Zenith
LSP _ _ _
2 Front Panel Buttons and the Function
2.1 MUTE
2.1.1 Press the MUTE
Function: Switch between the state of mut e or not for each
channel.
Operation: Press MUTE for less than 2 seconds and then release it. The
status
of mute or not is switchable for each channel.
2.1.2 Press and Hold the MUTE
Function: Enter in the parameter setting menu of some channel.
Operation: Press and hold the MUTE (about 3 seconds) on the selected
channel till the settings page displayed on LCD. Then
release the button.
and enter into the parameter settings menu of this channel.
®Press button MAIN MENU or to switch between different
pages in this channel.
®Press CURSOR or to move cursor position, and then
rotate the Rotary Encoder to adjust the value.
3.2 Various Operations for Channel Parameter Set
3.2.1 Input / Output Mute Set
Pr®ess MUTE button to your designated channel for less than 2
seconds and release it. Mute status will be reversed when press
the button each time.
®The LED in the MUTE button will bright in red when the
channel is mute, vice versa.
®
®
®
2.2 PARAMETER Encoder
2.2.1 Rotate the Encoder
Function: Change the value or options of parameters. Rotate
clockwise to increase the value. Rotate anticlockwise to
decrease the value.
Operation: Rotate the encoder clockwise or anticlockwise.
2.2.2 Push the Menu Lock via Encoder
Function: Lock and unlock. Push and hold the encoder to lock all
buttons and encoder, push again to unlock.
Operation: Push the encoder and release it.
Operation: Press it and then release it.
2.4 CURSOR ◀ and ▶
Function: Move the Cursor position to change the parameter at the
Cursor.
Operation: Press the button and then release.
2.5 RECALL
Function: A) Enter into user program menu.
B) Return to the root menu.
Operation: Press the button and then release.
2.6 SAVE / ENTER
Function: A) Enter in the menu of saving user program.
B) Enter in the next submenu or confirm the function.
Operation: Press the button and then release.
3 Front Panel Menu Operation
3.1 Common Operation for Channel Parameter Set
Pr®ess and hold the MUTE (about 3 seconds) of the selected channel
◀ ▶
◀ ▶
3.2.2 Input / Output Gain Set
Press MAIN MENU ◀ or ▶ to switch to GAIN settings page.
Rotate the Rotary Encoder to change the value.
Can also press CURSOR ◀ or ▶ to change the cursor's
position below the value, in order to switch to other step, such
as 0.1dB or 1dB.
1 IN-A GAIN: -10.3dB
MEMORY
1 USER PROGRAM：1
Operation
1 Power on
1.1 Plug in the power cable, turn on the power switch on the panel,
then the LCD shows the brand, model and version.
1.2 When the loading is completed, the LCD shows the current
program number, name and the processor ID.
Features
• LSP204 - 2 XLR inputs, 4 XLR out LSP408 - 4 XLR inputs,
8 XLR out
• 24-bit DSP with high performance AD/DA converters
• 48kHz sampling rate
• Input/output level control with -40dB to +12dB range in
0.1dB increments
• 7 band PEQ (parametric EQ) for each input and each output -
Each EQ features parametric, low shelf 6dB, low shelf 12dB,
high shelf 6dB and high shelf 12dB
• PEQ frequency range: 19.7Hz thru 21.9kHz, gain range
-30dB to +15dB, bandwidth: 0.017 to 4.750 octave
• Output high pass and low pass filter, each filter has multiple
slopes and types
• Filter slopes: 12dB/Oct, 24dB/Oct, 36dB/Oct, 48dB/Oct
• Filter types: Butterworth, Bessel or Linkwitz-Riley
• Up to 1 second of delay for each input and output, switchable
and selectable
• Compressor for each input and output with adjustable threshold,
ratio, attack-time, release-time and knee type
• Phase reverse for each input and output
• Copy function allows settings to be copied between channels
2.3 MAIN MENU ◀ and ▶
Function: A) Switch to different settings page of the same channel at the
channel parameter set menu.
B) Switch to different menus at program management and
configuration setting.
Lock KEY&Encoder? YES
Are you sure
Lock Succeed!
Lock KEY&Encoder? NO
Are you sure
Unlock Succeed!
