WOOSIM WSP-CP 260 Manuel utilisateur

http://www.woosim.com

MODEL WSP-CP

WOOSIM SYSTEMS Inc.

#501, Daerung Technotown 3th,

448, Gasan-Dong, GeumChun-Ku,

Seoul, Korea

Tel : +82-2-2107-3700

Fax : +82-2-2107-3707

URL: http://www.woosim.com

(2,3inch Panel Printer)

Rev. 3.0

All specifications are subjected to change without notice

WSP-CP Rev. 3.0

http://www.woosim.com

2012-02-02

All specifications are subjected to change without notice



WSP-CP(CP260,CP280,CP360,CP380)

2,3inch panel printer operator’s manual.

The information contained in this manual is the property of

Woosim Systems Inc.

And may not be reproduced in whole or in part without the prior written

permission of Woosim Systems Inc.



Trademark

a registered trademark of Woosim Systems Inc.

All other trademark are the properties of their respective companies.



Caution

Some semiconductor devices are easily damaged by static electricity. You

should turn the printer “OFF”, before you connect or removed the cable on

the rear side, in order to guard the printer against the static electricity.

If the printer is damaged by the static electricity, you should turn the

printer “OFF”



Notice

The contents of this manual are subject to change without notice.

WSP-CP Rev. 3.0

http://www.woosim.com

2012-02-02



Introduction

The WSP-CP is an extremely simple and functional panel printer.

It is the ideal solution for applications which require the immediate printing

of data on a paper, whether they be of an industrial, professional or

laboratory nature.

Medical analyzer, Industrial instrument, Recorder, Geological analyzer,

Underground analyzer, Chemical analyzer, Metallic analyzer, etc.

The general features of WSP-CP printer are as follows:

X Very silent printing thru direct thermal printing method.

X High speed(200mm/sec-2inch & 170mm/sec-3inch, MAX)

X UART(RS-232C or TTL), USB interface.

X Auto cutting

X Support text and graphic printing.

X Intutive LED’s indicate Power(on/off), Error

X Easier paper loading by CLAMSHELL design.

X Easier maintenance with self-diagnostic.

X One touch paper cover

X In field programming – Update Firmware, Download Fonts and Logos

X Microsoft Windows XP / VISTA / 7 / CE / Linux / Android compatible.

X Flow control : Software (XON/XOFF)

※ Hardware flow control not supported in printer.

WSP-CP Rev. 3.0

http://www.woosim.com

2012-02-02

X Using the Printer

● Be careful not to drop or bump the printer on a hard surface.

● Do not install the printer in direct sunlight or such areas.

Suitable environment for the use of the printer is as follows:

◆ Operating temperature :-10°C to 50°C

◆ Relative humidity : 30% to 85%

● Do not install the printer near devices that generate strong

electromagnetic fields such as a copy machine.

● Do not open the platen cover during printing .

● Do not remove or reinstall the communication cable during printing

or transmission.

● Do not touch the connectors of the communication during printing.

● Switch the POWER OFF when not in use.

● Do not use alcohol or other solvent.

● The AC adapter, the battery charger and the battery pack may

become warm when in use. This is normal and is not a malfunction.

● When the battery pack is used at low temperature, the length of time

the printer can be used may be shortened.

X Thermal Paper Handling

● Store the thermal paper in a cool, dry and dark place.

● Do not rub the paper with hard object.

● Do not leave the paper with hard object.

● Do not allow plastic film, erasers, or adhesive tape to touch the paper

for long periods.

● Do not stack the thermal paper with diazo copies immediately

after copying or wet-type copies.

● Do not use chemical glue.

● Always use the clean thermal paper.

