1.0 PURPOSE

The purpose of this App Note is to outline the EIB-UAV-01 UART’s controls.

2.0 Available UART’s

2.1 Frontend Board

The available UART’s on a fully built FXXX-DCK-15 is 2 –3 from the front end board (FSDI/FV4K has KEL J1

and Flex I/O = 2, FV2K has KEL J1 and J2 and Flex I/O = 3) then there is an additional 3 UART’s available off

the interface board EIB-UAV-01 (UART0, UART1 and UART4)

The KEL connector (J1 and J2) UARTs are pins 18 and 19 and are reserved for Camera 1 and Camera 2

connected via the KEL cable; and controlled via the z3termserv to serve VISCA commands directly to the

camera from either the encoder software (Serial/SSH VISCA menu, Camera 1 tab or through an open TCP

port to the encoder on port 1000 (KEL connector J2) and 1001 (KEL connectorJ1)

The Flex I/O connector UART pins are defined as pins 2 and 4 and are reserved for cameras such as the

Boson, Tau2 and Tamarisk. However this UART can be utilized for other devices if no thermal camera will be

used in operation. On the Term tab of the web UI this is defined as Function IR camera2

2.2 EIB-UAV-01 Interface Board

UART0 is on connector J4 (2.5mm stereo jack); Serial port interface, RS232 level. Tip=RX, Ring=TX,

Sleeve=GND and is defined within the Term Tab in the web UI as Linux Console

UART1 is on connector J2 ; Use CTSN as the buffer’s DE direction control on half duplex connections. Pin 3 is

TXD, Pin 4 is RXD and Pin 5 is CTSN. LVTTL levels are used for this connection. Within the Term Tab in the

web UI this is defined as RS485(PTZ)

UART4 is on connector J3 ; Pin 2 is RXD and Pin 3 is TXD. LVTTL levels are used for this connection. Within

the Term Tab in the web UI this is defined as User

Section 3.1.2 within this document further defines all Jacks of the EIB-UAV-01

CBL-0048-01 can be connected to J1, J2, and J3 and allow access to the UART2 pins defined. (Available for

purchase from Z3 Technology)

Figure 1 Cable CBL-0048-01

Z3C onfi dential

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

____________________________________________________________________________________

Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702

CBL-0048-01 RJ45 Jack pin correlation to EIB-UAV-01 J1,J2 and J3 pin assignments

2.3 Web UI Term Tab and Relation to UART’s on the Hardware

Figure 2 TermTab from FV2K displaying all available 6 UART’s

2.3.1 Frontend Board assignments in relation to the Serial Port within the Term Tab

Serial Z0 is J1

Serial Z1 is J2

Serial 2 (UART2) is the Flex I/O UART pins.

2.3.2 EIB-UAV-01 UART assignments in relation to the Serial Ports within the Term Tab

Serial 0 (2.5mm jack) is J4 (UART0)

Serial 1 is J2 (UART1)

Serial 4 is J3 (UART4)

Signal

GND

corresponds to RJ45 pin 6

corresponds to RJ45 pin 3

corresponds to RJ45 pin 2

corresponds to RJ45 pin 1

GND

Z3C onfi dential

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

____________________________________________________________________________________

Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702

3.0 Connectors further defined

3.1 Front End Board J1 and J2 Interface

The pin assignments of J2 (and J1 on the FV2K board) are shown in the table below.

Please note that the pin numbering of J2 on the Interface Front End PCB is opposite of that on the

Sony FCB-EV7520 camera, so that it provides a straight through pass.

(J2)

(EV7520)

Signal

Notes

TXOUT4-

Video output from camera to encoder

TXOUT4+

TXOUT5-

TXOUT5+

RESETn

Camera reset signal from encoder

BMODE

TXOUT6-

Video output from camera to encoder

TXOUT6+

TXOUT7-

TXOUT7+

GND

DC Input

+12V Power from encoder to camera.

Power comes directly from DC input

jack or PoE module, whichever is active.

DC Input

UART_TXD

VISCA UART, CPU TX to camera RX

UART_RXD

VISCA UART, camera TX to CPU RX

GND

TXOUT0-

Video output from camera to encoder

TXOUT0+

TXOUT1-

TXOUT1+

TXOUT2-

TXOUT2+

TXCLKOUT-

TXCLKOUT+

TXOUT3-

TXOUT3+

Table 1 IFE PCB J2 and Sony EV7520 Pin Out

3.1.1 Frontend Board Flexible I/O Connector (FV2K and FSDI Boards Only)

The FlexIO connector on the FV2K and FSDI boards provide a versatile interface with many different I/O

functions, including digital and composite video input path, control path, serial ports, etc.

These pins connect directly to the FPGA on the board, so their functions and I/O standard are determined by

the FPGA programming applied.

Z3C onfi dential

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

____________________________________________________________________________________

Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702

The digital I/O pins on the Flex-IO connector are programmable by software and can be used to implement

interfaces for a large number of different standards. All FlexIO pins that connect directly to an FPGA are

named AUX_*. The remaining pins have fixed functions that cannot be reassigned by software.

Pins can be programmed to be single ended or differential, input or output, and can conform to different

I/O standards such as LVTTL with 1.8V, 2.5V or 3.3V levels.

This connector is designed to provide a direct interface to popular IR cameras from FLIR, such as the Boson

or Tau, or from DRS Technologies such as the Tamarisk. However, the Flex-IO connector can easily be

programmed to accept most other common digita l formats such as LVDS, BT1120 (FSDI-DCK-1x only), etc.

