Xerox Phaser 6200N Manuel utilisateur

FRU Parts List 253

FRU Parts List

Parts List Contents

Print Engine Page

PL 1.1 Covers 256

PL 2.1 Universal Paper Tray 258

PL 3.1 Paper Feed I 260

PL 3.2 Paper Feed II 262

PL 3.3 Paper Feed III 264

PL 4.1 Housing Assembly Retard 266

PL 5.1 Chute Assembly In 268

PL 6.1 Chute Assembly Out 270

PL 7.1 Chute Assembly Exit 272

PL 8.1 Transfer Roller & Fuser Assembly (CRCs) 274

PL 9.1 Xerographics 276

PL 10.1 Holder Toner Cartridge Assembly 278

PL 11.1 Frame and Drive Assemblies 280

PL 12.1 Electrical 282

PL 13.1 Harness Assemblies 284

Optional High-Capacity Feeder

PL 14.1 High-Capacity Feeder Paper Trays 2 & 3 286

PL 14.2 High-Capacity Feeder Covers 288

PL 14.3 High-Capacity Feeder Guides and Turn Chute Assembly 290

PL 14.4 Paper Pick Assembly Trays 2 & 3 292

PL 14.5 High-Capacity Feeder Harness, Board and Motor 294

Supplies and Accessories

PL 15.1 Xerox Supplies and Accessories 296

254 Phaser 6200 Color Laser Printer - Service Manual

Changes to Xerox products are made to accommodate improved components as they

become available. It is important when ordering parts to include the following

information:

■ Component's part number

■ Product type or model number

■ Serial number of the printer

Serial numbering. Particular fields in the serial number indicate the modification

level of the printer, the date of its manufacture and the sequence number of the printer

produced on that day. The serial number is coded as follows:

■ The text “S/N” followed by the serial number in the barcode.

■ The barcode does not include a field identifier.

■ The nine digit serial number is based on the following format:

PPPRSSSSS

R - Single digit numeric revision digit. To be rolled when a major product change occurs. Initiated

with a change request.

SSSSS - Five digit numeric serial number.

Serial Number Example:

LPH453072:

LPH = Product code for the 110V Printer

4= Revision level

53072 = Serial number

PPP = Three digit alphanumeric product code

Product Model Voltage Product Code

6200 N110V LPH

6200 DP 110V LPH

6200V N220V LPK

6200V DP 220V LPK

FRU Parts List 255

Using the Parts List

1. No. = The callout number from the exploded part diagram.

2. Part Number = The material part number used to order specific parts.

3. Qty = This number represents the parts per printer, not the number of parts

supplied in the actual part order.

4. Name/Description = Details the name of the part to be ordered and the number of

parts supplied per order.

5. Parts identified throughout this manual are referenced PL#.#.#; For example,

PL3.1.10 means the part is item 10 of Parts List 3.1.

6. A black triangle preceding a number followed by a parenthetical statement in an

illustrated parts list means the item is a parent assembly, made up of the individual

parts called out in parentheses.

7. The notation “with X~Y” following a part name indicates an assembly that is

made up of components X through Y. For example, “1 (with 2~4)” means part 1

consists of part 2, part 3, and part 4.

8. An asterisk (*) following a part name indicates the page contains a note about this

part.

9. The notation (NS) next to a part indicates that pariticular part is not spared, but

contained in a kit or major assembly.

10.The notation “J1<>J2 and P2” is attached to a wire harness. It indicates that

connector Jack 1 is attached to one end of the wire harness and connector J2 is

attached to the other end that is plugged into P2.

Note: Only parts showing part numbers are available for support.

Parts not showing part numbers are available on the parent

assembly.

Legend:

Identifier Meaning

CC-ring

EE-ring

KL K-clip

SScrew

256 Phaser 6200 Color Laser Printer - Service Manual

PL 1.1 Covers

S6200-228

FRU Parts List 257

PL 1.1 - Covers - FRU Parts List Table

No. Part Number Qty Name/Description

1333-4382-00 1Control Panel (Front Panel Display)

2116-0003-00 1Cover Assembly, Front (with 3-7)

3 1 Cover, Front (NS, part of PL 1.1.2)

4 1 Holder, Lever Out (NS)

5 1 Lever Out (NS)

6 1 Con. Amp 175694-3 (NS)

7116-0004-00 1Fan, Fuser

8116-0005-00 1Cover Assembly, Top

9116-0006-00 1Cover, Top Main

10 116-0007-00 1Cover Assembly, Top Image Unit (with11-19) (Door C)

11 1CAM I/R (NS)

12 1Cover, CAM (NS)

13 116-0010-00 1Spring, CAM I/R

14 116-0011-00 1Latch, Top Right

15 1Handle, Top (NS)

16 1Shaft Latch, Top (NS)

17 1Spring, Handle (NS)

18 116-0014-00 1Latch, Top Left

20 116-0016-00 1Cover, Rear

21 116-0492-00 2Stud, Top (1 per order)

22 116-0586-00 2Spring, Link (1 per order)

23 116-0963-00 2Link (1 per order)

24 116-0974-00 1Cover, Side, Right

25 116-1322-00 1Cover Assembly, Front Right

26 1Cover, Multi-Purpose Tray (NS, part of Multi-Purpose Tray

99)

27 1Multi-Purpose Tray Slide (NS, part of Multi-Purpose Tray

99)

28 116-1325-00 1Assembly, MPT ,Base

29 116-1326-00 1Cover Assembly, Front Left

30 116-1327-00 1Cover, Side, Left

31 1Cover, Top Stopper (NS)

99 116-1329-00 1Tray, MPT(with 26 and 27)

258 Phaser 6200 Color Laser Printer - Service Manual

PL 2.1 Universal Paper Tray

S6200-229

FRU Parts List 259

PL 2.1 Tray, Univeral Paper - FRU Parts List Table

ID No. Part Number Qty Name/Description

1116-1330-00 1Universal Paper Tray (with 2~6)

2116-1331-00 2Paper Feed Roller Kit*

*(2 interchangeable rollers per order)

3116-1332-00 1Assembly, Friction Clutch

4 1 Holder, Retard (NS)

5116-1334-00 1Spring, Retard

6 1 Cover, Front Tray (NS)

260 Phaser 6200 Color Laser Printer - Service Manual

PL 3.1 Paper Feed I

S6200-230

FRU Parts List 261

PL 3.1 Paper Feed - FRU Parts List Table

ID No. Part Number Qty Name/Description

1116-1335-00 1Cover, Feeder, Front

2116-1336-00 1Assembly, Turn Chute

3116-1337-00 1Cover, Paper Tray, Rear

4116-1338-00 3Block (1 per order)

5212-0237-00 4Long Screw (M3 x 85) Kit (2 per order)

262 Phaser 6200 Color Laser Printer - Service Manual

PL 3.2 Paper Feed II

S6200-231
