Zenmuse Z15 Manuel utilisateur

Zenmuse Z15

User Manual

V2.0

2013.03.27 Revision

www.dji-innovations.com

Warning & Disclaimer

No adjusting or amending is allowed to Z15.

Z15 is specialized for Camera and Lens before it leaves the factory. Please mount your camera to Z15 when

get it. No adjusting or amending is allowed to Z15. Do not modify or add any other component/device (such

as filter, lens hood, etc.) to the camera; make sure to use the original battery; otherwise it may ends up with

worse performance or even internal malfunction.

Z15 can only work with Autopilot system specified by DJI Innovations (Ace One/ Ace WayPoint/ WooKong

M), so as to ensure the highest stability and precision.Please download the corresponding assistant software

and upgrade the autopilot system MC firmware, otherwise may lead the Z15 work abnormally.

Make sure theAutopilot system operates in the safest manner when the main power battery is connected.We

strongly recommend customers to remove all propellers, use power supply from R/C system or flight pack

battery, and keep children away during gimbal calibration and parameter setup. Please strictly follow these

steps to mount and connect gimbal on your aircraft, as well as to install the assistant software on your

computer. Please respect the AMA’s National Model Aircraft Safety Code.

As DJI Innovations has no control over use, setup, final assembly, modification (including use of non-specified

DJI parts i.e. motors, ESCs, propellers, etc.) or misuse, no liability shall be assumed nor accepted for any

resulting damage or injury. By the act of use, setup or assembly, the user accepts all resulting liability. DJI

assumes no liability for damage(s) or injuries incurred directly or indirectly from the use of this product.

DJI and Zenmuse is registered trademark of DJI Innovations Names of product, brand, etc., appearing in this

manual are trademarks or registered trademarks of their respective owner companies. This product and

reproduced in any form without the prior written consent or authorization of DJI Innovations. No patent liability

is assumed with respect to the use of the product or information contained herein.

Note1: Upgrade WooKong M firmware to V5.08 or above, ACE ONE firmware to V4.02 or above, or ACE WayPoint firmware

to V4.02 or above.

Note2: Specified Camera and Lens Type list for Z15-N and Z15-G.

(Items in gray italics font are not yet supported at present.)

Z15 Type

Camera Type

Lens Type

Z15-N

Z15-G

SONY

Panasonic

NEX-5N

NEX-7

NEX-5R

GH2

Supported

E 16mm f/2.8(SEL16F28)

Lumix G14 mm/F2.5

Lumix G20 mm/F1.7

Not yet supported

Sonnar T*E 24mm F1.8 ZA

Lumix G 1:2.5 / 14 ASPH

Note3: All diagrams in the manual are for SONY NEX-5N with SEL16F28 unless stated, since different

camera or lens should use special component.

Product Profile

Z15 is an excellent gimbal designed for AP. The gimbal has built-in slip ring in the mechanical structure,

preventing wire rod from winding up. It also has built-in independent IMU module, special servos drive

module, HDMI- AV module, etc. Excellent job can be done by Z15 in any working mode, including

Orientation-locked control, Non orientation-locked control and FPV Mode (Reset).

Z15 Working Mode

Orientation-locked Mode

Non orientation-locked

Mode

FPV Mode

(Reset)

Gimbal Pointing

Gimbal pointing moves

with aircraft nose direction

Gimbal pointing stays

unchanged when aircraft

nose moves.

Gimbal pointing stays

the same as aircraft

nose direction when

power up

Gimbal and

Aircraft Nose

Relative Angle

Gimbal pointing keeps the

same relative angle with

aircraft nose direction

Relative angle between

gimbal pointing and aircraft

nose direction may change

Zero relative angle

between gimbal pointing

and aircraft nose

TX Control

Controlled

Not controlled

Attitude stability

YES

Vibration

Reduction

YES

Stick Meaning

ROLL is locked level in

0~2/3 command stick and

rotate in 2/3 ~endpoint;

command stick stands for

rotation angle limited to

45oin PAN; command

stick stands for gimbal

rotation velocity in TILT.

Command stick stands for

gimbal rotation velocity，Stick

center position is for 0，its

endpoint is maximum

velocity.

