MF656

USB Modem

Quick Guide

Introduction

The ZTE MF656 USB modem is a multi-mode 3G modem. With a USB interface connecting to your

laptop or desktop computer, it supports data and SMS services through the mobile USB Modem

network, helping you realize mobile communication anytime and anywhere.

Hardware Installation

Installing the SIM/USIM Card

1. Remove the back cover on the modem.

2. Hold your SIM/USIM card with the cut corner oriented

as shown and then slide it into the card holder with the

metal contacts facing the modem.

3. Replace the back cover.

Installing the Memory Card

Only microSD card is supported by the modem and do not insert other memory

cards into the modem.

Insert the microSD card, orientated as shown, into the holder until you hear a

click.

Notes: The logo is a trademark.

Connecting the USB Modem to Your Computer

Remove the modem cap and plug the modem firmly into a USB port on your computer.

Software Installation

On different operating systems, the software installation procedures may be different. Please follow

the general guide below and the system prompts during installation.

• For Windows XP, Vista and Windows 7

When you connect the modem to your PC correctly, the system automatically recognizes it as a

CD-ROM and starts the software installation wizard. If the system does not launch the installation

wizard automatically, please start it by running the executable file in the new CD-ROM directory.

• For Mac OS

The system will automatically display a new CD-ROM icon on the desktop, when you connect the

modem to your Mac correctly. Double click the installation software package in the CD-ROM, and

follow the system prompts to complete the software installation.

Functions

Click the following buttons to access each function.

Connect Connect to the Internet.

SMS Send and receive text messages.

USB Modembook Manage contacts information.

Settings Configure the USB modem settings.

Data record Show connection information.

LED Lights

Indication Modem Status

Red Power on

,

but not re

g

istered to a networ

k

Indication Modem Status

Green soli

d

Re

g

istered to a networ

k

Green blinkin

g

Active data transfer on the networ

k

Warning and notice

Health and safety information

Radio Frequency (RF) Energy

This model USB Modem meets the government’s requirements for exposure to radio waves.

This USB Modem is designed and manufactured not to exceed the emission limits for

exposure to radio frequency (RF) energy set by the Federal Communications Commission

of the U.S. Government:

The exposure standard for wireless mobile USB Modems employs a unit of measurement

known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.

*Tests for SAR are conducted using standard operating positions accepted by the FCC with

the USB Modem transmitting at its highest certified power level in all tested frequency bands.

Although the SAR is determined at the highest certified power level, the actual SAR level of

the USB Modem while operating can be well below the maximum value. This is because

the USB Modem is designed to operate at multiple power levels so as to use only the poser

required to reach the network. In general, the closer you are to a wireless base station

antenna, the lower the power output.

The highest SAR value for the model USB Modem as reported to the FCC is 1.02 W/kg

(Body-worn measurements differ among USB Modem models, depending upon available

enhancements and FCC requirements.)

While there may be differences between the SAR levels of various USB Modems and at

various positions, they all meet the government requirement.

The FCC has granted an Equipment Authorization for this model USB Modem with all

reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines.

SAR information on this model USB Modem is on file with the FCC and can be found under

the Display Grant section of http://www.fcc.gov/oet/fccid after searching on

FCC ID: Q78-MF656.

For body worn operation, this USB Modem has been tested and meets the FCC RF

exposure guidelines for use with an accessory that contains no metal and the positions the

handset a minimum of 0.5 cm from the body. Use of other enhancements may not ensure

compliance with FCC RF exposure guidelines. If you do no t use a body-worn accessory

and are not holding the USB Modem at the ear, position the handset a minimum of 0.5 cm

from your body when the USB Modem is switched on.

FCC Compliance

Thisdevicecomplieswithpart15oftheFCCRules.Operationis

subjecttothefollowingtwoconditions:(1)Thisdevicemaynot

causeharmfulinterference,and(2)thisdevicemustacceptany

interferencereceived,includinginterferencethatmaycause

undesiredoperation.

To the owner

• Some electronic devices are susceptible to electromagnetic interference sent by modem if

inadequately shielded, such as the electronic system of vehicles. Please consult the manufacturer of

the device before using the modem if necessary.

• Operating of laptop and desktop PCs and the modem may interfere with medical devices like

hearing aids and pacemakers. Please always keep them more than 20 centimeters away from such

medical devices when they are turned on. Turn the modem off if necessary. Consult a physician or

the manufacturer of the medical device before using the modem.

• Be aware of the usage limitation when using a modem at places such as oil warehouses or chemical

factories, where there are explosive gases or explosive products being processed. Turn off your

modem if required.

• The use of electronic transmitting devices is forbidden in aircrafts, at petrol stations and in

hospitals. Please observe and obey all warning signs and switch off your modem in these

conditions.

• Do not touch the inner antenna area if not necessary. Otherwise it will affect your modem’s

performance.

• Store the modem out of the reach of little children. The modem may cause injury if used as a toy.
