. The
built-in, enhanced IDE controller provides a 4-layer, 32-bit, posted write
buffer and a 4-layer, 32-bit read-prefetch buffer to boost IDE performance.
Onboard features include two high speed RS-232 serial ports, one bidirec-
tional SPP/EPP/ECP parallel port and a floppy drive controller. In addition
to the 486's 16 KB of on-chip cache memory, the SBC-411/411E includes an
extra128 KB of L2 onboard cache memory.
If program execution is halted by a program bug or EMI, the board's
watchdog timer can automatically reset the CPU or generate an interrupt.
This ensures reliability in unmanned or standalone systems.
StockCheck.com
Chapter 1 General Information 3
All configuration display and Ethernet (SBC-411E) is done through
software. A single Flash chip holds the system BIOS, VGA BIOS. This
minimizes the number of chip and eases configuration. You can
change the display BIOS or install a boot ROM simply by program-
ming the Flash chip.
TheSBC-411/411E supports5V EDODRAM.It also providesone 72-
pin SIMM (Single In-line Memory Module) sockets for its onboard
system DRAM. These sockets give you the flexibility to configure
your system from 4 MB to 32 MB of DRAM using the most economi-
cal combination of SIMMs.
Features
•CPU:AMDDX5-133 CPU(SQFP Type)
•Half-size:ISAbus CPU card
•BIOS:AMI FlashBIOS
•Chipset:ALi M1489/M1487
•Level2cache: Onboard 128KB L2 cache
•DiskOnChip: One 32-pin DIP socket supports the M-Systems'
DiskOnChip2000 Series, memory capacity from 2MB to72MB
•EthernetInterface(SBC-411E): Supports 10Base-T, remote boot ROM
function
StockCheck.com
4SBC-411/411E User Manual
Specifications
CPU: AMDDX5-133,(SQFPType)
BusInterface: ISA bus
BIOS: AMIFlashBIOS
Chipset: ALi1489/1487
Systemmemory: 4MB to 32MB. One 72-pin SIMM socket onboard supports
BEDO,EDO, Fast PageDRAM
L2cahcememoryF.D.D. : Onbaord 128KB L2 cache memory.Supports up to
twofloppy disk drives, 5.25" (360KBand1.2MB) and/or 3.5" (720KB, 1.44MB,
and2.88MB)
EnhancedIDE: Supports two hard disk drive. Supports PIO mode 3/4
Multi-modeparallel port: Configured toLPT1,LPT2, LPT3 ordisabled.
Supports SPP, ECP, and EPP modes
Serialport: Two RS-232 ports. Ports can be individually configured from
COM1 to COM4 or disabled.
Keyboardconnector: 6-pin mini-DIN connectorsupportsstandardPC/AT
keyboard
Ethernetcontroller(SBC-411E): RealtekRTL8029AS10-BasePCI-Bus
Ethernet controller
EtherentInterface: Software drivers available. Supports remote boot ROM
function
SSD interface: One 32-pin DIP socket supports the M-Systems DiskOnChip
2000series, memory capacity from 2MBto72MB
PC/104connector: 104-pin connector for a 16-bit bus
Watchdog Timer: Can generate a system reset or IRQ15. The time interval is
software selectable (2sec~128min, 1sec/step)
DMAchannels: 7
Interruptlevels: 15
Powermanagement: I/O Peripheral devices support power saving and doze/
standby/suspend modes
StockCheck.com
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Aaeon Matériel informatique
Aaeon
Aaeon PCM-4330 Manuel utilisateur
Aaeon
Aaeon RICO-3288 Manuel utilisateur
Aaeon
Aaeon SBC-556/L Manuel utilisateur
Aaeon
Aaeon UP Squared Pro Manuel utilisateur
Aaeon
Aaeon SBC-555 Manuel utilisateur
Aaeon
Aaeon ETX-700 Manuel utilisateur
Aaeon
Aaeon ECB-901A Manuel utilisateur
Aaeon
Aaeon SBC-551 Manuel utilisateur
Aaeon
Aaeon RICO-3399 Manuel utilisateur
Aaeon
Aaeon PCM-6892 Rev.B Manuel utilisateur
Aaeon
Aaeon EMB-A50M Manuel utilisateur
Aaeon
Aaeon NanoCOM-WHU Manuel utilisateur
Aaeon
Aaeon COM-690T Manuel utilisateur
Aaeon
Aaeon GENE-APL6 Manuel utilisateur
Aaeon
Aaeon HSB-810A Manuel utilisateur
Aaeon
Aaeon EPIC-BT07-A13 Manuel utilisateur
Aaeon
Aaeon UP Squared 6000 Edge Computing Kit Manuel utilisateur
Aaeon
Aaeon PCM-8300 Manuel utilisateur
Aaeon
Aaeon GENE-U15B Manuel utilisateur
Aaeon
Aaeon PER-C41L Manuel utilisateur
Manuels Matériel informatique populaires d'autres marques
EMC2
EMC2 VNX Series Manuel du propriétaire
Panasonic
Panasonic DV0PM20105 Manuel utilisateur
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur
Gigabyte
Gigabyte B660M DS3H AX DDR4 Manuel utilisateur
Raidon
Raidon iT2300 Manuel utilisateur
National Instruments
National Instruments PXI-8186 Manuel utilisateur
