3M MP220 Manuel d'installation et d'exploitation
product
warranty
and
safety
guide
3
3M™Mobile Projector MP220
© 2011 3M. All Rights Reserved.
Product Warranty and Safety Guide
English
8/17/2011 2:26:24 PM
English
Important Notice
All statements, technical information, and recommendations related to 3M’s
products are based on information believed to be reliable, but the accuracy or
completeness is not guaranteed. Before using this product, you must evaluate it
and determine if it is suitable for your intended application. You assume all risks and
liability associated with such use. Any statements related to the product which are
not contained in 3M’s current publications, or any contrary statements contained
on your purchase order shall have no force or effect unless expressly set forth in a
written agreement signed by an authorized officer of 3M.
Technical Support Contact
For technical support, call 1-866-631-1656 or email meetings@mmm.com
4
3M™Mobile Projector MP220
© 2011 3M. All Rights Reserved.
English
Important Notice
All statements, technical information, and recommendations related to 3M’s
products are based on information believed to be reliable, but the accuracy or
completeness is not guaranteed. Before using this product, you must evaluate it
and determine if it is suitable for your intended application. You assume all risks and
liability associated with such use. Any statements related to the product which are
not contained in 3M’s current publications, or any contrary statements contained
on your purchase order shall have no force or effect unless expressly set forth in a
written agreement signed by an authorized officer of 3M.
Technical Support Contact
For technical support, call 1-866-631-1656 or email meetings@mmm.com
5
3M™Mobile Projector MP220
© 2011 3M. All Rights Reserved.
English
Contents
Important Notice .....................................................................................4
Technical Support Contact ....................................................................... 4
Intended Use Statement ..........................................................................6
Safety Information................................................................................... 6
Safety Labels..........................................................................................9
Install Battery........................................................................................10
Remove Battery .................................................................................... 10
Limited Warranty................................................................................... 12
Video and Audio Decoder Notices........................................................... 18
6
3M™Mobile Projector MP220
© 2011 3M. All Rights Reserved.
English
Intended Use Statement
The 3M Mobile Projector MP220 is designed to operate with the 3M specified
battery and 3M power adapter in normal office or home environments.
• 0˚–35˚C (32˚–95˚F)
• 10–80% RH (without condensation)
• 0–1829 m (0–6000 feet) above sea level
The ambient operating environment should be free of airborne smoke, grease,
oil and other contaminants that can affect the operation or performance of the
projector.
Use of this product in adverse conditions will void the product warranty.
Safety Information
Please read, understand, and follow all safety information contained in these
instructions prior to the use of this projector. Retain these instructions for future
reference.
Explanation of Signal Word Consequences
m Warning: Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury and/or property damage.
m Caution: Indicates a potentially hazardous situation, which, if not avoided, may
result in minor or moderate injury and/or property damage.
Warning: Hazardous voltage
7
3M™Mobile Projector MP220
© 2011 3M. All Rights Reserved.
English
mWarning
To reduce the risk associated with hazardous voltage:
• Do not modify this product in any way. Use only 3M approved replacement
components.
• Do not attempt to service this projector other than battery replacement.
There are no user-serviceable parts other than the battery. Service to be
performed only by a 3M authorized service provider using 3M approved
system components.
• Do not use the wall power supply in a wet environment.
• Do not use with a damaged wall power supply. Replace damaged part prior
to use.
To reduce the risk associated with fire and explosion:
• Do not immerse the projector or battery in any liquid or allow either to get
wet.
• Use only 3M approved power supply and lithium ion battery provided.
• Do not disassemble or short circuit the battery.
• Do not dispose of the battery by incineration or fire.
• Do not operate this projector in any environment above 35°C (95°F).
• Do not expose the projector or battery to direct sunlight in a closed space
such as avehicle.
• Do not carry the battery in pockets, purses or handbags where it may contact
metalobjects.
• Do not place battery in contact with metal objects.
• Do not expose or store battery in direct sunlight or excessive heat (>60°C
[140°F]), or in moist or caustic environments.
To reduce the risks associated with driver distraction:
• Do not use this projector in a moving motor vehicle.
To reduce the risks associated with choking:
• Keep AV adapters and other small parts away from young children.
8
3M™Mobile Projector MP220
© 2011 3M. All Rights Reserved.
English
mWarning
To reduce the risk associated with fire and explosion, battery leakage
or overheating:
• Do not immerse the battery in water or allow it to get wet.
• Do not reverse the positive(+) and negative(-) terminals.
• Do not connect the battery directly to a wall outlet. Use only the 3M specified
wall charger or automobile charger.
• Do not strike, throw or subject the battery to physical shock.
• Do not pierce the battery or break it open.
• Keep batteries out of the reach of children.
• Do not recharge the battery near a heat source or in extremely hot
conditions.
• Do not use the battery if it gives off an odor, generates heat, or becomes
discolored ordeformed.
• Keep away from exposed flames if the battery leaks or emits an odor.
• Flush the eyes with water and seek medical attention if the battery leaks and
battery fluid gets in the eyes.
mCaution
To reduce the risks associated with hearing loss:
• Be sure to read earphone manufacturer's instructions with respect to volume
level.
• User is responsible to set a safe volume level.
To reduce the risk associated with environmental contamination:
• Dispose of all system components in accordance with applicable government
regulations.
To reduce the risks associated with LED bright light:
• Do not stare directly into the projector lens.
To reduce the risks associated with tripping and falling:
• Position the charging cord and data cables so that they are not a tripping
hazard.
SAVE THESE INSTRUCTIONS
9
3M™Mobile Projector MP220
© 2011 3M. All Rights Reserved.
English
Safety Labels
LITHIUM ION BATTERY
Model No. LIN376-001
28.86Wh (11.1V 2600mAh x 3)
P/N 78-6972-0053-9
mWarning
• Use a specified charger.
• Do not throw the battery into fire or heat.
• Do not short-circuit the battery terminals.
• Do not disassemble the battery.
Charging Specification
Standard Charge 11.1V/1.3A
Cut Off Voltage 8.5V
Max Charge 12.3V/1.3A
LED Light Output
CLASS 1 LED
PRODUCT
IEC60825-1 :1993+A1
:1997+A2:2001
Maximum Radiant Power:
1.693 mW
10
3M™Mobile Projector MP220
© 2011 3M. All Rights Reserved.
English
Installing and Charging the Projector Battery
Remove Battery Protective Film
The 3M projector comes with a rechargeable battery. When the projector is
shipped, there is a protective film between the battery and the battery contacts on
the projector. Remove the protective film by pulling in the direction shown below.
Pull
to
remove
The battery should be fully charged before using the projector with the
battery.
