English
Congratulations!
Thank you for purchasing Creative’s multiformat player, Creative ZEN™
Neeon 2. Read on to learn how to get started with your new player!
To get the most out of your player, also read the comprehensive User’s
Guide on your Installation and Applications CD.
1 Power On / Off, Play and
Pause button
Press and hold to turn the player on
or off.
Starts, pauses and resumes
playback.
Enables various functions, depending
on the mode you are in.
2Scroller
For information on using the Scroller,
see “Selecting Options” on page 2.
3 Color Super-Twist Nematic
(CSTN) display
4 USB connector
5 Reset button
6 Record button
7 Volume Decrease button
8 Volume Increase button
9 Headphone jack
10 Line-In jack
11 Microphone
12 Lock switch
12
567891011
1 2 3 4
ZEN Neeon 2 QSB.fm Page 1 Friday, June 30, 2006 9:38 AM
2 Selecting Options
Selecting Options
We use the term “Select” to mean the following actions.
1Turn the Scroller.
2Highlight the menu option you want.
3Press the Scroller.
TIPS • During playback, turn the Scroller to move between tracks, or
turn and hold the Scroller to move within a track.
• When scrolling through menu items, press and hold for two
seconds to return to the previous menu.
• When scrolling through menu items, turn the Scroller in either
direction to scroll up or down continuously.
2 31
ZEN Neeon 2 QSB.fm Page 2 Friday, June 30, 2006 9:38 AM
3 Getting Started
Getting Started
Step 1: Set Up the Software
1Turn on your computer.
You must log in as an administrator in Microsoft®Windows®before you can
set up the software. For more information, refer to your operating system’s
online Help.
2Insert the Installation and Applications CD into your CD-ROM/DVD-ROM
drive. Your CD should start automatically. If it does not, follow the steps
below:
i. Double-click the My Computer icon.
Alternatively, click Start My Computer.
ii. Right-click the CD-ROM/DVD-ROM drive icon, and then click Autoplay.
3Follow the instructions on the screen.
4When prompted, restart your computer.
5When your computer restarts, follow the product registration instructions
on the screen.
Note that you require an Internet connection to register your product.
6Follow the instructions on the screen to complete the installation.
WARNING DO NOT connect your player to your computer before setting up
the software.
NOTES You need an Internet connection to register your product.
ZEN Neeon 2 QSB.fm Page 3 Friday, June 30, 2006 9:38 AM
4 Charge the Battery
Step 2: Charge the Battery
1If you have not done so, connect your player to your computer’s USB port
using the supplied USB cable.
When the battery is charging, the battery charging icon and external
power icon flashes alternately on the CSTN display.
2To check the battery power level, disconnect your player from your
computer. The battery is fully charged when you see only the external power
icon on your player's CSTN display. It takes approximately five hours to
charge your battery fully.
NOTES • For continuous battery charging using the USB port, make sure
your computer is not in power conservation mode. For more
information on power conservation modes, refer to your
operating system's Help.
• Connect your player directly to a USB port on your computer or
a self-powered USB hub; do not connect your player to a bus-
powered USB hub.
• For express battery charging without using your computer,
purchase the ZEN Neeon 2 Power Adapter. For more
information on this and other ZEN Neeon 2 accessories, visit
www.creative.com.
LIN
ZEN Neeon 2 QSB.fm Page 4 Friday, June 30, 2006 9:38 AM
5 Select Your Menu Language
Step 3: Select Your Menu Language
1If your player is not turned on, press and hold the Play/Pause button
until your player turns on.
2When you turn on your player for the first time, the menu will be in English.
To change the language:
i. Press the Scroller.
ii. Select Menu.
iii. Select System.
iv. Select Language.
v. Select a language.
3After you have finished using your player, press and hold the Play/Pause
button until the screen turns off.
Step 4: Transfer Content
Transfer music, picture, video and other files from your CD collection or
computer to your player.
To start Creative Media Explorer
1Make sure your player is connected to your computer as shown on page 4.
2Double-click the ZEN Neeon 2 Media Explorer icon on the desktop.
To transfer or ‘rip’ music from your CD collection
1In Creative Media Explorer, click the Rip Audio CDs button.
2Follow the instructions on the screen. If you are connected to the Internet,
album information is automatically retrieved.
ZEN Neeon 2 QSB.fm Page 5 Friday, June 30, 2006 9:38 AM
6 Transfer Content
To transfer music, videos, pictures, playlists or data from your
computer
1In Creative Media Explorer, click the Browse Data button.
2Locate your media files, and using the drag-and-drop method, copy them to
the following folders in your player:
•MUSIC folder for audio files
•VIDEO folder for video files
•PICTURES folder for pictures
•PLAYLIST for playlists
NOTES • WMA files with Digital Rights Management technology cannot
be copied to your player using Windows Explorer. You can only
do so with applications that support this technology, such as
Creative Media Explorer or Windows Media®Player 10 (WMP
10) and above.
WMP 10 is included with your player. For more information on
WMP10, refer to the User’s Guide on your Installation &
Applications CD or visit Creative's 24-hour self-help Knowledge
Base (see page 12 for details).
• Your player only supports pictures in the JPEG (JPG) format.
• All video formats require conversion before they can be played
on your ZEN Neeon 2. Use Creative Media Explorer only to
convert your videos. Note that if you choose to skip a video file
during file transfer, it will not be transferred to your player.
• Your player only supports playlists created in Creative Media
Explorer.
• Data files can be copied to any location in your player.
ZEN Neeon 2 QSB.fm Page 6 Friday, June 30, 2006 9:38 AM
7 Disconnect Your Player
Step 5: Disconnect Your Player
When you have finished transferring files, disconnect your player. DO NOT
disconnect your player if you see the picture below on the display.
Track or data file transfer is in progress and disconnecting your player may
damage the content being transferred. Wait until you see the picture below
on the display before disconnecting your player.
To prevent data loss ensure that:
• you have stopped your player properly in Windows before unplugging
it from the USB port on your computer (see below).
• you do not unplug your player from the USB port on your computer
when transferring files to or from the device, or when files stored in
your player are in use.
To safely disconnect your player, click the Safely Remove Hardware
icon on the Taskbar, click Safely remove USB Mass Storage Device, and
disconnect your player when you are prompted to do so.
ZEN Neeon 2 QSB.fm Page 7 Friday, June 30, 2006 9:38 AM
8 Watch Videos, View Pictures and Play Music
Step 6: Watch Videos, View Pictures and Play Music
You are now ready to play or view files.
To watch videos
1Press the Scroller and select Menu Videos. The first video begins
playback.
2To select another video, press the Scroller and select Videos.
Select the video you want. Video playback starts automatically.
To view pictures
1Press the Scroller and select Menu Photos. The first photo in your player
is displayed.
2To select another picture, press the Scroller and select Pictures.
Select the picture you want.
To play music
1Connect your earphones to the Headphone jack.
2Press the Scroller and select Menu Music. The first track in your player
begins playing.
3To select another track, press the Scroller and select Browse Music.
Select a track or the folder containing the track that you want.
4Press the Volume buttons to increase or decrease the volume
level.
NOTES Files in your player are sorted alphabetically to enable faster
searches.
ZEN Neeon 2 QSB.fm Page 8 Friday, June 30, 2006 9:38 AM
