Z GRILLS ZPG-450A Manuel utilisateur
VN082020
WOOD PELLET GRILLS
ZPG-450A/ZPG-450APro
OWNER’S MANUAL
MON TO FRI, 8:00 A.M. - 5:00 P.M. PACIFIC STANDARD TIME
SERVICE CONTACT: 1-833-947-4557/1-833-ZGRILLS
EMAIL: support@zgrills.com
WEBSITE: www.zgrills.com
1
CONTENTS
IMPORTANT SAFETY INFO
3
COMPONENT LIST
6
ASSEMBLY INSTRUCTIONS
8
INITIAL FIRING INSTRUCTIONS
15
SUBSEQUENT START-UP
16
OPERATING TIPS
17
MAINTENANCE & CLEANING
18
TROUBLESHOOTING
20
DIGITAL THERMOSTAT CONTROL WIRING DIAGRAM
22
Z GRILLS SUPPORT
23
3-Y LIMITED WARRANTY
24
2
SAVE THIS MANUAL FOR FUTURE REFERENCE
3
IMPORTANT SAFETY INFO
GENERAL WARNINGS
Please read this entire manual before installation and use of the pellet fuel-burning
appliance. Failure to follow these instructions could result in property damage, bodily
injury or even death.
Contact local building or fire officials about restrictions and installation inspection
requirements in your area.
This grill is for outdoor use only. DO NOT use it in any enclosed area.
DO NOT store or use combustible materials or liquids near this appliance.
Keep children away while it is in use.
Maintain a safe distance between your grill and any combustible material.
DO NOT move your grill while operating or while it is hot. Wait until the grill is
completely cold.
If a grease fire occurs, turn “off”and leave lid closed until the fire is extinguished. DO
NOT unplug the power cord. DO NOT throw water on it. DO NOT try to smother the
fire.
Clean and maintain your grill after each use.
DO NOT use your grill on rainy days.
DO NOT touch any part of your grill while it is hot. Serious bodily injury could result.
We suggest the use of heat-resistant gloves when operating this grill.
We suggest that you should wrap the Grease Drain Pan with heavy-duty aluminum
foil before using because it is easy to clean.
For convenient and safe assembly, use at least two people to assemble the grill.
Make sure the power cord is disconnected before performing any service or
maintenance.
4
DO NOT place anything heavy on top of hopper lid. It is not a shelf and is a tip hazard.
Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or
similar liquids to start or ‘freshen up’ a fire in this appliance. Keep all such liquids
well away from the appliance when in use.
Do not use accessories not specified for use with this appliance.
NOTE: A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED
CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF
UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN
ACCORDANCE WITH THESE INSTRUCTIONS.
5
PELLET RESTRICTIONS
This grill is designed for use of wood pellets only designed for burning in wood pellet
grills. Do Not Use Pellet Fuel Labeled As Having Additives.
We suggest that you use Z GRILLS BBQ WOOD PELLETS, which are specifically
made to work in our grills. There is no guarantee that other brands of pellets are
suitable for use in Z GRILLS. And Z GRILLS assumes no liability for any loss, damage
or injury caused by the use of any other brands of pellets.
Always keep the Pellet Hopper dry, the wood pellets will expand greatly, break apart
and even jam the feed system if the pellets get wet or are exposed to high humidity.
CARBON MONOXIDE WARNING
Follow these guidelines to prevent this colorless, odorless gas from poisoning you,
your family or others.
Know the symptoms of carbon monoxide poisoning: headache, dizziness, weakness,
nausea, vomiting, sleepiness, and confusion. Carbon monoxide reduces the blood’s
ability to carry oxygen. Low blood oxygen levels can result in loss of consciousness
and death.
See a doctor if you or others develop cold or flu-like symptoms while cooking or in
the vicinity of this appliance. Carbon monoxide poisoning, which can easily be
mistaken for a cold or flu, is often detected too late.
Alcohol consumption and drug use increase the effects of carbon monoxide
poisoning.
Carbon monoxide is especially toxic to mother and child during pregnancy, infants,
the elderly, smokers, and people with blood or circulatory system problems, such as
anemia, or heart disease.
6
COMPONENT LIST
ITEM
QTY
DESCRIPTION
ITEM
QTY
DESCRIPTION
1
2
Hinge Assembly
24
1
Hopper Lid Handle
2
2
Pin
25
2
Wheels
3
1
Fan
26
1
Firepot Welding Assembly
4
1
Lid
27
2
Axle Bolt
5
1
Name Plate
28
1
Wheeled Leg Base
6
1
Lid Handle
29
1
Footed Leg Base
7
1
Grill Chamber Assembly
30
1
Heat Baffle
8
1
Hopper Assembly
31
1
Grease Drain Pan
9
1
Chimney Cap Assembly
32
1
Porcelain Grills
10
1
Smoke Stack Assembly
33
1
Warming Rack
11
1
Smoke Stack Gasket
34
1
Hopper Bottom Cover
12
1
RTD Temperature Probe
35
1
Hopper Guard
13
2
Foot Pad
36
1
Hopper Shell
14
1
Front Shelf Left Bracket
37
1
Cable Box
15
1
Hot Rod (Ignitor)
38
1
Power Cord
16
1
Feeder Assembly
39
1
Digital Control
17
1
Front Shelf Right Bracket
40
1
Auger Drive Motor
18
1
Front Table
41
1
Auger Nylon Ring
19
1
Grease Bucket
42
1
Auger
20
2
Leg A
43
1
Hopper Handle
21
2
Leg B
44
1
Hopper Lid
22
1
Side Table
45
1
Insulation
23
1
Cable Clip
46
1
Heat Insulation Foam
7
HARDWARE PACKAGE LIST
ITEM
QTY
DESCRIPTION
ITEM
QTY
DESCRIPTION
A
4
Hexagon Bolt 1/4-20×1/2
H
2
Hexagon Nut 1/4-20
B
36
Bolt 1/4-20×1/2
I
2
Gasket (OD0.75×ID0.4)
C
4
Step Screw 1/4-20
J
24
Gasket (OD0.6×ID0.25)
D
4
Cap Nut 1/4-20
K
1
Screwdriver
E
28
Spring Washer
(OD0.4×ID0.25)
L
2
Open End Wrench
F
2
Bolt 8#-32×4/17
M
2
Cap Nut 5/16-18
G
4
Gasket (OD0.73×ID0.25)
8
ASSEMBLY INSTRUCTIONS
PARTS DIAGRAM
