ZyXEL Communications ES1100 Series Manuel utilisateur

ES1100 Series

8/16/24-port FE

Unmanaged Switch

ES1100 Series

8/16/24-port FE

Unmanaged Switch

Ł

Non-blocking, wire-speed

transmission

Ł

Auto MDI/MDI-X support

Ł

IEEE 802.3az compliant

(ES1100-16/24/24E)

Ł

Fanless design for silent

operations

Ł

IEEE 802.3x flow control

supported

Ł

IEEE 802.1p CoS supported

Ł

IEEE 802.3af power on up to

4/8 ports (ES1100-8P/16P)

The ZyXEL Switch ES1100 Series is designed for SMBs to boost business network

performance and efficiency. It enables businesses to enter the world of networking

connectivity without the need for complicated management.The Series provides not only

plug-and-play simplicity for high-bandwidth connectivity but also the N-way

Auto-negotiation functions to connect its network counterparts with the highest possible

data speed as well as to activate the duplex mode automatically.The ES1100 Series is Ideal

for typical noise-sensitive office environments for its superior energy efficiency and

Ethernet connectivity.

The ES1100 Series consists of four Fast Ethernet switches and two Power over Ethernet (PoE)

switches: the ZyXEL ES1100-16, ES1100-24, ES1100-24E and ES1100-24G; ES1100-8P and

ES1100-16P.The desktop design of ZyXEL ES1100-8P/16P/16/24E switch is ideal for SB or

SOHO users seeking reliable network connectivity that fits into rack environment easily,

while the ES1100-24/24G is designed for 19”racks,making it easy to be deployed in

standard wiring closets.

Benefits

Green networking

The environment-aware ES1100 Series offers 10/100M Ethernet speeds critical to the

next-generation network applications, and it also provides power-saving functions to reduce

energy consumption for lower operating cost.

Traffic detection — IEEE Energy Efficient Ethernet (EEE) compliance (ES1100-16/24/24E)

The feature automatically detects network traffics and adjusts power consumption accordingly in

a dynamic manner. It reduces power consumption during the low link utilization periods.

Inactive link detection

The power usage adjustment feature automatically reduces power usage when any shut down

network device or inactive link is detected.That is,power consumption of the Series can be

adjusted according to the link status or the number of active network devices when possible.

Cable length detection

The devices equipped with this green feature can automatically detect the length of connected

Ethernet cables and adjust power usage accordingly.The shorter the cable length, the less power it

consumes.

IEEE 802.3az-compliant Switch

with Decent Performance for

Small-group Networks

ES1100 Series

8/16/24-port FE

Unmanaged Switch

ES1100 Series

8/16/24-port FE

Unmanaged Switch

Best-in-class solution for Fast Ethernet environments

The ES1100 Series comprises of unmanaged Fast Ethernet switches that provide an inexpensive solution for Fast Ethernet connections to the desktop with

outstanding performance.The ES1100 Series is an ideal solution for bandwidth-intensive applications such as high-resolution photo delivery, video/audio

streaming and downloading as well as server farm connections.

Better performance and efficiency

The full ES1100 range of 16/24-port Fast Ethernet switches has been designed to boost your network with better performance and efficiency.With the N-Way

Auto-negotiation function, the ES1100 Series connects the network counterparts with the highest possible data speed and activates the duplex mode

automatically.

Transmission reliability

Unlike shared 10/100 Mbps networks, the ES1100 Series eliminates congestion by providing dedicated bandwidth; and its duplex mode doubles the effective

bandwidth by enabling two-way communications.The store-and-forward service brings low latency and error-free packet delivering,while the plug-and-play

and multiple network protocol compatibility of the ES1100 Series makes installation and management easier and faster than ever.

Desktop size with flexible rackmount and wallmount design fits your working environments

With embedded rackmount brackets, the desktop size devices can fits into your rack environment easily. No matter how intense your network demand is, the

ES1100 Series supports your needs with an affordable and reliable network solution designed especially for small businesses.

