WHITE KNIGHT CL43
Reversing Integrated Dryer - UK
SERVICE MANUAL
Technical Data
Exploded Views
Wiring Diagram
Parts List
January 2003
4213 094 82521
0312 432 15001
Grant Hood 2004 Page 1 04/03/2004
Service & Repair Information
Tumble Dryer White Knight CL432 Built-in Dryer - UK
I Technical Data
General
Front-loading standard door opening built-in tumble dryer model. Forward and reverse tumble. Single
or double element heating. Timer control. Induced airflow passes through rear ventilation inlets, over
heating element, through drum rear perforations, through laundry load/lint filter, through fan and into
the exhaust venting.
Door opening direction optional – left to right or right to left.
Identity
Model type, manufacturer source, date and serial number are displayed on a white label revealed
when the door is open, below where the filter is located.
HA identifies the machines as having been manufactured at the Halifax factory.
The 1st & 2nd numerals represent the year of manufacture (e.g. 2004 is represented by 04)
The 3rd & 4th numerals represent the month of manufacture (e.g. March is represented by 03).
The final 6 numerals represent the main serial number of the machine.
All information from this label should be quoted in any service communication.
Mains Voltage
220/240V
50HZ
Maximum Power Consumption
2450W Approximately
Connections
Please note; plug not fitted to built-in machines. They are designed to be connected to a double pole
switched spur with at least 3mm contact separation with a pilot lamp.
The appliance must be earthed
Dimensions
Height – 87cm (33.9”) to 89cm (34.7”) depending on the adjustable feet.
Width – 59.6cm (23¼”)
Depth – 53cm (21”)
Depth when rear vent hose is assembled – 60cm (⅝”)
Weight
With packing – 32.5kg approximately
Without packing – 31kg approximately
Air Flow
140m³/h with capacity laundry load
Grant Hood 2004 Page 2 04/03/2004
II Components
Drive Motor
Permanent split capacitor induction – 4 pole-reversing - ⅛HP with heat and current sensitive overload
protection. Trip temperature between 125°C and 155°C. Reset 90°C. Winding resistances 41.08Ω
and 43.3Ω. 8µF Capacitor.
No Load Full Load
Power Consumption 110W approximately 225W approximately
Current Consumption 0.45A approximately 0.75A approximately
Speed 1450 RPM approximately 1350 RPM approximately
Heater
Power Consumption (determined by programme)
Low Setting – 1125W
High Setting – 2250W
Temperature Overload Cut-out (TOC) (bi-metal contacts normally closed)
Contacts open - 120°C under No Air Flow condition
Contacts reset - manual operation
Inlet (Heater) Thermostat (bi-metal contacts normally closed)
Contacts open - 142°C under restricted air flow conditions
Contacts reset - 115°C automatically
Exhaust Thermostat (bi-metal contacts normally closed)
Contacts open - 60°C under normal air flow conditions
Contacts reset - 49°C automatically
Timer
Composite programme timer.
Variable time setting up to 128mins plus 12 minutes cool-down
Clockwise 5 minutes 46 seconds (heater on except for first and last 2 seconds)
Pause 2 seconds (heater off)
Anti-clockwise 10 seconds (heater off)
Pause 2 seconds (heater off)
Drum
Drum Wrapper, Front and Rear are manufactured from Galvanized Steel
Volume: 105 litres
Capacity: 6kg dry cotton
Speed: 50-59 RPM approximately
Rotation: alternating clockwise 5 minutes 46 seconds and anti-clockwise 10 seconds
Grant Hood 2004 Page 3 04/03/2004
III General Information
To assist with part identification, a key number is stated in parentheses after a specific part is
mentioned so that it can be located on the Parts List for this appliance and consequently on the
Exploded Views.
Basic Programme
After loading damp clothes into the dryer, the door must be closed or the programme cannot begin.
Clockwise rotation of the Control Knob (352) closes switch contacts within the Timer (211) to (a)
energise the main motor (101) and (b) energise the heater (227).
The Timer switch contacts will remain closed until the Timer motor mechanism returns the Control
Knob to the ‘0’ position.
The contacts controlling heating will open 12 minutes before the Timer Knob reaches the ‘0’ position.
This is to allow the circulation of cool air for prevention of creasing to synthetic garments.
The Heat Selector Switch (216) provides options for either 1.125kW or 2.25kW heating.
Thermal Controls
Temperature Sensitive Control Switches are electrically in series with the Heater (227). In most
conditions, only the Exhaust Thermostat (229) will operate to control the drying programme
(automatic reset).
An additional Manual Reset TOC (Thermal Overload Control) (228) will operate when severely
restricted or lost airflow conditions exist; i.e. air vents blocked, no motor action, belt has come off etc.
This switch can be identified by its red coloured reset button protruding from the Back Panel (413).
Grant Hood 2004 Page 4 04/03/2004
IV Adjustments and Recommendations for Dismantling
To assist with part identification, a key number is stated in parentheses after a specific part is
mentioned so that it can be located on the Parts List for this appliance and consequently on the
Exploded Views.
Before working on the appliance, the external cupboard door must be removed and the dryer pulled
out from its recess within the cupboard.
Front Access
Access to all Control Switches is available after removal of the Top Cover (386).
For the removal of the Front Panel (376), Door Microswitch (248), Bearing Housing (440), Seal (442)
and Bearings (445), the machine should be laid flat on its rear after the Top Cover (386), Top Cover
Brackets (385) and Plinth (199) have been removed.
Withdraw the securing screws from the top of the Control Panel (353) together with all of the screws
and fittings in connection with the Front Panel (376) and the Door Assembly (203). The Front Panel
can then be detached from location lugs with the Control Panel (353) and Cabinet (196).
The Banjo Assembly (440) has a location lug with the Cabinet (196) base. It can be lifted out
following disengagement of the following: Exhaust Thermostat (229), Venting Bracketry (437) and
Fan Housing Cover (447).
Rear Access Upper
For removal of the combined Back Panel (413) with Heater Unit (227), Drive Belt (125), Drum (266),
Drum Bearings (445) and Drum Front Seal (442).
Remove the Top Cover (386) and withdraw the main Wiring Loom connections from the Terminal
Block (142) and Heater terminals. Lay the machine flat on its front, supported to take the weight off
the door and controls.
With the exception of 4 screws positioned in shallow recessed channels projecting radially from the
panel centre, remove all other screws in the Back Panel (413). Lift off the Back Panel (413), which
will then allow access to the Heater Assembly (227), Inlet Thermostat (230) and Manual Reset TOC
(228).
Lift out the Drum (266) and Drive Belt (125) after removing the Back Panel. The Drum Front
Bearings (445), Drum Seal (442) and Door Microswitch (248) also become accessible at this point.
For dismantling of the Drum Rear Bearing (270), access to screws is through holes in the Drum rear.
Removal of one screw and the Earth Finger provides access to the Bearing Shaft screw. Note; it is
important that the slot in the head of the shaft centre screw is filled with electrically
conductive grease.
Rear Access Lower
The Access Panel (402) to the lower rear of the dryer only needs removing for access to the Motor
(101) and associated parts, the Exhaust Thermostat (229) and Venting Bracketry (437).
To remove the Motor Assembly (101), withdraw the Motor Bracket (432) securing screws from the
Cabinet (196) base, remove the Screw from the Fan Cover (447) and exert anti-clockwise force to
disconnect if from the Fan Housing (446). The Motor Assembly can then be withdrawn.
