Xerox DocuPrint M750 Manuel utilisateur

DocuPrint M750/M760

Quick

Reference

Guide

701P31954

00-SFXM750.book Page 1 Friday, August 18, 2000 1:30 PM

00-SFXM750.book Page 2 Friday, August 18, 2000 1:30 PM

Quick Reference Guide iii

QUICK REFERENCE GUIDE

Table of Contents

BASIC INFORMATION

Basic Information 1-1

Printer Components and Parts 1-1

Printer Components 1-2

Connections 1-2

Control Panel 1-2

Printer Components 1-3

Paper Thickness Dial 1-3

Print Heads 1-3

Printer Components 1-4

HOW TO PRINT

How to Print 2-1

How to Print 2-2

Printing Banners 2-3

Printing Cards 2-4

Printing Envelopes 2-5

Printing A Single Envelope 2-5

00-SFXM750.book Page iii Friday, August 18, 2000 1:30 PM

Quick Reference Guide iv

Printing Several Envelopes 2-6

Printing Iron-On 2-7

Printing Labels 2-8

Printing Photographs 2-9

Printing Transparencies 2-10

MAINTENANCE

Maintaining Your Printer 3-1

Changing an Ink Cartridge 3-2

Cleaning and Aligning the Print Head 3-5

Cleaning the Print Head 3-5

Changing the Print Head 3-6

Printing a Test Print 3-6

TROUBLESHOOTING

Troubleshooting 4-1

Error Indicators 4-2

Error Indicators 4-3

Paper Feeding Problems 4-4

Print Quality Problems 4-5

Print Quality Problems 4-7

Printer Problems 4-9

Printer Problems 4-11

Printer Problems 4-12

Printer Problems 4-13

SERVICE AND SUPPORT

Service and Support 5-1

Ordering Supplies 5-2

Ink Cartridge/Print Head Re-Order Numbers 5-2

00-SFXM750.book Page iv Friday, August 18, 2000 1:30 PM

Quick Reference Guide 1.1

BASIC INFORMATION

Chapter One

BASIC

INFORMATION

Basic Information

To find more complete information about your

printer, refer to the Online User Guide. To access

the Online User Guide, select

Start>Programs>Xerox DocuPrint M750/

M760>User Guide.

Printer Components and Parts

1. AC power cord

2. CD, Getting Started Guide, Quick Reference

Guide, a Warranty Card (in most countries).

3. M750/M760 color printer

4. Output tray

5 . P a p e r t r a y

6. Print heads (2)

7. Ink cartridges (4)

00-SFXM750.book Page 1 Friday, August 18, 2000 1:30 PM

1.2 Quick Reference Guide

PRINTER COMPONENTS

Printer Components

Connections

1. AC power cord

2. USB cable -OR- 3. Parallel cable

Control Panel

1. Ink status light:

• Fast blink - Ink cartridge missing,

wrong ink cartridge, or out of ink

• Slow blink - Cover open or low ink

2. Paper status light:

• Fast blink - Out of paper or paper jam

3. Resume button:

• Resumes printing after clearing a paper

jam or loading paper

• Prints a test page

4. Power light:

• Light on - Power on

• Light off - Power off

• Slow blink -Incoming data

5. Power button:

• Power on

• Low power mode

00-SFXM750.book Page 2 Friday, August 18, 2000 1:30 PM

1.3

Quick Reference Guide

PRINTER COMPONENTS

Printer Components

Paper Thickness Dial

The paper thickness dial allows you to choose

envelope or paper printing. An envelope icon

shows the setting for envelope printing and a

paper icon shows the setting for paper printing.

Print Heads

Thisedgeoftheprintheadcanbeeasilydamaged.

When you remove it, be careful not to set it down

on this edge.

Note: Always keep the dial in the paper

position, except when printing envelopes.

Caution: Be careful not to set print heads down

on this edge, as they damage easily.

00-SFXM750.book Page 3 Friday, August 18, 2000 1:30 PM

1.4 Quick Reference Guide

PRINTER COMPONENTS

Printer Components

Paper Tray

The paper tray lowers onto the printer.

Output Tray

The output tray rests on the top of the paper tray

and slides into the printer.

Output Tray Extension

The output tray extension pulls out and flips up.

DocuPrint M750

ocuPrint

M750

DocuPrintM750

00-SFXM750.book Page 4 Friday, August 18, 2000 1:30 PM

1.5

Quick Reference Guide

PRINTER COMPONENTS

Bypass Tray

The bypass tray feeds one sheet at a time. The

bypass tray is used for banner paper, envelopes,

and heavy weight media. The bypass tray is

located on the back of the printer. To use the

bypass tray, flip it down.

Rear Access Door

1. The rear access door is located on the back of

the printer underneath the bypass tray. The

bypass door must be closed before you can open

the rear access door. The rear access door is

available to help you clear paper jams. 1

00-SFXM750.book Page 5 Friday, August 18, 2000 1:30 PM

1.6 Quick Reference Guide

PRINTER COMPONENTS

00-SFXM750.book Page 6 Friday, August 18, 2000 1:30 PM
