Yamaha NS-E60 Manuel utilisateur

Thank you for selecting this Yamaha NS-E60

speaker system.

This model is designed mainly to be used as an

effect speaker system.

➂Remove your finger from the tab to allow it to lock

snugly on the cable’s wire end.

➃Test the security of the connection by tugging

lightly on the cable at the terminal.

Note

Do not let the bare wires touch each other as this

could damage the speaker and/or the amplifier.

PRECAUTIONS

Read these precautions carefully before operating

your speaker.

●When using an amplifier with a rated output power

higher than the music input of the speaker, care

should be taken never to exceed the speaker’s

music input.

●Do not attempt to clean the speaker with chemical

solvents as this might damage the finish. To clean,

wipe with a dry, soft cloth.

●To prevent the enclosure from warping or discolor-

ing, do not place the speaker where it will be

exposed to direct sunlight or excessive humidity.

●Do not place the speaker where it is liable to be

knocked over or struck by falling objects. Stable

placement will also ensure better sound perfor-

mance.

●Placing the speaker on the same shelf or rack as

the turntable can result in feedback.

●Anytime you note distortion, reduce the volume con-

trol on your amplifier to a lower setting. Never allow

your amplifier to be driven into “clipping”.

●Though this speaker is a magnetic shielding type,

there may be an influence on TV picture according

to the type of TV or the placement of the speaker.

In such a case, place the speaker apart from the TV

so that there is no influence on TV picture.

●Secure placing is the owner’s responsibility.

YAMAHA shall not be liable to any accident

caused by an improper placing of the speaker.

CONNECTION TO

YOUR AMPLIFIER

BEFORE MAKING CONNECTIONS, MAKE SURE

THAT THE AMPLIFIER IS SWITCHED OFF.

■CONNECTIONS

●Connect the push-type input terminals at the rear of

the speakers to the speaker output terminals of

your amplifier with the provided speaker cables.

●One side of the speaker cable is marked by a white

line. Connect the (+) terminals on both the amplifier

and the speakers using this white-marked side.

Connect the (–) terminals on both components

using the unmarked side of the cable.

●Connect the left speaker to the left (marked L) ter-

minals of your amplifier, and the right speaker to

the right (marked R) terminals, making sure not to

reverse the polarity (+, –). If one speaker is con-

nected with reversed polarity, the sound will be

unnatural and lack bass.

Procedures:

➀Press the tab on the terminal down, as shown in

the figure.

➁Insert the bare wire end properly into the terminal

hole. [Remove approx. 5 mm (1/4”) insulation

from the speaker cable.

NS-E60 Natural Sound Bass-Reflex

Type Effect Speaker System

Press tab

White line White line

Left speaker

Right speaker

Speaker output

terminals of the

amplifier

Side long configuration (facing right)

Side long confirugation (facing left)

To hang in upright configuration

Hang the speakers upside down so that they face

downward as figured left.

To hang in side long configuration

Hang the speakers so that each of them faces inside

as figured below.

WARNING:

* Each speaker weigh 1.4 kg (3 lbs. 1 oz.). Do not

attach them to thin plywoods or soft wall surface

materials, as the screws may tear free from flimsy

surfaces, causing the speakers to fall and be dam-

aged, or result in personal injury.

* Do not fasten the speakers to walls with nails, adhe-

sives, or other unsound hardware. Long-term use

and vibrations may cause them to pull free.

* To avoid accidents resulting from tripping over loose

speaker cables, fix these to the wall along with the

speakers.

SPECIFICATIONS

Type...............................Full-Range Bass-Reflex type

Speaker Unit........10 cm paper cone woofer (JA1074)

Input Terminal .............................................Push-type

Nominal Impedance.........................................6 ohms

Frequency Response...........70 Hz – 20 kHz (–10 dB)

Nominal Input Power............................................25W

Music Input Power................................................50W

Sensitivity ...................................................90 dB/w/m

Dimensions (WxHxD)

......................................180 mm x 233 mm x 112 mm

(7-1/16” x 9-5/16” x 3-7/16”)

Weight...........................................1.4 kg (3 lbs. 1 oz.)

Accessories...................2 speaker cables (10m each)

* Specifications subject to change without notice due

to product improvements.

SETTING UP THE SPEAKERS

Set up the speakers on a shelf or rack, or hang them

on the wall.

■Attaching the speakers to a wall

The speakers may be attached to a wall by using the

hooks provided on the speakers’ back panels. Fasten

wood screws into a firm wall or wall support as shown

in the diagram, and hang the speaker hooks on the

protruding screws.

The speaker hooks are arranged so that the speakers

can be mounted in any of the three configurations

shown by the following figures.

Upright configuration

Tapping screw

(Available at the

hardware store)

Diam. 4~5 mm

Min.

12 mm

4 mm

80 mm

Wall/

wall support

60 mm
