Xerox 4215 Manuel utilisateur

XEROX

Xerox MRP Family

4215/MRP, 4219/MRP, 4220/MRP, 4230/MRP

Coax Command Reference

May 1995

720P12761

Xerox Corporation

701 S. Aviation Boulevard

El Segundo, CA 90245

copyrightable material and information now allowed by statutory

or judicial law or hereinafter granted, including without limitation,

material generated from the software programs which are

displayed on the screen, such as icons, screen displays, looks,

etc.

Printed in the United States of America

Publication number: 720P12761

Xerox® and all Xerox products mentioned in this publication are

trademarks of Xerox Corporation. Products and trademarks of

other companies are also acknowledged.

Changes are periodically made to this document. Changes,

technical inaccuracies, and typographic errors will be corrected in

subsequent editions.

This document was created on the Xerox 6085 Professional

Computer System using VP software. The typeface is Optima.

Notices

Installation caution

Your Xerox 4220/MRP And 4230/MRP printers are not customer

installable. Only a Xerox service representative should install the

equipment.

Safety

CAUTION: This equipment generates, uses, and can radiate radio

frequency energy, and if not installed and used in accordance

with the installation requirements, may cause interference to

radio communications.

U.S.A.

Your printer has been tested and found to comply with the limits

for a Class A computing device pursuant to Subpart J of Part 15

of FCC rules, which are designed to provide reasonable

protection against such interference when operated in a

commercial environment. Operation of this equipment in a

residential area is likely to cause interference. In such cases, the

user at his or her own expense is required to correct the

interference.

Canada

This digital apparatus does not exceed the Class A limits for radio

noise emissions from digital apparatus as set out in the radio

interference regulations of the Canadian department of

communications.

Ce present appareil numerique n’emet pas de bruits

radioelectriques depassant les limites applicables aux appareils de

Classe A prescitees dans le reglement sur le brouillage

radioelectrique edicte par le ministre des communications du

Canada.

XEROX MRP FAMILY COAX COMMAND REFERENCE iii

NOTICES

Europe: 50 Hz, 220 - 240 V equipment

This equipment has been tested and certified in conformance

with European commission directive 82/499/ECC and VDE

0871/0875, Class A, relating to radio frequency interference.

CAUTION: In order to allow this equipment to operate in

proximity to Industrial, Scientific and Medical (ISM) equipment,

the external radiation from ISM equipment may have to be

limited or special mitigation measures taken.

Laser safety

Your pirnter complies with appropriate safety standards.

Specifically regarding lasers, the equipment complies with laser

product performance standards set by governmental,

international, and national agencies as a Class 1 laser product. It

does not emit hazardous light; the beam is totally enclosed

during all phases of customer operation and maintenance.

WARNING: Use of controls or adjustments or performance of

procedures other than those specified herein may result in

hazardous radiation exposure.

LUOKAN 1 LASERLAITE

KLASS 1 LASER APPARAT

VAROITUS: LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ

KÄYTTÖHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA

KÄYTTÄJÄN TURVALLISUUSLUOKAN 1. YLITTÄVÄLLE

LASERSÄTEILYLLE

VARNING: OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I

DENNA BRUKSANSVISNING SPECFICERADE, KAN ANVÄNDAREN

UTSÄTTAS FÖR O SYNLIG LASERSTRÄLNING, SOM ÖVERSKRIDER

GRÄNSEN FÖR LASERKLASS 1.

iv XEROX MRP FAMILY COAX COMMAND REFERENCE

NOTICES

Warning labels

There are several user accessable Laser Safety Warning labels

located on the printer. These are as shown on the next two

pages.

DANGER-invisible laser

radiation

when open and interlock

defeated for service.

AVOID DIRECT EXPOSURE TO

BEAM.

Instructions for safe service are

in SERVICE MANUAL.

NOTICES

60hz.

Configuration

50hz.

Configuration

These laser warning labels are placed on panels that cover areas

that are not operator serviceable. These panels are not to be

removed.

vi XEROX MRP FAMILY COAX COMMAND REFERENCE

NOTICES

Operational safety

Your Xerox equipment and supplies are designed and tested to

meet strict safety requirements. These requirements include

safety agency examination, approval, and compliance with

established environmental standards.

Follow these notes to ensure safe operation of your equipment.

Do this

Always connect equipment to a properly grounded power source

receptacle. If in doubt, have the receptacle checked by a

qualified electrician.

WARNING: Improper connection of the equipment grounding

conductor can result in electrical shock.

Always place equipment on a floor with adequate strength for

the weight of the machine.

Always have your Xerox service representative move or relocate

the equipment.

Always use materials and supplies specifically designed for your

Xerox equipment.

WARNING: Use of unsuitable materials may result in poor

performance and can possibly create a hazardous condition.

Always use a Xerox specified cordset with the Equipment Leakage

Circuit Interrupter/Residual Current Device (ELCI/RCD).

Do not do this

Never use an extension cord with the ELCI/RCD.

Never use the ELCI/RCD where water may enter the casing.

Never attempt any maintenance function that is not specifically

described in your Xerox MRP family documentations.

Never remove any covers or guards that are fastened with screws

unless otherwise instructed. There are no operator-serviceable

areas within these covers.

Never override or “cheat” electrical or mechanical devices.

Never operate the equipment if you notice unusual noises or

odors. Disconnect the power cord from the power source

receptacle and call Xerox service to correct the problem.

U.S. only: If you need any additional safety information

concerning the equipment or if you need Xerox supplied

materials, call the following toll-free number: 1-800-828-6571.

XEROX MRP FAMILY COAX COMMAND REFERENCE vii

NOTICES

Approvals and certification

60 Hz, 115 V Listed by Underwriters Laboratories (UL), UL1950. Meets CSA

standards, C22.2 NO 950.

50 Hz, 220 - 240 V UL classified to IEC 950

The CE marking applied to this product symbolises Rank Xerox

Declaration of Conformity with the following applicable

Directives of the European Union as of the dates indicated:

January 1, 1995: Council Directive 73/23/EEC amended by

Council Directive 93/68/EEC, approximation of the laws of the

member states related to low voltage equipment.

January 1, 1995: Council Directive 89/336/EEC, approximation of

the laws of the member states related to electromagnetic

compatibility.

A full declaration, defining the relevant Directives and referenced

standards can be obtained from your Rank Xerox representative.

Safety feature

Your printer is equipped with an Equipment Leakage Circuit

Interrupter/Residual Current Device (ELCI/RCD). This safety

device protects you if an electric outlet supplying power to the

printer is improperly wired.

U.S. configuration of ELCI/RCD

1 Window

2 Reset button.

viii XEROX MRP FAMILY COAX COMMAND REFERENCE

NOTICES

International configuration of ELCI/RCD

1 Window

2 Reset button.

If power to the printer is interrupted, follow these steps:

1. Locate the safety device, using the U.S. or International

Configuration (refer to the appropriate illustration).

2. Check to see if a red flag displays in the window of the

safety device.

3. If the red flag does not display, press and release the black

Reset button.

The red flag displays and power is restored to the system.

If power is not restored by this procedure or if the device

interrupts power to the machine again, call your Xerox service

representative.

XEROX MRP FAMILY COAX COMMAND REFERENCE ix