——

Command

Linearity

YES

——

Note1: Gimbal pointing means gimbal PAN rotation direction.

Note2: Attitude stability means that gimbal’s ROLL/TILT will not follows the aircraft’s ROLL/PITCH.

Note3: Gimbal rotating maximum velocity is corresponding to TX 100%end-point.

In Box

Gimbal ×1

In the mechanical structure, the gimbal has built-in slip rings,

preventing wire rod from winding up, which also enables free rotations

for the 3 axes rotating rods.

The gimbal has built-in Z15 gimbal special servos drive module,

independent IMU module and HDMI－AV module.

Gimbal Controller Unit (GCU)×1

Connect the gimbal controller to the autopilot system by CAN bus.

The GCU will control the gimbal’s pan, roll and tilt axes rotation.

Lens Retaining Ring×1, L-Connector ×1(Z15-N)

For fixing the camera lens.

(With jackscrew ×2)

Lens Retaining Ring Shim×1(Z15-N)

For fastening the camera lens.

Mounting Bracket ×4

For gimbal and bi-pod connection.

Camera Mount Screw×1

For camera mount.

Lens Retaining Ring Screw×1(Z15-N)

For fixing the lens retaining ring to the gimbal.

Hot Shoe ×1(Z15-G)

For fastening the camera to gimbal.

Quick Twist Screw for Hot Shoe ×1(Z15-G)

For fixing the hot shoe to camera.

Quick Twist Screw for Camera ×1(Z15-G)

For fixing the camera to gimbal.

Screw×10(Z15-N) or Screw×8(Z15-G)

For mounting gimbal to aircraft (2.5*8 Head-cup screw×8).

(OnlyZ15-N needs)For fixing the lens retaining ring (M2.5*5 Screw×2).

Gimbal Video Power Cable×1

For gimbal controller and Wireless Video Transmission Unit

connecting, transmitting AV signal.

Micro-USB Cable×1

For adjusting parameter and upgrading firmware via PC.

CAN-Bus Cable×1

Use CAN-Bus to power and communicate with the autopilot

system.

DJI

Spare Package×1

Damping units, Spare Screw, and Mounting Bracket.

Note: there are different between Z15-N and Z15-G.

Contents

WARNING & DISCLAIMER ...............................................................................................2

PRODUCT PROFILE..........................................................................................................3

IN BOX............................................................................................................................4

CONTENTS......................................................................................................................6

MATTERS NEED ATTENTION............................................................................................7

GIMBAL DESCRIPTION ....................................................................................................8

CAMERA SETUP ............................................................................................................10

MOUNT ........................................................................................................................12

CAMERA WIRING/SHUTTER CONTROL .........................................................................15

VIDEO SIGNAL TRANSMISSION .....................................................................................17

GIMBAL CONTROLLER WIRING .....................................................................................18

WORKING MODES/HDMI/AUX2/AUX3 SWITCH SETUP......................................................20

ASSISTANT ....................................................................................................................22

TEST .............................................................................................................................25

APPENDIX.....................................................................................................................27

1-PILOT SOLUTION ..............................................................................................................27

2-PILOT SOLUTION ..............................................................................................................28

PORT DESCRIPTION ..............................................................................................................29

GIMBAL LED INDICATOR .......................................................................................................30

GIMBAL LABEL DESCRIPTION .................................................................................................30

TROUBLE SHOOTING ............................................................................................................31

SPECIFICATIONS...................................................................................................................32

Matters Need Attention

For safety reasons, please pay serious attention to all following items:

Ensure nothing blocks the servo driver module rotation, to avoid motor damage.

Camera’s HDMI resolution should be set to 1080i.

Ensure to mount the side of servo driver module1 without ports to the aircraft nose

direction.

The gimbal center of gravity has been set, whose position directly determine gimbal

performance. Please do not adjust the gimbal center of gravity by yourself.

The gimbal is a high-precision control device. Do not remove any other screws in the

gimbal, which may result in bad performance or even damage.

Do not unplug any cable attaching to the gimbal ports, or even change the mechanical

structure.

Make sure all wiring is correct, otherwise may lead to gimbal abnormal work or even

out of control.

Make sure to connect Video Transmission Unit to gimbal controller before power on

the system.

