YC-3B Owner’s Manual 1

Contents

What is the YC-3B?.................................................... 2

YC-3B window ............................................................ 2

Voice window .................................................... 2

Effect window.................................................... 4

Parameter Chart ......................................................... 6

• Copying of the commercially available music sequence data and/or digital audio files is strictly prohibited except for

your personal use.

• The software and this owner’s manual are exclusive copyrights of Yamaha Corporation.

• Copying of the software or reproduction of this manual in whole or in part by any means is expressly forbidden without

the written consent of the manufacturer.

• Yamaha makes no representations or warranties with regard to the use of the software and documentation and cannot

be held responsible for the results of the use of this manual and the software.

• The screen displays as illustrated in this Owner’s Manual are for instructional purposes, and may appear somewhat

different from the screens which appear on your computer.

• Windows is the registered trademarks of Microsoft®Corporation.

• Apple, Mac and Macintosh are trademarks of Apple Inc., registered in the U.S. and other countries.

• Steinberg and Cubase are the registered trademarks of Steinberg Media Technologies GmbH.

• The company names and product names in this Owner’s Manual are the trademarks or registered trademarks of their

respective companies.

• Click on the blue-colored text to jump to the related item in this manual.

This owner’s manual assumes that you are already familiar with basic Windows/Mac operations. If you are not, please

refer to the owner’s manual which came with your Windows/Mac software before using the YC-3B.

YC-3B Owner’s Manual

YC-3B Owner’s Manual 2

What is the YC-3B?

YC-3B is a VST Instrument which reproduces tone wheel organ sounds. The YC-3B contains 64 different

preset sound programs and lets you create your original organ sounds from these preset sound programs.

Also you can save your original organ sounds as VST presets.

YC-3B window

Voice window

1Preset

This box lets you select the preset sound in the YC-3B. Click the icon () at right of this box, then select the

preset sound. The name of the selected preset will be shown in this box.

NOTE You cannot save the edited sound from the Preset box.

2[Voice]/[Effect] buttons

These buttons switch the window between Voice and Effect. Clicking [Voice] calls up the Voice window while

clicking [Effect] calls up the Effect window. The yellow colored button indicates the currently selected window.

3Master Volume knob

Controls the entire volume of the YC-3B.

4Rotary

The lower lever alternates the Rotary Speaker status between “Run” and “Stop.” When you set this lever from

“Stop” to “Run,” the speaker rotation speed will increase gradually until it reaches the specified value. When

you set this lever from “Run” to “Stop,” the speaker rotation speed will decrease gradually until it reaches 0.

The upper lever changes the speaker rotation speed between “Slow” and “Fast.”

46 7

)

YC-3B window: Voice window

YC-3B Owner’s Manual 3

5Expression slider

Controls the expression volume. The higher the slider setting, the larger the volume, and vice versa.

6Noise, Response, Key On Click, Key Off Click

7Cho/Vib

Sets the Chorus or Vibrato effect. The button on the left side will turn this effect on/off and you can click the

desired button from six variations (upper [1] – [3] and lower [1] – [3]).

8Percussion

Determines the attack sound at the key-on timing. Clicking the button on the left side will turn this effect on/off.

9On (Linked)

Determines whether Bar 1' is disabled or not when Percussion is turned On. If this switch is turned On (lit), Bar

1' will be disabled, and vice versa.

)Percussion bars

Each of these three bars lets you edit the percussion sound level for each footage. The longer the bar or the

further it is “pulled out,” the louder the level.

By adjusting each footage, you can create your desired or favorite percussion sound.

!16', 5 1/3', 8', 4', 2 2/3', 2', 1 3/5', 1 1/3', 1' bar

Each of these nine bars lets you edit the Organ sound level for each footage. The longer the bar or the further

it is “pulled out,” the louder the level.

By adjusting each footage, you can create your desired or favorite Organ sound.

Noise knob Adjusts the tone wheel noise level.

Response knob Adjusts the attack speed when pressing the key and the decay speed when

releasing the key.

Turning this knob to the left will decrease the speed while turning it to the

right will increase the speed.

Key On Click knob Adjusts the level of the click noise generated by pressing the key.

Key Off Click knob Adjusts the level of the click noise generated by releasing the key.

