CLM920_TE5 LTE Module Hardware Manual

Version 1.1

Address:Office 603, Building E, No.666, Shengxia Road,

Shanghai, China

HomePage: http://www.yuge-info.com

Mail: [email protected]

Tel:021-50177336

YUGA Information Technology Co.,Ltd

Revision

Date

Description

Author

V1.0

20170710

Initial

David

V1.1

20170825

Cheung

CLM920_TE5 LTE Module Hardware Manual

YUGAInformation Technology Co.,Ltd

Contents

1 Introduction....................................................................................................................................................... 7

2 Product Overview ............................................................................................................................................ 7

2.1 General Description ................................................................................................................................. 7

2.2 Key Features............................................................................................................................................. 8

2.3 Module Function..................................................................................................................................... 10

3 Application Interface ......................................................................................................................................11

3.1 General Description ................................................................................................................................11

3.2 Module Interface..................................................................................................................................... 12

3.2.1 52-pin Goldfinger ............................................................................................................................ 12

3.2.2 Interface definition .......................................................................................................................... 13

3.3 Power Interface ...................................................................................................................................... 15

3.3.1 Power Design .................................................................................................................................. 16

3.3.2 Reference Design of Power Supply............................................................................................. 17

3.3.3 VDD_EXT 1V8 output..................................................................................................................... 18

3.3.4 Power-on sequence........................................................................................................................ 19

3.4 Reset control........................................................................................................................................... 19

3.4.1 Power off .......................................................................................................................................... 20

3.5 USB interface.......................................................................................................................................... 21

3.6 UART interface....................................................................................................................................... 22

3.7 USIM interface........................................................................................................................................ 23

3.7.1 USIM card reference circuit........................................................................................................... 23

3.7.2 UIM_DET Hot-Plug Reference Design ........................................................................................ 24

3.8 General purpose GPIO interface ......................................................................................................... 25

3.9 Network Indication Interface................................................................................................................. 25

3.10 Analog voice interface......................................................................................................................... 26

3.10.1 Analog Voice Reference Design ................................................................................................ 26

3.10.2 Analog Voice Reference Design ................................................................................................ 27

3.11 PCM audio interface............................................................................................................................ 28

3.12 Antenna Interface................................................................................................................................. 29

4 Overall Technical Indicators ........................................................................................................................ 31

4.1 Overview of this chapter........................................................................................................................ 31

4.2 Operating frequency .............................................................................................................................. 32

4.3 Conducted RF Measurements radio frequency................................................................................. 32

4.3.1 Test environment ............................................................................................................................ 32

4.3.2 Test standards................................................................................................................................. 33

CLM920_TE5 LTE Module Hardware Manual

YUGAInformation Technology Co.,Ltd

4.4 Conducted receive sensitivity and transmit power............................................................................ 33

4.5 Antenna requirements........................................................................................................................... 34

4.6 Power consumption characteristics..................................................................................................... 36

5 Interface electrical characteristics............................................................................................................... 37

5.1 Operating Storage Temperature.......................................................................................................... 37

5.2 Module IO electrical characteristics..................................................................................................... 37

5.3 Power supply characteristics................................................................................................................ 38

5.4 Electrostatic characteristics.................................................................................................................. 38

6 Structural and mechanical properties......................................................................................................... 38

6.1 Appearance............................................................................................................................................. 38

6.2 Mini PCI Express connector ................................................................................................................. 39

6.3 Module fixing method ............................................................................................................................ 39

CLM920_TE5 LTE Module Hardware Manual

YUGAInformation Technology Co.,Ltd

Figure Index

Figure 2- 1 CLM920_TE5 Functional Diagram...........................................................................................11

Figure 3- 1 TOP and BOTTOM of Goldfinger............................................................................................... 12

Figure 3- 2 TOP and BOTTOM of Goldfinger Detail A&B .......................................................................... 13

Figure 3- 3 GSM TDMA Power Supply Voltage Drop ................................................................................. 16

Figure 3- 4 VBAT Power Supply .................................................................................................................... 17

Figure 3- 5 Reference Design of LDO linear power supply........................................................................ 17

Figure 3- 6 Reference Design of DC switching power supply ................................................................... 17

Figure 3- 7 Reference Design of PMOS tube to control the power switch .............................................. 18

Figure 3- 8 Power-on sequence diagram...................................................................................................... 19

Figure 3- 9 Reset Reference Circuit .............................................................................................................. 20

Figure 3- 10 RESET sequence diagram ....................................................................................................... 20

Figure 3- 11 USB design circuit diagram ...................................................................................................... 21

Figure 3- 12 UART serial port design............................................................................................................ 22

Figure 3- 13 Level conversion circuit............................................................................................................. 23

