Wildgame L20B20-7 Manuel utilisateur

Invisible IR Digital Scouting Camera

User’s Manual Model # L20B20-7

NOTE: Flextime Player Software is optional. Flextime files can

be played by using most media players

page 1

Includes

User Manual

Flextime Player

Software

Camera Unit

Adjustable Strap

RESOLUTION

FLASH

FLASH RANGE

SENSOR

SENSOR RANGE

IMAGE FORMAT

MEMORY

USB

IMAGE RESOLUTION

POWER SUPPLY

BATTERY LIFE

ONBOARD POWER

HOUSING

MOUNTING

MAX: 20 MP

56 pc High Intensity Invisible IR LED’s

up to 100 feet

Passive Infrared Sensor (PIR) Motion and Heat

up to 60 feet

JPEG - Digital Stills/ AVI-Digital Video

up to 32GB SD Card (not included and required)

Class 6 and above recommended

5-PIN Micro USB style - (not included)

High (20 MP)

Medium (10 MP)

Low (5 MP)

8 AA batteries (not included and required)

Alkaline recommended

Estimated up to 1 Year or 30,000 photos

Built in capacitor to retain Date and Time

Weather resistant with rubber gaskets

Adjustable Strap - included

Note: Battery life will vary depending on camera settings as well as environmental

conditions. Camera settings such as shorter delay periods or even using

Flextime mode are examples of settings that can reduce overall battery life.

Environmental conditions such as extreme cold can also influence battery life.

page 2

Features

1. Open the door on the right of

the camera and PULL the tab

towards you. 3. Push the battery latch up to unlock.

At the same time grab the battery

compartment out.

page 3

Installing Batteries

With the camera facing up, open

the compartment door.

2. Open the door on the bottom of

the camera and PULL the tab

towards you.

With the camera facing up, open

the compartment door.

page 4

4. Make sure to insert the AA-cell

batteries based on the direction

labeled on the inside of each com-

partment. Match minus “-” sign

with the marked negative on the

battery and the plus “+” sign with

the marked plus sign on the battery.

5. Load SD memory card (up to 32GB not

included) into the SD CARD slot with the

connectors facing down.

IMPORTANT:

Make sure the camera is powered off before

removing or installing an SD card.

If you are using an SD card from other cam-

eras, please make sure to format the SD card in

your computer prior to use in your camera. New

cards are ok to use straight from the package.

page 5

1. To turn the unit ON press and

release the power button.

2. Check the battery level icon to ensure

the batteries just installed contain

the proper charge level. If so, you are

ok to proceed with camera use.

1. LCD Ready Mode: The camera will

automatically enter Ready Mode if a

button is not pressed for greater than

30 seconds. The status lights will

illuminate for a total of 2 minutes.

2. PIR LED Status Light: During the

first 2 minutes of Ready Mode, the

red light will illuminate when a PIR

event is triggered. The red light will

blink for 2-3 seconds when photo

is taken during this first 2 minutes.

After 2 minutes all indicator lights

will turn off until a button is pressed.

Power On Test Mode

TIME / DATE

LOCATION

IMAGE TYPE

EXPOSURE

TRIGGER

PIC RESOLUTION

VID RESOLUTION

PIR SENSITIVITY

ACTIVE TIME

FLEXTIME

DELAY

PICTURES TAKEN

PICTURES REMAINING

LOC1

STILL - WIDE

LOW

BOTH

HIGH

REGULAR

MED

24 HOURS

OFF

15S

0000

00:00 PM 00/00/00

page 6

1. After 30 seconds without any buttons

being pushed, the LCD will turn off

and camera enters into Power Save

or Ready Mode.

2.The LCD screen can be awakened by

pressing the Power button briefly.

Note: The LCD will not “wake up”

when camera is writing to memory.

1. To change Date & Time, enter

MENU and press the UP,DN,L or R

buttons to navigate to the DATE &

TIME icon and press ENTER.

2.Press the UP or DN navigation

button to go up or down in

sequence. Press L or R to move

to the next digit.

3.When the Time & Date are set,

press ENTER to save and press

ENTER again to go back to the

MENU.

