Yale NexTouch Caractéristiques techniques

P/N 80-9086-0030-010 (03-18)

Retroﬁtting or modifying this product may impact ﬁre rating, safety features and warranty.

Consult with code speciﬁcations to ensure compliance with all codes and ratings.

nexTouch®

Touchscreen and Push Button Keypad Sectional Mortise Lock

Installation and Programming Instructions

1/2"3/4"

3/32"

Optional

#3 & #2

1/8"

P/N 80-9086-0030-010 (03-18)

?Determining Handing

The hand of a door is determined from the secure side of the door.

The term "secure" means the side from which you unlock and enter.

RED Locking Slide

should face the secure

side of door.

Latchbolt -

Beveled edge

must face strike.

(See step 1

to reverse

latchbolt.)

Deadbolt

Key cylinder used for cylinder

option installation.Thumbturn

used when mortise lock is

equipped with deadbolt.

P/N 80-9086-0030-010 (03-18)

1Handing Latchbolt & Hubs

(If Necessary)

Locking

Slide

PUSH away from

square hole to create gap.

Check for free movement

of locking slide.

PUSH IN

causing locking slide

to rotate.

RED MARK on locking slide

must be on secure side of door!

Continue to

rotate locking

slide from other side

until "set" in position.

Insert ﬂat head

screwdriver to

pry latch head up.

Rotate latch head

to correct orientation.

P/N 80-9086-0030-010 (03-18)

2Preparing Door

Inside of Door

Outside of Door

Drill thru holes 1/2 way

thru door then complete

from other side to

prevent splitting.

Mortise Lock Cable Hole:

Drill only 1/2 way into

door (7/8" depth) then

STOP!

Mortise Key

Cylinder Hole:

Drill only 1/2 way

into door ONLY if

lock is equipped

with cylinder.

Mortise Deadbolt Thumbturn Hole:

Drill only 1/2 way into door ONLY if

lock is equipped with deadbolt.

P/N 80-9086-0030-010 (03-18)

#12-24x1" Flat Head Combo Screw

Frame

Optional

Strike Box

Preparing Frame & Installing Strike

This prep is standard with

or without deadbolt.

Use #3 Philips head

screwdriver

P/N 80-9086-0030-010 (03-18)

Installing Lockbody

!Do not tighten screws

until Step 10.

Make sure mortise pocket

is free from debris.

Inside

of Door

#12-24x1" Flat Head Combo Screw

Mortise Lock

Cable Hole

Use #3

Philips head

screwdriver

P/N 80-9086-0030-010 (03-18)

5Installing Key Cylinder (if applicable)

For Cylinder Option ONLY

STOP Test Operation

It may be necessary to

loosen the cylinder set screw

before installing the cylinder.

Outside of Door

Then, use #2

Philips head

screwdriver to

tighten cylinder

set screw.

First, tighten cylinder

until snug against

door with the Yale

logo horizontal.

Outside

of Door

Use #2

Philips head

screwdriver

HAND TIGHTEN.

Do not use powered

screw driver.

P/N 80-9086-0030-010 (03-18)

Adjusting for 1-3/4" to 2-1/4" Door

(if necessary)

Use screw pack for thicker door at this step.

Use appropriate fastener lengths to ensure proper installation.

Installing Rose Trim - all types

Outside

of Door

Inside

of Door

#8-32x1"

Pan Head Screw

with Thread Locker

(For 1-3/4" Door)

Use #2

Philips head

screwdriver

If provided

Tighten screws

securely but avoid

overtightening and

warping door.

P/N 80-9086-0030-010 (03-18)

Inside

Spindle

Loosen Inside Spindle

1/2 to 1 turn until

Correct Orientation. Outside

Lever Assembly

Installing Levers

Outside

of Door

Preparing Levers

Inside

Lever Assembly Correct

Orientation

Pushing levers together,

use hex wrench

to tighten set screw securely

against spindle.

P/N 80-9086-0030-010 (03-18)

9Installing Thumbturn (if applicable)

For Deadbolt Option ONLY

#6x3/8" eadOval H Screw

x2 Inside

of Door

Use #2

Philips head

screwdriver

STOP Test Operation