Figure 3- 14 USIM design circuit.................................................................................................................... 23

Figure 3- 15 Hot plugging of the USIM card................................................................................................. 24

Figure 3- 16 WAKEUP_OUT signal wave.................................................................................................. 25

Figure 3- 17 network indicator circuit diagram ............................................................................................. 26

Figure 3- 18 Analog voice reference circuit .................................................................................................. 27

Figure 3- 19 External audio codec reference circuit.................................................................................... 27

Figure 3- 20 PCM short mode sequence diagram....................................................................................... 29

Figure 3- 21 RF connector location map....................................................................................................... 29

Figure 3- 22 RF connector dimensions ......................................................................................................... 30

Figure 3- 23 Recommended Coaxial RF Cable Dimensions ..................................................................... 30

Figure 3- 24 Antenna matching circuit........................................................................................................... 31

Figure 3- 25 Received signal strength with and without diversity antenna.............................................. 31

Figure 6- 1 CLM920_TE5 appearance.......................................................................................................... 39

Figure 6- 2 Connector dimensions................................................................................................................. 39

CLM920_TE5 LTE Module Hardware Manual

YUGAInformation Technology Co.,Ltd

Table Index

Table 2- 1 Operating frequency band.............................................................................................................. 8

Table 2- 2 Key Features .................................................................................................................................... 9

Table 3- 1 IO parameter definitions ............................................................................................................... 13

Table 3- 2 Interface definitions ....................................................................................................................... 13

Table 3- 3 Power pin definitions ..................................................................................................................... 16

Table 3- 4 Reset Pin Definition....................................................................................................................... 20

Table 3- 5 Power-on sequence parameters ................................................................................................. 19

Table 3- 6 RESET Pin Definitions .................................................................................................................. 20

Table 3- 7 USB interface pin definitions........................................................................................................ 21

Table 3- 8 UARTserial signal definitions....................................................................................................... 22

Table 3- 9 USIM Pin definitions...................................................................................................................... 23

Table 3- 10 SIM Hot-plug detective pins definitions.................................................................................... 24

Table 3- 11 General GPIO Pin Definitions.................................................................................................... 25

Table 3- 12 Network LED Pin Definition........................................................................................................ 25

Table 3- 13 Network indicator status ............................................................................................................. 26

Table 3- 14 Analog voice pin definitions ....................................................................................................... 26

Table 3- 15 PCM Pin Definition ...................................................................................................................... 28

Table 3- 16 PCM Parameter ........................................................................................................................... 28

Table 3- 17 RF Connector Parameters ......................................................................................................... 30

Table 4- 1 RF Frequency Table...................................................................................................................... 32

Table 4- 2 Test Instruments ............................................................................................................................ 32

Table 4- 3 2G 3G RF specifications............................................................................................................... 33

Table 4- 4 4G RF sensitivity index ................................................................................................................. 33

Table 4- 5 4G RF transmission power........................................................................................................... 34

Table 4- 6 Main Antenna specifications ........................................................................................................ 35

Table 4- 7 GNSS Antenna specifications...................................................................................................... 35

Table 4- 8 GSM power consumption ............................................................................................................. 36

Table 4- 9 WCDMA power consumption....................................................................................................... 36

Table 4- 10 LTE power consumption............................................................................................................. 36

Table 4- 11 TDS-CDMA power consumption............................................................................................... 37

Table 4- 12 CDMA power consumption ........................................................................................................ 37

Table 5- 1 4G module operation and storage temperature ........................................................................ 37

Table 5- 2 CLM920_TE5 Module IO Electrical Characteristics............................................................. 37

Table 5- 3 CLM920_TE5 module operating characteristics .................................................................... 38

Table 5- 4 CLM920_TE5 ESD Characteristics............................................................................................. 38

CLM920_TE5 LTE Module Hardware Manual

YUGAInformation Technology Co.,Ltd

1 Introduction

This document is the hardware interface manual of the wireless solution product

CLM920_TE5 Mini PCIE module. It is intended to describe the hardware composition and

functional characteristics of the module solution product, application interface definition

and usage, electrical and mechanical characteristics, etc., provide hardware instructions

for users’application development based on the product.

2 Product Overview

2.1 General Description

CLM920_TE5 module provides data connectivity on FDD / TDD / TD-SCDMA / UMTS /

EVDO / CDMA / EDGE / GSM networks and integrated GPS service with PCI Express

Mini Card 1.2 standard interface. The module bases on Qualcomm's MDM9x07, supports

Cat4 which upload/download speed can reach 50Mbps/150Mbps, fully supports VOLTE

and SRLTE and supports embedded operating system such as Windows 7/Windows

8/Windows 10/Android /Linux/WinCE.

