Zte MF65 Manuel utilisateur
1
ZTE MF65
Let’s go
Getting started with your device.
2
LEGAL INFORMATION
Copyright © 2014 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated
or utilized in any form or by any means, electronic or mechanical,
including photocopying and microlm, without the prior written per-
mission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right
to make modications on print errors or update specications with-
out prior notice.
Version No. : R1.0
Edition Time : 2014.03
NOTE:
Do not use the device in an enclosed environment or where heat
dissipation is poor. Prolonged work in such space may cause ex-
cessive heat and raise ambient temperature, which may lead to au-
tomatic shutdown of the device for your safety. In the case of such
event, cool the device in a well-ventilated place before turning on
for normal use.
3
Getting to Know Your Device
Appearance
The following gure is only for your reference. The actual product
may be different.
1. LED Indicators
2. Power Button
3. WPS Button
4. Micro USB Port
5. (U)SIM Card Slot
6. microSDHC Card Slot
NOTE:
microSDHC logo is a trademark of SD-3C, LLC.
4
Indicators
Indicator Status Description
Network
Red solid
Error status. Not registered to the mo-
bile network, no (U)SIM card inserted
or no network service available.
Green solid Registered to the mobile network.
Green
blinking
Connected to the mobile network and
data is being transferred.
Wi-Fi Blue solid Wi-Fi is active.
Blue blinking WPS is active.
LED light off Wi-Fi is off or your device is in sleep
mode.
Battery
Red solid/
blinking
The battery is low. Please charge the
battery.
Green
blinking The battery is being charged.
Green solid The battery level is middle or high.
LED light off
Your device is in standby mode and
not being charged, or the battery is not
inserted.
5
Connection Scenario
UMTS Mode: Your device allows to use your (U)SIM card to access
the Internet and supports multi-clients for surng on the Internet at
the same time. The following gure is only for your reference.
Installing Your Device
1. Slide the back cover and remove it
6
2. Remove the battery.
3. Insert the (U)SIM card.
IMPORTANT:
Your device does not support Micro/Nano or any other nonstandard
SIM cards. To avoid device damage, please do not use them.
7
4. Insert the microSDHC card if necessary.
5. Insert the battery.
6. Close the back cover.
8
Connecting to Your Device
Via Wi-Fi
Follow the following steps and gures for PC to connect to your de-
vice.
1. Power on your device directly. It will take 1~2 minutes to initial-
ize.
2. Use your normal Wi-Fi application on the client to search for
the available wireless networks.
NOTE:
Please set the client to obtain an IP address automatically referring
to the chapter “Conguring your PC”, and then the client will get an
IP address like “192.168.0.101”.
9
3. Select the SSID of your device, and then click Connect.
NOTE:
Please check the label on your device to get the default SSID.
4. Input the password, and then click Connect.
NOTE:
You may need to input the password for Wi-Fi connection. Please
check the label on your device to get the default.
10
5. Wait a moment, and then the client will connect to your device
successfully.
Via USB Cable
1. Connect to the device.
2. Power on your device.
3. The OS detects and recognizes new hardware and nishes the
installation automatically.