The header on the FV2K and FSDI board is from JST, part number BM30B-SRDS-G-TF. Pin 1 is marked on the

PCB silkscreen by a triangle.

Signal

Aux power, +12V

AUX_D7N

AUX_D7P

GND

N/C

GND

AUX_D9P

AUX_D0N

AUX_D8N

AUX_D0P

AUX_D8P

AUX_D1N

GND

AUX_D1P

AUXD6N

AUX_D2N

AUX_D6P

AUX_D2P

AUX_D5N

AUX_CLKP

AUX_D5P

AUX_CLKN

AUX_D4N

AUX_D3N

AUX_D4P

AUX_D3P

GND

Composite Video In

Table 2: Flex-IO Connector Pinout

3.1.2 EIB-UAV-01 Connector Pin Outs

The following table is for pin connector J1:

Note: The ethernet cable used with pin connectors J1, J2, and J3 is part number CBL-0048-01. This cable can be

purchased separately from Z3 Technology.

Signal

GND

RX minus (corresponds to RJ45 pin 6)

RX plus (corresponds to RJ45 pin 3)

TX minus (corresponds to RJ45 pin 2)

TX plus (corresponds to RJ45 pin 1)

Z3C onfi dential

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

____________________________________________________________________________________

Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702

Table 1 J1 EIB-UAV-01 pin out connectors

Figure 3: EIB-UAV-01 pin out connectors

Connector

Type

Function

UART1

UART1 for PTZ. Use CTSN as the buffer’s DE direction control

on half duplex connections. LVTTL levels.

UART4/GPIO

UART4, GPIO_6 and 7. LVTTL levels.

2.5mm stereo jack

Serial port interface, RS232 level. Tip=RX, Ring=TX, Sleeve=GND

Power

Power Supply

Table 4: J2, J3, J4, J5 FV2K-DCK-15 pin out connectors

Note: The power cable used with pin connector J5 is part number CBL-0047-01. This cable can be purchased

separately from Z3 Technology.

Item

Quantity

Reference

Footprint

Z3 Part

Part

Manufacturer

MFR Part

Description

GND

Z3C onfi dential

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

EIB-UAV-01 (DCK-15) UART’s

CONFIDENTIAL DOC-USR-0220-01

____________________________________________________________________________________

Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702

Number

J1, J2, J3

DF13A-6P

JH064

HEADER

1.25mm

Hirose

DF13A-

6P-1.25H

Conn Header

1x6pins, 1.25mm,

R/A, SMT

PJK-

JPDA69

JC005

2.5mm

stereo jack

Genesis

AJ2.5-

145

2.5 mm Phono

Jack, stereo,

thru hole

JST-S4B-PH

JH063

Header 4x1

2mm R/A

JST

S4B-PH-

Header 2mm

male 4x1

Shrouded TH R/A

J22, J27

HDR8X2M-

1D27MM-SM

JH065

HEADER

8X2M

Amphenol

20021121

Header Male 2x8-

pin, 1.27mm,

VSM

J28

HDR8X1M-

1D27MM-SM

JH066

HEADER

8X1M

Harwin

M50-

3630842

Header Male 8-

pin 1.27mm Vert

Table 2 Bill of Materials for EIB-UAV-01

Figure 4: EIB-UAV-01 J2 & J3 Pinout Connectors

3.2 Connecting the DRS Tamarisk Camera Digital Interface

The DRS Tamarisk camera requires a DRS Feature Board, which provides a compatible interface to the Z3

FlexIO header. The Tamarisk Feature Board is capable to provide digital video in LVDS Cameralink format as

well as analog composite video.

The FlexIO connector is used to connect directly to the DRS Tamarisk. It provides power and control to the

camera while allowing for video capture for digital formats.

The MCX connector on the Flir Camera interface board can be used for an Analog passthrough directly to a

monitor. If a streaming analog video output is desired the MCX connector can connect directly to the MMCX

on the encoder.

The only connection needed between the camera and encoder is a FlexIO cable, wired straight pin to pin

between the camera side and encoder side. Both sides use a JST shell part number SHDR-30V-S-B.

The following pins are required:

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Z3 Technology Matériel informatique

Z3 Technology

Z3 Technology FV2K-1XA Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM8168-PCI-RPS Manuel utilisateur

Z3 Technology

Z3 Technology DM8168-MOD-35 Manuel utilisateur

Z3 Technology

Z3 Technology FV2K-DCK-1x Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM8169-4CH-RPS Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM368-ZDVR Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM8168-APP-41 Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM8107-SDI2-RPS Manuel utilisateur

Z3 Technology

Z3 Technology Q603-RPS Instructions d'installation

Z3 Technology

Z3 Technology FVXK-13A-RPS Manuel utilisateur

Z3 Technology

Z3 Technology Z3CAM Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM8168-PCI-RPS Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM8107-SDI-RPS Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM368-VI-RPS Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM8168-DVR-RPS Manuel utilisateur

Z3 Technology

Z3 Technology HETM-DCK-21 Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM8168-RPS Manuel utilisateur

Z3 Technology

Z3 Technology DM816 Series Manuel utilisateur

Z3 Technology

Z3 Technology FV4K-1XA Manuel utilisateur

Z3 Technology

Z3 Technology FSDI-13A-RPS Manuel utilisateur

Z3 Technology

Z3 Technology HE4K-DCK-10 Manuel utilisateur

Z3 Technology

Z3 Technology Z3-HE2160-RPS Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM8169-4K-RPS Manuel utilisateur

Z3 Technology

Z3 Technology Z3-DM368-RPS Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