Freedom of installation by PoE (ES1100-8P/16P)

The ES1100-8P and ES1100-16P support IEEE 802.3af PoE to ease installation in challenging spaces such as ceiling or wall mounting. It works with devices

such as WLAN APs,VoIP phones and IP surveillance cameras that can be powered by Ethernet connectivity over CAT-5 cables less than 100 meters (300 feet) in

length; so there is no need for extra power adapters, and powering the devices installed on the ceiling is no longer a headache.This feature helps enterprises

to reduce installation time and cost when many new devices are needed.

Standard Compliance

• IEEE 802.3 10Base-T Ethernet

• IEEE 802.3u 100Base-TX Fast Ethernet

• IEEE 802.ab 1000Base-T Ethernet

• IEEE 802.3af PoE

• IEEE 802.3x Flow control and Back-pressure

• IEEE 802.1p CoS

• IEEE 802.3az EEE

Certification

Safety

• EN 60950-1

• IEC 60950-1

• EU RoHS Compliant

Emission (EMC)

• FCC Part15 (Class A)

• CE EMC (Class A)

Specifications

Model ES1100-8P ES1100-16P ES1100-16 ES1100-24E ES1100-24 ES1100-24G

8-port FE 16-port FE 16-port FE 24-port FE 24-port FE 24-port FE

Unmanaged Unmanaged Unmanaged Unmanaged Unmanaged Unmanaged

Product Name PoE Switch PoE Switch Switch Switch Switch Switch

Port Density

10/100Base-T 4 8 16 24 24 24

10/100 Base-T PoE 4 8 - - - -

Dual personality GbE ports - - - - - 2

Performance

Switching Capacity (Gbps) 1.6 3.2 3.2 4.8 4.8 8.8

Switching Forwarding Rate (Mpps) 1.2 2.4 2.4 3.6 3.6 6.6

Packet Buffer 96 KB 160 KB 256 KB 256 KB 256 KB 320 KB

MAC Address 1K 8K 8K 8K 8K 8K

Jumbo frame support (up to 2048 bytes) - - Yes Yes Yes -

802.3x flow control prioritization Yes Yes Yes Yes Yes Yes

802.1p CoS Yes Yes Yes Yes Yes Yes

Broadcast Storm Control Yes Yes Yes Yes Yes Yes

Back-Pressure-Base flow control Yes Yes Yes Yes Yes Yes

Loop-detection - - Yes Yes Yes -

Auto MDI/MDI-X Yes Yes Yes Yes Yes Yes

Power Requirement

Input voltage of AC

PoE power budget 64 W 130 W - - - -

Physical Feature

Fanless Yes - Yes Yes Yes Yes

262 x 184 x 41/ 262 x 184 x 41/ 216 x 133 x 42/ 267 x 162 x 42/ 441 x 131 x 44/ 441 x 131 x 44/

Item dimensions (WxDxH)(mm/in.) 10.31 x 7.24 x 10.31 x 7.24 x 8.50 x 5.24 x 10.51 x 6.38 x 17.36 x 5.16 x 17.36 x 5.16 x

1.61 1.61 1.65 1.65 1.73 1.73

Item weight (kg/lb.) 1.4/3.09 1.7/3.75 0.77/1.70 1.28/2.82 1.35/2.98 1.5/3.31

318 x 275 x 73/ 318 x 275 x 73/ 325 x 227 x 71/ 325 x 227 x 71/ 477 x 222 x 71/ 477 x 222 x 71/

Packing dimensions (WxDxH)(mm/in.) 12.52 x 10.83 x 12.52 x 10.83 x 12.80 x 8.94 x 12.80 x 8.94 x 18.78 x 8.74 x 18.78 x 8.74 x

2.87 2.87 2.80 2.80 2.80 2.80

Packing weight (kg/lb.) 2.2/4.85 2.5/5.51 1.59/3.51 2.1/4.63 2.14/4.72 2.2/4.85

Environmental Specification

Operating temperature

Storage temperature

Operating humidity

0°C to 50°C/32°F to 122°F

100 - 240 V AC, 50/60 Hz

-40°C to 70°C/-40°F to 158°F

10% to 95% (non-condensing)

5-100-01011003 05/11

For more product information, visit us on the web at www.ZyXEL.com

ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their

respective owners. All specifications are subject to change without notice.
