Winmate W10FA3S-GSH1 Manuel utilisateur

Please read these instructions carefully before using this product, and save this manual for future use.

G-WIN Slim IP65

P-CAP Panel PC

Freescale® Cortex® A9 i.MX6

Quad Core (Optional Quad Core)

W07FA3S-GSO1

W10FA3S-GSH1

R10FA3S-GST2

R12FA3S-GSM2(HB)

R15FA3S-GSC3(HB)

Quick Start Guide

V1.1

For more information on this and

other Winmate products, please

visit our website at:

www.winmate.com

Document Part Number: 91521110100O

Android 6.0

- 2 -

CONTENTS

1 INTRODUCTION 8

1.1 Features 8

1.2 Package Contents 9

1.3 Description of Parts 10

2 GETTING STARTED 15

2.1 Turning on Your Device 15

2.2 Configuring Serial Port Settings 16

2.3 Brightness Adjustment 18

2.4 Operating the Device 19

2.5 Ethernet 23

2.6 Winmate® Home Manager (WHM) 26

2.7 Turning off Your Device 31

3 INSTALLATION 32

3.1 Wiring Requirements 32

3.2 Connecting to Other Devices 33

3.3 Connector Description 34

4 Mounting 38

4.1 VESA Mounting 38

4.2 Panel Mounting 39

5 SPECIFICATIONS 40

Hardware Specifications 40

APPENDIX 42

Appendix A: Cleaning the Monitor 42

Appendix B: Winmate Software Development Kit 43

- 3 -

FCC Statement

This device complies with part 15 FCC rules.

Operation is subject to the following two

conditions:

This device may not cause harmful

interference.

This device must accept any interference

received including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the

limits for a class "B" digital device, pursuant to part 15 of the FCC

rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference in which

case the user will be required to correct the interference at him

own expense.

- 4 -

European Union

Electromagnetic Compatibility Directive

(2014/30/EU)

EN55024: 2010/ A1: 2015

oIEC61000-4-2: 2009

oIEC61000-4-3: 2006+A1: 2007+A2: 2010

oIEC61000-4-4: 2012

oIEC61000-4-5: 2014

oIEC61000-4-6: 2014

oIEC61000-4-8: 2010

oIEC61000-4-11: 2004

EN55032: 2012/AC:2013

EN61000-3-2:2014

EN61000-3-3:2013

Low Voltage Directive (2014/35/EU)

EN 60950-1:2006/A11:2009/A1:2010/A12:2011/

A2:2013

This equipment is in conformity with the requirement of the

following EU legislations and harmonized standards. Product also

complies with the Council directions.

- 5 -

No part of this document may be reproduced, copied, translated, or

transmitted in any form or by any means, electronic or mechanical, for

any purpose, without the prior written permission of the original

manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of

their respective owners.

Disclaimer

Winmate Inc. reserve the right to make changes, without notice, to

any product, including circuits and/or software described or contained

in this manual in order to improve design and/or performance. We

assume no responsibility or liability for the use of the described

product(s) conveys no license or title under any patent, copyright, or

masks work rights to these products, and make no representations or

warranties that these products are free from patent, copyright, or

mask work right infringement, unless otherwise specified. Applications

that are described in this manual are for illustration purposes only. We

make no representation or guarantee that such application will be

suitable for the specified use without further testing or modification.

Warranty

Winmate Inc. warranty guarantees that each of its products will be

free from material and workmanship defects for a period of one year

from the invoice date. If the customer discovers a defect, we will, at

his/her option, repair or replace the defective product at no charge to

the customer, provide it is returned during the warranty period of one

year, with transportation charges prepaid. The returned product must

be properly packaged in its original packaging to obtain warranty

service. If the serial number and the product shipping data differ by

over 30 days, the in-warranty service will be made according to the

shipping date. In the serial numbers the third and fourth two digits

give the year of manufacture, and the fifth digit means the month (e.

g., with A for October, B for November and C for December).

For example, the serial number 1W16Axxxxxxxx means October of

year 2016.

