Wilson Electronics Weboost Drive Reach OTR Guide d'installation

Power

Supply

Outside Antenna

This kit comes with parts

to accommodate multiple

installation options on

any vehicle.

Inside

Antenna

Drive Reach

Signal Booster

For product installation videos and more, visit:

weboost.com/install

Diagram Register your Signal Booster now!

Complete the two easy steps to register your booster and receive premium customer service,

special oers and more!

Step 1: Take a photo of your Photoregister

Code including the points ( ).

Step 2: Send it in.

Smartphone U.S. only

Text photo to 71403

Email U.S./CAN

weboost@photoregister.com

Online

Need help? Visit photoregister.com/help or text HELP to 71403.

weboost.com

GDE000284_Rev01_09.22.20

Installation

Overview

Drive Reach OTR

Cell Signal Booster

STEP 1: Select Mounting

Location & Assemble the

Outside Antenna

STEP 2: Mounting the

Outside Antenna

STEP 5: Connect Power

Supply To Booster

STEP 4: Booster Location

& Connect Cables

STEP 3: Mounting the

Inside Antenna

Find a location to place the Drive Reach

Booster and secure it with provided bracket.

Connect cable from Outside Antenna to

labeled booster port and connect cable from

Inside Antenna to labeled booster port.

Identify a place to mount the In-Vehicle

Antenna, either on the side of the seat

or on the dash and mount. The location

should be at least 18 inches but no

more than 36 inches from where the

cellular device will be used.

Once you have determined the best location

for the Outside Antenna, insert cable through

mast(s) then through Side Exit Adapter.

Screw together as shown.

Refer to Installation Guide for Detailed Instructions.

from Inside

Antenna

from Outside

Antenna

Booster

If the vehicle does not have built-in

mounting points, a Three-way Mount

is included that will work on vehicles

with mirror rails. For more info on

using Spring, see Installation Guide.

Connect the power supply cord to the end

of the booster, labeled “ ”, and plug

the power adapter into vehicles 12V DC

power supply. Enjoy your boosted signal!

Dierent Assembly Options

3-Way Mount

shown

Side Exit

Adapter

Mast

Side Exit

Adapter

mast

Drive OTR

Outside Antenna

In-Vehicle

Antenna

Velco®