The standard gimbal video power cable is recommended.

Make sure you solder the gimbal video power cable to the wireless video transmission

unit correctly, to avoid the 12V power burn the gimbal or your own device. And

ensure the cables are insulated, to prevent from short circuit.

Ensure the 12V power is safe for you own device when other power cable is used.

Make sure the wireless video transmission module current consumption does not

exceed 1A, to prevent GCU from damage.

Pay attention to that S800 power supply voltage is within the defined limits (6S), when

using one battery for both S800 and Gimbal power supply.

Different camera or lens should use special component.

Prevent the Gimbal from the power cable; otherwise it may lead to the short circuit of

the Gimbal.

Gimbal Description

Notices:

Ensure nothing blocks the servo driver module rotation, to avoid motor damage.

Clear obstacle at once if the rotating gimbal is blocked.

Tips:

Servo driver module is with two motor command input ports and one encoder private port.

HDMI-AV module converts HDMI video signal to AV video signal with a cable connecting to camera

HDMI port; also transforms TX signal into shutter control signal with a shutter control module.

(Z15-N)Shutter control module is for camera shutter control using an infrared signal emission head.

Please read the related content according to your product (Z15-N or Z15-G).

Z15-N

(To GCU G6)

Damping Unit

(To GCU G8)

Servo Driver Module Port

Encoder Private Port

Motor Command Input Port

Pan

±360° continuous rotation

Servo Driver Module 3

Cameral Mount Position

Camera Mount　Screw-hole

HDMI-AV Port

IMU Module

HDMI-AV Module

Tilt

±360° continuous rotation

±40°　 (±360° mechanic

continuous rotation)

Roll

Servo Driver Module 2

Shutter Control Module

Servo Driver Module 1

Mounting Bracket

Motor Command Input Port

Port of 8-Pin Cable

Gimbal LED Indicator

Lens Retaining Ring

Lens Retaining Ring Shim

Z15-G

(To GCU G6)

Damping Unit

(To GCU G8)

Servo Driver Module Port

Encoder Private Port

Motor Command Input Port

Pan

±360° continuous rotation

Servo Driver Module 3

Cameral Mount Position

Camera Mount　Screw-hole

HDMI-AV Port

IMU Module

HDMI-AV Module

Tilt

±360° continuous rotation

±40°　 (±360° mechanic

continuous rotation)

Roll

Servo Driver Module 2

Shutter Control Cable

Servo Driver Module 1

Mounting Bracket

Motor Command Input Port

Port of 8-Pin Cable

Gimbal LED Indicator

Hot Shoe

Camera Setup

Configure your camera by following the settings, meeting the requirements of Z15. Please read the related

content according to your product (Z15-N or Z15-G).

Sony NEX-5N /7 /5R

Shot Mode Camera Image Size

Brightness/

Color Playback Setup

Shot Mode

Manual Exposure

Camera

Drive Mode

Remote Cdr.

AF/MF Select MF

Brightness/Color

ISO

White Balance

Not use Auto

Setup

Lens Comp: Shading Off

Off

HDMI Resolution

1080i

Lens Comp: Chro.Aber

Lens Comp: Distortion

1/60 F3.5

Shutter

Aperture

Not use Auto

Please set Shot Mode as Manual Exposure M.

Shutter: Value 1/15~1/80 is recommended, do not set it bellow 1/80(like 1/120).

Aperture: According to exposure degree.

Drive Mode: Set as Remote Cdr., so that camera shutter can be controlled by TX.

AF/MF Select: Select MF, otherwise output image would be flashing.

ISO: Please fix a certain value instead of automatically.

White Balance: Please do not set it to auto white balance mode.

Lens Comp: Set Shading/Chro.Aber/Distortion Off.

HDMI Resolution: Should be set to 1080i.

Panasonic GH2

SCN

AFC

AFS

Please set Shot Mode as Manual Exposure M.

MF/AFC/AFS Select: Select MF。

Using the MOTION PICTURE Mode Menu, set the REC MODE as AVCHD(1080i)。

Table des matières

Autres manuels Zenmuse Appareil photo numérique

Zenmuse

Zenmuse Z3 Manuel utilisateur

Zenmuse

Zenmuse X5 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