WSP-CP Rev. 3.0

http://www.woosim.com

2012-02-02

CONTENTS

1. Outline ..........................................................................................................................................6

1.1. Model classifications .............................................................................................................6

1.2. Product Part Number System..............................................................................................6

1.3. Specifications..........................................................................................................................7

2. Setting up the printer...............................................................................................................9

2.1. Printer & Accessories............................................................................................................9

2.2. Printer Features ....................................................................................................................10

2.3. Dimension...........................................................................................................................11

2.3. Panel Installation Ⅰ.............................................................................................................13

2.3. Panel Installation Ⅱ.............................................................................................................14

2.4. Replacing paper roll............................................................................................................16

2.5. Specified power supply ......................................................................................................17

3. Interface......................................................................................................................................18

3.1. UART ( RS-232C or TTL )....................................................................................................18

3.2. USB .........................................................................................................................................19

4. Using the printer......................................................................................................................20

4.1. Control panel........................................................................................................................20

4.2. The self test ..........................................................................................................................21

5. Consumable Parts ....................................................................................................................22

5.1. Recommended paper..........................................................................................................22

5.2 Printing position ...................................................................................................................23

6. Revision History .......................................................................................................................24

WSP-CP Rev. 3.0

http://www.woosim.com

2012-02-02

1.1. Model classifications

1.2. Product Part Number System

WSP–CP ( ) ( ) ( )

Model name

Inch&Paper (60 Øor80 Ø)

2inch : 260 or 280

3inch : 360 or 380

Interface

A0 : UART

Power

None : 24VDC, 3A

Model name / Interface Spec.

Example) 1. Porti-S40 Serial/Bluetooth Part No. ⇒ S40/A1

2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1

S40

SC30

W25

Wired Wireless

A RS-232C 1 Bluetooth

B TTL 2 IrDA

C USB 0 None

D RS-485

E Parallel

Z None

WSP-CP Rev. 3.0

http://www.woosim.com

2012-02-02

1.3. Specifications

Item Specification

2inch (CP260, CP280) 3inch(CP360, CP380)

Print method Thermal dot line printing

Characters per line 42cpl (MAX) 64cpl (MAX)

Character size Eng. : 9×24dots, 12×24dots Kor. : 16×24dots, [24×24dots]

Optional Characters Simplified/Traditional Chinese, Arabic, Cyrillic, Russian, Tukish,

Greek, Japanese, Persian, Latin9 and Others upon request.

Resolution W 8dots/mm X H 8 dots/mm

Print width 54mm, 432dots 72mm, 576dots

Paper roll 57.5±0.5mm (60ø, 80ø) 79.5±0.5mm (60ø, 80ø)

Print speed 200mm/sec (MAX) 170mm/sec (MAX)

Dimension 260 : 91.1x104.4x67.55mm

280 : 91.1x122.4x88.43mm

360 : 113.1x104.4x67.55mm

380 : 113.1x122.4x88.39mm

Weight 260 : 286g (expert roll paper)

280 : 336g(expert roll paper)

360 : 333g (expert roll paper)

380 : 391g (expert roll paper)

Interface UART(RS-232C or TTL), USB

Barcodes

1-dimension : Code128, Code39, I2/5, Code93, UPC, EAN,

KAN, JAN, CODABAR

2-dimension : PDF417, QR Code, DATA Matrix

Driver Microsoft Widows XP / VISTA / 7

Windows CE, Linux, Android OS driver compatible

H/W spec MCU : 32bits RISC, FLASH : 4Mbytes, RAM : 8Mbytes

Receive buffer size 1M bytes

Paper cutting

method Slide cutting

Type of paper

cutting Full cut and Partial cut(1.5±0.5mm tab left at the center)

Input Power 24VDC, 3A Over

WSP-CP Rev. 3.0

http://www.woosim.com

2012-02-02

Item Specifications

Environment

conditions

Temperature -10°C ~ 50°C (operating)

-20°C ~ 60°C (storage)

Humidity 30% - 85% (operating)

Life span

(at 25℃ and rated

energy)

Activation pulse

resistance 100 million pulses or more

Abrasion

resistance

100km or more (excluding damage caused by

dust and foreign materials)

Paper cutting

resistance

700,000 cuts or more

WSP-CP Rev. 3.0

http://www.woosim.com

2012-02-02

2.1. Printer & Accessories

Your printer box should include these items. If any items are damaged or missing,

please contact your dealer for assistance.

Thermal roll paper

WSP

CP260

WSP-CP280

WSP-CP360 WSP-CP380

Bracket Screw M2x5PH

(

2EA

)

WSP-CP Rev. 3.0

http://www.woosim.com

2012-02-02

2.2. Printer Features