CLM920_TE5 module can be applied in the following applications:

Vehicle System

Wireless POS System

Wireless Advertising, media

Remote Monitor System

Intelligent Meter Reading System

Mobile Broadband

Industrial Automation

Other Wireless Terminal Device

CLM920_TE5 LTE Module Hardware Manual

YUGAInformation Technology Co.,Ltd

2.2 Key Features

Table 2- 1 Operating frequency band

Network

Band

Product Series

CLM920_TD5

CLM920_TE5

CLM920_NC5

GSM

GSM850



GSM900



GSM1800



GSM1900



LTE(FDD)

LTE FDD B1



LTE FDD B2



LTE FDD B3



LTE FDD B4



LTE FDD B5



LTE FDD B7



LTE FDD B8



LTE FDD B17



LTE FDD B20



LTE FDD B28



LTE(TDD)

LTE TDD B38



LTE TDD B39



LTE TDD B40



LTE TDD B41



TD-SCDMA

TD-SCDMA B34



TD-SCDMA B39



WCDMA

BAND 1



BAND 2



BAND 3



BAND 5



BAND 8



CDMA1x/EVDO

BC0

(optional)



GNSS

GLONASS



GPS



BeiDou/Compass



Category 1



①GNSS function is optional.

②The module supports Cat4 as default. In case of Cat1 module, label is different.

Cat1 doesn’t support diversity antenna.

CLM920_TE5 LTE Module Hardware Manual

YUGAInformation Technology Co.,Ltd

Table 2- 2 Key Features

Feature

Details

Physical

Characteristics

51mmx30mmx4.1mm

Mounting

Grounding screw holes (2)

Application

processor

Single-core ARM Cortex-A7 processor, clocked at

1.2GHZ, 256kB level 2 cache

Power Supply

3.3V - 4.2V Typical supply voltage:3.7V

Standby Current

< 5mA

Application

Interface

Standard SIM interface, support 3.0V/1.8V,

support hot plug

USB2.0 (High-Speed)

Hardware reset interface

UART serial interface

PCM/Analog voice interface

Power interface

Network status indication interface

GPIO interface

Antenna connector

Main Antenna Connector（MM4829-2702RA4）

Diversity Antenna connectorMM4829-2702RA4）

GPS Antenna connector（MM4829-2702RA4）

Transmitting Power

LTE:

Class 3 (23dBm±2dB)

UMTS:

Class 3 (24dBm+1/-3dB)

TD-SCDMA:

Class 2 (24dBm+1/-3dB)

CDMA2000：

Class 3 (24dBm+3/-1dB)

GSM/GPRS:

Class 4 (33dBm±2dB) GSM850/GSM900

Class 1 (30dBm±2dB) DCS1800/PCS1900

CLM920_TE5 LTE Module Hardware Manual

YUGAInformation Technology Co.,Ltd

Data services

GSM/EDGE:

GPRS: DL 85.6 kbps/UL 85.6 kbps

EDGE: DL 236.8 kbps/UL 236.8 kbps

WCDMA:

UMTS R99：DL 384 kbps/UL 384 kbps

DC-HSPA+: DL 42 Mbps/UL 5.76 Mbps

TD-SCDMA:

TD-HSDPA/HSUPA: 2.2Mbps（UL）/2.8Mbps（DL）

EV-DOr0/DOrA

CDMA 1xEVDOr0: DL 2.4Mbps/UL 153kbps

CDMA 1xEVDOrA: DL 3.1Mbps/UL 1.8Mbps

LTE:

LTE FDD:DL 150Mbps/UL 50Mbps@20M BW cat4

LTE TDD:DL 130Mbps/UL 35Mbps@20M BW cat4

LTE FDD:DL 10Mbps/UL 5Mbps@20M BW cat1

LTE TDD:DL 10Mbps/UL 5Mbps@20M BW cat1

Satellite

positioning

GPS/BEIDOU/GLONASS

Protocol：NMEA

Diversity antenna

Supports LTE diversity antenna

AT instruction

Supports standard AT command set（Hayes 3GPP TS

27.007 和27.005）

SMS

Text and PDU mode

Point to point MO and MT

SMS storage: USIM card/ME by default

Virtual network card

Support USB virtual network card

Temperature Range

Normal operation: –35°C to +75°C

Restricted operation: –40°C to +85°C

Storage temperature: -45°C to +90°C

Module function

distinction

On the label paper M shorts for the main set, D shorts

for diversity, G shorts for GPS, V shorts for analog

voice

2.3 Module Function

CLM920_TE5 module contains the following circuit elements:

Baseband processing unit

Power management unit

Memory unit

Table des matières

Autres manuels Yuga Unité de contrôle

Yuga

Yuga CLM920 Manuel d'installation

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