Each/First select switch When “Each” is selected, a new AEG is generated independently every time

you press the key. This means that each key-on produces a new percussion

sound with the same level as that of the first one. When “First” is selected, the

AEG is generated via only the first key-on and this AEG will be maintained

until you release all the keys. This means that a new key-on (after you release

all other keys) produces a percussion sound with the AEG level at the new

key-on timing.

Length Adjusts the decay time of the percussion sound.

Turning this knob to the left will decrease the time while turning it to the right

will increase the time.

YC-3B window: Effect window

YC-3B Owner’s Manual 4

Effect window

1Preset

2[Voice] button/[Effect] button

3Master Volume knob

These are same as in the Voice window.

4Distortion

Sets the Distortion effect. The button at the top will turn on/off this effect.

5Rotary

Sets the Rotary Speaker effect. The button at the left top will turn this effect on/off.

Volume knob Adjusts the output level of the Distortion.

Drive knob Adjusts the amount of Distortion. Turning this knob to the right will increase

the Distortion amount, and vice versa.

Treble knob Adjusts the Treble gain of the Distortion.

Bass knob Adjusts the Bass gain of the Distortion.

Slow/Fast switch

Stop/Run switch

These switches are the same as in the Voice window. See page 2.

Mic Angle knob Adjusts the angle of the virtual microphones at both the right and left sides of

the speaker.

Turning this knob to the right will increase the angle, meaning that the output

sound moves widely between left and right.

R/H Balance knob Adjusts the volume balance between the rotor section (bass) and the horn

section (treble) of the rotary speaker.

Setting this knob to the center will make both the levels equal. Turning this

knob to the right will increase the horn level and decrease the rotor level, and

vice versa. Turning this knob all the way right will produce only the horn

sound, while turning it all the way to the left will produce only the rotor sound.

YC-3B window: Effect window

YC-3B Owner’s Manual 5

Horn/Rotor setup

6Reverb

Sets the Reverb effect. The button at the top will turn this effect on/off.

Speed Slow knob Adjusts the Rotary Speaker speed for the “Slow” setting. Turning this knob to

the right will increase the speed, and vice versa.

Speed Fast knob Adjusts the Rotary Speaker speed for the “Fast” setting. Turning this knob to

the right will increase the speed, and vice versa.

Slow-Fast Time knob Adjusts the time that the effect takes to reach the target speed when you

alternate the Fast/Slow status or the Run/Stop status.

Turning this knob to the left will decrease the speed, and vice versa.

Drive knob Adjusts the degree to which the Rotary Speaker modulates the sound.

Turning this knob to the right will increase the degree, and vice versa.

Room/Plate switch Changes the Reverb type to Room or Plate.

Level knob Adjusts the Reverb level. Turning this knob to the right will increase the

depth, and vice versa.

Time knob Adjusts the Reverb time. Turning this knob to the right will increase the time,

and vice versa.

Parameter Chart

Parameter Automation MIDI CC#

Preset No —

Master Volume Yes 7

Expression Yes 11

Organ Tone 1' Yes 78

1 1/3' Yes 77

1 3/5' Yes 76

2' Yes 75

2 2/3' Yes 74

4' Yes 73

8' Yes 72

5 1/3' Yes 71

16' Yes 70

Response Yes —

Noise Yes 85

Key On Click Yes 86

Key Off Click Yes 87

Percussion Percussion Yes 80

Length Yes —

Mode Yes —

Link to 1' Yes —

Perc 2' Yes 81

Perc 2 2/3' Yes 82

Perc 4' Yes 83

Chorus/Vibrato Cho/Vib Yes 93

Cho/Vib Type Yes 92

Distortion Distortion Yes —

Dist Drive Yes 94

Dist Volume Yes —

Dist Bass Yes —

Dist Treble Yes —

Rotary Rotary Yes 95

R. Speed Slow Yes —

R. Speed Fast Yes —

R. SlowFast Time Yes —

R. Drive Yes —

H. Speed Slow Yes —

H. Speed Fast Yes —

H. SlowFast Time Yes —

H. Drive Yes —

R/H Balance Yes —

Mic Angle Yes —

Slow/Fast Yes 1

Stop/Run Yes —

Reverb Reverb Yes —

Rev Type No —

Rev Level Yes 91

Rev Time Yes —

Yes: Automation available

No: Automation not available

U.R.G., Digital Musical Instruments Division

102MW-A0