Power Save Date/Time

TIME / DATE

LOCATION

IMAGE TYPE

EXPOSURE

TRIGGER

PIC RESOLUTION

VID RESOLUTION

PIR SENSITIVITY

ACTIVE TIME

FLEXTIME

DELAY

PICTURES TAKEN

PICTURES REMAINING

LOC1

STILL - WIDE

LOW

BOTH

HIGH

REGULAR

MED

24 HOURS

OFF

15S

0000

00:00 PM 00/00/00

ENTER

RESET

BACK

ACTIVE TIME

LOCATION TRIGGER

DELAY

PIR SENSITIVITY FLEXTIME

™

DATE & TIME

PLAY BACK

IMAGE TYPE

VIEW ASSIST

DATE & TIME

ENTER

RESET

ENTER

RESET

ENTER

RESET

page 7

1. To change Image Type, enter

MENU and press the UP,DN,L or

R buttons to navigate to the Image

Type icon and press ENTER.

2.Press the L, R button to select

STILL and press ENTER. Then

select the Resolution and press

ENTER. Select the Exposure and

press ENTER. Then select the

aspect and press ENTER.

3.When the Image Type is set, press

ENTER to save and press ENTER

again to go back to the MENU.

Location Image Type: Still

1. To change Location, enter MENU

and press the UP,DN,L or R buttons

to navigate to the LOCATION icon

and press ENTER.

2.Press the UP or DN navigation

button to go up or down in

sequence. Press L or R to move to

the next digit.

3.When the Location is set, press

ENTER to save and press ENTER

again to go back to the MENU.

Save the location of the area the camera

was installed. This is for your reference and

is optional. If you do not wish to name your

location skip to the next step.

ENTER

RESET

ENTER

RESET

ENTER

RESET

ENTER

RESET

ENTER

RESET

ENTER

RESET

page 8

1. To change Image Type, enter

MENU and press the UP,DN,L or

R buttons to navigate to the Image

Type icon and press ENTER.

2.Press the L, R button to select

VIDEO and press ENTER. Then

select the Resolution and press

ENTER. Then select the length

and press ENTER.

Image Type: Video Trigger

1. To change Trigger, enter MENU

and press the UP,DN,L or R

buttons to navigate to the Trigger

icon and press ENTER.

2.Press the L, R button to select

Trigger Mode. Then select the

ENTER to save. If PIR is selected

press ENTER again to go back to

the MENU. If FlexTime or Both is

selected you will be redirected to

the Flextime Menu (see page 11).

TRIGGER:

PIR MODE: Takes a photo only when the PIR

sensor is triggered.

FLEXTIME(Time Lapse): Takes time lapse images

at set intervals during the key movement

periods of the day, depending on your Flextime

settings.

BOTH: Both PIR and Flextime are active.

This setting allows you to choose the mode in

which the camera will be capturing images.

3.When the Image Type is set,

press ENTER to save and press

ENTER again to go back to the

MENU.

ENTER

RESET

ENTER

RESET

ENTER

RESET

ENTER

RESET

ENTER

RESET

page 9

PIR Sensitivity

PIR ACTIVE:

24 HR: The PIR can be active at all times.

DAY: The PIR can be active in daylight hours

only.

NIGHT: The PIR can be active in nighttime hours

only.

1. To change PIR Sensitivity, enter

MENU and press the UP,DN,L or

R buttons to navigate to the PIR

Sensitivity icon and press ENTER.

2.Press the L, R button to select

the sensitivity and press ENTER

to save. Then press ENTER again

to go back to the MENU.

ENTER

RESET

ENTER

RESET

1. To change the Active Time, enter

MENU and press the UP,DN,L or

R buttons to navigate to the Active

Time icon and press ENTER.

2.Press the L, R button to select

the active time and press ENTER

to save. Then press ENTER again

to go back to the MENU.

Active Time

ENTER

RESET

ENTER

RESET

PIR SENSE:

HI: The PIR detects the smallest movement.

MED: (Default) The PIR detects most common

size movements.

LO: The PIR detects only larger movements.
