2N Helios IP Force Manuel utilisateur

www.2n.czVersion

®Helios IP Force

Security IP Intercom

Installation Manual

2.1



The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of telecommunications

equipment.

The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways, private

branch exchanges (PBX), and door and lift communicators. 2N TELEKOMUNIKACE a.s. has

been ranked among the Czech top companies for years and represented a symbol of

stability and prosperity on the telecommunications market for almost two decades. At

present, we export our products into over 120 countries worldwide and have exclusive

distributors on all continents.

2N is a registered trademark of 2N TELEKOMUNIKACE a.s. Any product and/or other

names mentioned herein are registered trademarks and/or trademarks or brands protected

by law.

2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find

information and to answer your questions about 2N products and services. On

www.faq.2n.cz you can find information regarding products adjustment and instructions for

optimum use and procedures „What to do if...“.

2N TELEKOMUNIKACE a.s. hereby declares that the 2N product complies

®Helios IP Force

with all basic requirements and other relevant provisions of the 1999/5/EC directive. For

the full wording of the Declaration of Conformity see the CD-ROM enclosed or our website

at www.2n.cz.

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All

development, production and distribution processes of the company are managed by this

standard and guarantee a high quality, technical level and professional aspect of all our

products.

Content

1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.1ComponentsandAssociatedProducts ...............................6

1.2TermsandSymbols ..............................................11

2. Description and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.1BeforeYouStart .................................................13

2.2MechanicalInstallation ............................................14

2.3ElectricInstallation ...............................................20

2.4ExtendingModuleConnection ......................................25

2.5ButtonTags ....................................................47

3. Function and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

3.1Configuration ...................................................49

3.2Control ........................................................53

3.3Maintenance ....................................................55

4. Technical Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

5. Supplementary Information . . . . . . . . . . . . . . . . . . . . . . . . . . 59

5.1Troubleshooting .................................................60

5.2Directives,LawsandRegulations ...................................61

5.3GeneralInstructionsandCautions ...................................63

42N TELEKOMUNIKACE a.s., www.2n.cz

1. Product Overview

Here is what you can find in this section:

1.1 Components and Associated Products

1.2 Terms and Symbols

Basic Features

®Helios IP Force is a highly resistant and reliable IP door access intercom

provided with a lot of useful above-standard functions. Supporting the SIP standard

and being compatible with the leading IP PBX and telephone suppliers, 2N

®Helios IP

can make use of all VoIP services. can work as a standardForce 2N

®Helios IP Force

or emergency door access intercom for buildings, entrances to premises or garages,

manufacturing halls, highways and so on.

®Helios IP Force is equipped with two very sensitive microphones and an up to

10W loudspeaker. Thanks to an integrated acoustic echo cancelling (AEC) system, the

product provides mutual audibility even of persons talking at the same time under

normal conditions.

®Helios IP Force can be equipped with a colour wide-angle camera, which

displays the calling person on the called party's video telephone or PC monitor.

®Helios IP Force can be provided with 1, 2 or 4 pre-programmed buttons. You

can set up to three telephone numbers and time profiles for each of the buttons to

increase the accessibility of the called party.

®Helios IP Force can be equipped with a numerical keypad to be used as a code

lock for lock switch activating or telephone/subscriber number dialling.

®Helios IP Force is equipped with an electric lock switch. You can control the

switch using a numerical keypad or, during a call, using any telephone set. An

additional switch module can be installed if necessary. A wide range of settings allow

for a variety of applications.

52N TELEKOMUNIKACE a.s., www.2n.cz

®Helios IP Force can also be provided with RFID card reader modules.

®Helios IP Force is very easy to install. All you have to do is connect the system

into your LAN via a network cable and feed it from a 12 V power supply or your PoE

supporting LAN.