- 6 -

Customer Service

We provide a service guide for any problem by the following steps:

First, visit the website of our distributor to find the update information

about the product. Second, contact with your distributor, sales

representative, or our customer service center for technical support if

you need additional assistance.

You may need the following information ready before you call:

Product serial number

Software (OS, version, application software, etc.)

Description of complete problem

The exact wording of any error messages

In addition, free technical support is available from our engineers

every business day. We are always ready to give advice on

application requirements or specific information on the installation and

operation of any of our products.

- 7 -

Safety Information

WARNING! / AVERTISSEMENT!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Toujours débrancher le cordon d’alimentation du chassis

lorsque vous travaillez sur celui-ci. Ne pas brancher de

connections lorsque l’alimentation est présente. Des

composantes électroniques sensibles peuvent être

endommagées par des sauts d’alimentation. Seulement

du personnel expérimenté devrait ouvrir ces chassis.

CAUTION/ATTENTION

Always ground yourself to remove any static charge

before touching the CPU card. Modern electronic devices

are very sensitive to static electric charges. As a safety

precaution, use a grounding wrist strap at all times. Place

all electronic components in a static-dissipative surface

or static-shielded bag when they are not in the chassis.

Toujours verifier votre mise à la terre afin d’éliminer toute

charge statique avant de toucher la carte CPU. Les

équipements électroniques moderns sont très sensibles

aux décharges d’électricité statique. Toujours utiliser un

bracelet de mise à la terre comme précaution. Placer

toutes les composantes électroniques sur une surface

conçue pour dissiper les charge, ou dans un sac anti-

statique lorsqu’elles ne sont pas dans le chassis.

- 8 -

1 INTRODUCTION

Congratulations on purchasing Winmate® G-WIN Slim IP65 with P-

CAP Panel PC. The elegantly designed, yet rugged, industrial grade

G-WIN S65 series is designed for usability with brilliant true-flat

screens, which offer superior readability and Projected Capacitive

Multi-Touch (P-CAP) technology, available in 7”, 10.1”, 12.1” and 15”

options.

G-WIN Slim IP65 Panel PC operates on Freescale® Cortex® A9

i.MX6 Dual Core 1GHz (optional Quad Core) processor and support

Android, Linux Kernel or Ubuntu operating systems. The Panel PC

features Projected Capacitive Multi-Touch (P-CAP). These models

are full IP 65 dustproof and waterproof and have M12 connectors.

1.1 Features

Winmate® G-WIN Slim IP65 with P-CAP Panel PC features:

Freescale® Cortex® A9 i.MX6 Dual Core 1GHz (optional Quad

Core)

Android, Linux Kernel or Ubuntu OS

Projected Capacitive Multi-Touch (P-CAP)

Fanless cooling system and Ultra-low power consumption

Onboard 1GB LPDDR3

Onboard 16GB eMMC Flash

Full IP65 rating

1 x LAN, 1 x RS232, 1 x USB, 1 x USB OTG, 1 x Console, 1 x

MicroSD

- 9 -

1.2 Package Contents

Carefully remove the box and unpack your device. Please check if

all the items listed below are inside your package. If any of these

items are missing or damaged contact us immediately.

Standard factory shipment list:

Panel PC

Quick Start Guide

(Hardcopy)

Driver CD & User

Manual

Varies by product

specifications

91521110100O

9171111I102Y

M12 Power Cable

M12 Serial

Interface Cable

M12 USB/ LAN

Cable

94J004L040K1

94G0123090Q0

94E0128040K0

I/O Protective

Cap x 3

60Y031131000

- 10 -

1.3 Description of Parts

W07FA3S-GSO1

Unit: mm

Dimensions: 189.4 x 145.4 x 39.8

№

Description

№

Description

󰪦

12V DC (M12 Type)

󰪩

USB OTG, Console Port,

MicroSD

󰪧

RS232 (M12 Type)

󰪪

1 Watt Speaker

󰪨

LAN, USB (M12 Type)
