ZyXEL Communications NWA-3500 Manuel utilisateur

www.zyxel.com

NWA-3500

802.11a/b/g Wireless Access Point

User’s Guide

Version 3.60

3/2007

Edition 1

About This User's Guide

ZyXEL NWA-3500 User’s Guide 3

About This User's Guide

Intended Audience

This manual is intended for people who want to configure the ZyXEL Device using the web

configurator. You should have at least a basic knowledge of TCP/IP networking concepts and

topology.

Related Documentation

• Quick Start Guide

The Quick Start Guide is designed to help you get up and running right away. It contains

information on setting up your network and configuring for Internet access.

• Supporting Disk

Refer to the included CD for support documents.

• ZyXEL Web Site

Please refer to www.zyxel.com for additional support documentation and product

certifications.

User Guide Feedback

Help us help you. Send all User Guide-related comments, questions or suggestions for

improvement to the following address, or use e-mail instead. Thank you!

The Technical Writing Team,

ZyXEL Communications Corp.,

6 Innovation Road II,

Science-Based Industrial Park,

Hsinchu, 300, Taiwan.

E-mail: [email protected]

Document Conventions

ZyXEL NWA-3500 User’s Guide

Document Conventions

Warnings and Notes

These are how warnings and notes are shown in this User’s Guide.

1Warnings tell you about things that could harm you or your device.

"Notes tell you other important information (for example, other things you may

need to configure or helpful tips) or recommendations.

Syntax Conventions

• The NWA-3500 may be referred to as the “ZyXEL Device”, the “device” or the “system”

in this User’s Guide.

• Product labels, screen names, field labels and field choices are all in bold font.

• A key stroke is denoted by square brackets and uppercase text, for example, [ENTER]

means the “enter” or “return” key on your keyboard.

• “Enter” means for you to type one or more characters and then press the [ENTER] key.

“Select” or “choose” means for you to use one of the predefined choices.

• A right angle bracket ( > ) within a screen name denotes a mouse click. For example,

Maintenance > Log > Log Setting means you first click Maintenance in the navigation

panel, then the Log sub menu and finally the Log Setting tab to get to that screen.

• Units of measurement may denote the “metric” value or the “scientific” value. For

example, “k” for kilo may denote “1000” or “1024”, “M” for mega may denote “1000000”

or “1048576” and so on.

• “e.g.,” is a shorthand for “for instance”, and “i.e.,” means “that is” or “in other words”.

Document Conventions

ZyXEL NWA-3500 User’s Guide 5

Icons Used in Figures

Figures in this User’s Guide may use the following generic icons. The ZyXEL Device icon is

not an exact representation of your device.

ZyXEL Device Computer Notebook computer

Server DSLAM Firewall

Telephone Switch Router

Safety Warnings

ZyXEL NWA-3500 User’s Guide

Safety Warnings

1For your safety, be sure to read and follow all warning notices and instructions.

• Do NOT use this product near water, for example, in a wet basement or near a swimming

pool.

• Do NOT expose your device to dampness, dust or corrosive liquids.

• Do NOT store things on the device.

• Do NOT install, use, or service this device during a thunderstorm. There is a remote risk

of electric shock from lightning.

• Connect ONLY suitable accessories to the device.

• ONLY qualified service personnel should service or disassemble this device.

• Make sure to connect the cables to the correct ports.

• Place connecting cables carefully so that no one will step on them or stumble over them.

• Always disconnect all cables from this device before servicing or disassembling.

• Use ONLY an appropriate power adaptor or cord for your device.

• Connect the power adaptor or cord to the right supply voltage (for example, 110V AC in

North America or 230V AC in Europe).

• Do NOT allow anything to rest on the power adaptor or cord and do NOT place the

product where anyone can walk on the power adaptor or cord.

• Do NOT use the device if the power adaptor or cord is damaged as it might cause

electrocution.

• If the power adaptor or cord is damaged, remove it from the power outlet.

• Do NOT attempt to repair the power adaptor or cord. Contact your local vendor to order a

new one.

• Do not use the device outside, and make sure all the connections are indoors. There is a

remote risk of electric shock from lightning.

• Antenna Warning! This device meets ETSI and FCC certification requirements when

using the included antenna(s). Only use the included antenna(s).

• If you wall mount your device, make sure that no electrical lines, gas or water pipes will

be damaged.

• The PoE (Power over Ethernet) devices that supply or receive power and their connected

Ethernet cables must all be completely indoors.

This product is recyclable. Dispose of it properly.

Safety Warnings

ZyXEL NWA-3500 User’s Guide 7

Safety Warnings

ZyXEL NWA-3500 User’s Guide

Contents Overview

ZyXEL NWA-3500 User’s Guide 9

Contents Overview

Introduction ............................................................................................................................ 31

Introducing the ZyXEL Device ...................................................................................................33

Introducing the Web Configurator .............................................................................................. 43

Status Screens .......................................................................................................................... 47

Tutorial ....................................................................................................................................... 51

The Web Configurator ...........................................................................................................79

System Screens ........................................................................................................................ 81

Wireless Configuration .............................................................................................................. 87

Wireless Security Configuration .............................................................................................. 103

MBSSID and SSID ...................................................................................................................119

Other Wireless Configuration .................................................................................................. 127

IP Screen ................................................................................................................................. 137

Rogue AP ................................................................................................................................ 141

Remote Management Screens ................................................................................................ 147

Internal RADIUS Server .......................................................................................................... 157

Certificates ............................................................................................................................... 163

Log Screens ............................................................................................................................ 181

VLAN ....................................................................................................................................... 187

Maintenance ............................................................................................................................ 205

SMT and Troubleshooting ................................................................................................... 215

Introducing the SMT ................................................................................................................ 217

General Setup ......................................................................................................................... 223

LAN Setup ............................................................................................................................... 225

SNMP Configuration ................................................................................................................ 227

System Password .................................................................................................................... 229

System Information and Diagnosis .......................................................................................... 231

Firmware and Configuration File Maintenance ........................................................................ 237

System Maintenance and Information ..................................................................................... 243

Troubleshooting ....................................................................................................................... 251

Appendices and Index ......................................................................................................... 255

Contents Overview

ZyXEL NWA-3500 User’s Guide