Configure using your PC via any web browser. Use the 2N

®Helios IP Force IP

to manage extensive systems easily and quickly.Manager 2N

®Helios IP Force

Advantages of Use

Uncompromising Antivandal design

High coverage level – up to class IP69K

Variable mounting options (brick/plasterboard flush mounting, surface mounting)

Sensitive microphone and powerful loudspeaker

Bidirectional communication – acoustic echo cancelling

Integrated colour camera with wide-angle lens

Optional dial buttons including name tags and backlight

Optional numerical keypad with backlight

Integrated electronic lock switches with wide setting options

Optional integrated RFID card reader module

LAN (PoE) or external 12 V power supply

Configuration via web interface or dedicated PC application

SIP 2.0 support

Up to 1999 telephone directory positions

Up to 20 user time profiles

Video codecs (H.263+, H.264, MPEG-4, JPEG)

Audio codecs (G.711, G.729)

HTTP server for configuration

SNTP client for time synchronisation with server

RTSP server for video streaming

SMTP client for e-mail sending

TFTP client for automatic configuration and firmware update

62N TELEKOMUNIKACE a.s., www.2n.cz

1.1 Components and Associated Products

Components and Associated Products:2N

®Helios IP Force

Basic Units

Part No.

9151101

1 button

Part No.

9151101C

1 button with

camera

9151101WPart No.

1 button, 10 W

loudspeaker,

IP69K

Part No.

9151101CW

1 button with

camera,

10 W loudspeaker,

IP69K

Part No.

9151104

4 buttons

Part No.

9151104C

4 buttons with

camera

9151101KPart No.

1 button with keypad

Part No.

9151101CK

1 button with

keypad

and camera

72N TELEKOMUNIKACE a.s., www.2n.cz

Part No.

9151101KW

1 button with

keypad,

10 W loudspeaker,

IP69K

Part No.

9151102R

2 buttons,

card reader ready

Part No.

9151102CR

2 buttons with

camera,

card reader ready

Part No.

9151102CRW

2 buttons with

camera,

card reader ready,

10 W loudspeaker,

IP69K

Part No.

915101RP

1 button,

pictograms,

card reader ready

Part No.

9151101CRP

1 button,

pictograms,

with camera,

card reader ready

®Helios IP Force is designed for outdoor applications and requires no additional

roof. W-including Part Nos. are intended for WAP pressure cleaning and extremely

noisy environments (such as highways, etc.).

All units can be flush or wall mounted without requiring any2N

®Helios IP Force

additional accessories. Use the appropriate mounting box (see below) for plasterboard

and hollow brick flush mounting.

82N TELEKOMUNIKACE a.s., www.2n.cz

Flush Mounting Box

9151001Part No.

Brick flush mounting box

9151002Part No.

Plasterboard flush mounting box

VoIP Telephones

91378351Part No.

Grandstream GXV3140 VoIP video telephone

91378354Part No.

Grandstream GXV3175 VoIP telephone

Electric Locks

932070EPart No.

BEFO 1211 12 V / 600

932080EPart No.

BEFO 1221with

momentum pin

932090EPart No.

BEFO 1211MBwith mechanical

blocking

92N TELEKOMUNIKACE a.s., www.2n.cz

Power Supply

Part No.

91378100E

Part No.

91378100US

PoE injector

91341481EPart No.

Adapter 12 V / 2 A

A stabilised power supply has to be used

if the Ethernet (PoE) power supply is not

available.

Part No.

932928E

12 V transformer

Additional Modules

9151010Part No.

Additional switch with

normally open/closed

contact and 12 V switched

output.

Includes tamper switch.

9151011Part No.

Internal RFID card reader

125 kHz for 2N

®Helios

mounting.IP Force

Includes tamper switch.

9151016Part No.

Internal RFID card reader

13.56 MHz for 2N

®Helios

IP Force mounting.

Includes tamper switch.

9159010Part No.

Security Relay

9159011Part No.

Wiegand Isolator

9137410EPart No.

External IP relay

9134165EPart No.

RFID card

9134166EPart No.

RFID key fob

9137420EPart No.

External RFID card reader

for PC connection via USB

interface

102N TELEKOMUNIKACE a.s., www.2n.cz

Autres manuels pour Helios IP Force

Table des matières

Autres manuels 2N Système d'interphone

2N C-CURE 9000 Manuel utilisateur

2N Helios IP Manuel de l'opérateur

2N Analog Vario Manuel utilisateur

2N Helios IP Safety Manuel utilisateur

2N Helios IP Automation Feuille d'instructions

2N IP Vario Manuel utilisateur

2N IP Verso Manuel utilisateur

2N Helios IP Feuille d'instructions
