INSTRUCTIONS FOR USE

TUMBLE DRYER

IMPORTANT: PLEASE READ THESE

INSTRUCTIONS THOROUGHLY BEFORE USING

THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR

FUTURE REFERENCE.

IMPORTANT USER INFORMATION

These notes are provided in the interest of safety.

You must read them before installing or using the

appliance.

- This tumble dryer is intended for NORMAL DOMESTIC

USE ONLY.

- This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use

of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children

without supervision. Children of less than 3 years should be

kept away unless continuously supervised.

-Adequate ventilation must be provided to avoid back flow of

gases into the room from appliances burning other fuels,

including open fires.

-Exhaust air must not be discharged into a flue which is used

for exhausting fumes from appliances burning gas or other

fuel.

- Please note it is not recommended that the dryer is placed

directly next to ovens or cookers as the performance of the

dryer may be affected.

- A carpet must not obstruct the ventilation openings in the

base of the dryer.

- Do not stack the tumble dryer on top of other appliances

without the correct stacking kit.

- Any electrical work required to install the appliance should

be carried out by a qualified person.

- It is important to clean the lint filter after each drying cycle

or the restrictions to airflow will extend drying times and

could cause the safety cut-out to trip.

- Under no circumstances should anything other than the

recommended articles be placed in the tumble dryer.

- The tumble dryer should be serviced by an appointed service

organisation and only genuine parts used.

- It is dangerous to alter or modify the product in any way

other than fitting authorized accessories.

- We recommend that the appliance is unplugged each time

after use. It should always be disconnected from the electricity

supply for long periods (i.e. weekends, if it is to be left

unattended for holidays etc.)

- The rear of the dryer gets quite hot during use. Position the

dryer so that the back is not accessible while in operation, but

ensure that the sides have a space available to allow airflow.

- The special mains cable and plug assembly must only be

replaced with a genuine part by the manufacturer or his service

agents in order to avoid a hazard.

-It is important to clean fluff from the window of the dryer and

around the door seal after each drying cycle. Failure to do so

could result in water leaking.

WARNING: Never stop a tumble dryer before the end of a

drying cycle unless all items are quickly removed and spread

out so that heat is dissipated.

Remove all objects from pockets such as lighters and matches.

DO NOT use a two-way adaptor, or extension lead. The dryer

must be connected to its own socket.

DO NOT block the air inlets at the base and side of your

dryer.

DO NOT allow fluff to accumulate around the tumble dryer.

Risk of fire

DO NOT exceed the recommended maximum load.

DO NOT dry unwashed items in the tumble dryer

DO NOT place articles in the dryer if anything other than a

water solution has been used in the cleaning process.

DO NOT attempt to dry dripping wet articles.

DO NOT use the tumble dryer if you suspect that it is

damaged in any way. Under no circumstances should you

attempt to repair the appliance yourself. Repairs carried out by

inexperienced persons may cause serious

injury. Consult your local appointed service engineer and

insist on genuine spare parts.

ADDITIONAL INFORMATION

Many outlets sell “universal” tumble dryer accessories. These may not fit satisfactorily and could impair the

efficient operation of your tumble dryer and may even cause air-flow restrictions not covered by our guarantee.

Crosslee always obtains test house approval for dryer accessories so use this order form to obtain genuine authentic

accessories.

INSTALLATION

Position the tumble dryer so that the plug remains accessible after installation. Do not block the vent at the side or

base of the dryer, as this will impair the working of the machine. This appliance must not be installed behind a

lockable door, a sliding door or a door with hinges on the opposite side to that of the tumble dryer.

TUMBLE DRYER VENTING

Your tumble dryer may be supplied with a vent hose (If not, one is available as an accessory).

A vent hose allows you to direct the warm, damp air expelled from the rear of the dryer to an open door or

window.

The best solution is to make a permanent connection through either a wall or a window. This is particularly

recommended for small, cool rooms and a kit for this purpose is available as an accessory.

When using a vent hose, remember the following points:

The vent hose must be at least 10cm (4 ins) in diameter.

No more than three right-angled bends should be allowed when positioning the vent hose.

Do not distort or constrict the vent hose as this will reduce the airflow.

When drying, the vent hose must always be extended to an open door or window.

The vent hose must not be shared with other appliances, for example, a cooker hood outlet.

Note: Do not obstruct or add a mesh to the vent hose outlet during use and ensure that it cannot be blocked

or bent sharply which may obstruct the airflow.

It is recommended that the interior of the hose be periodically inspected and cleaned if necessary.

FINAL INSTALLATION

Push the filter into its operating position as shown in the

diagram. Remove any dust by wiping the drum and door with

a damp cloth. Any initial smell of burning will be caused by

dust on the heater and will quickly disappear.

THE CONTROLS

A. THE TIMER Turn the timer knob fully clockwise before selecting the required drying time based on the

recommendations on the control panel.

B. HEAT SWITCH Select the required heat setting based on the recommendations on the control panel.

PREPARATION

Check care labels inside the garments.

CARE LABELS YOU MAY FIND ON YOUR FABRICS

Do not tumble dry woollen or wool mixture articles unless the article is labelled as being suitable .This should

avoid shrinkage.

Place delicate articles, e.g.tights, scarves, inside a pillowcase.

To avoid the need to iron easycare polyester/cotton items it is better to only dry small loads (i.e. half fill drum) It is

better to dry small and large articles together.

Fabric softeners, or similar products, should be used as specified by the fabric softener instructions.

Do not overload the dryer or dry large bulky items such as duvets or sleeping bags as it is important that the airflow

through the dryer is not obstructed.

The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are left at a

temperature that ensures that the items will not be damaged.

Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers,

turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being

dried in the tumble dryer.

Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or

pillows fitted with foam rubber pads should not be dried in the tumble dryer.

OPERATION

Open the door.

Load clothes loosely into the drum.

Load sheets first, starting with one corner.

Close the door.

Dry your hands.

Check that the timer is in the ‘0’position.

Plug in the machine.

Select correct heat position, (see programme chart on control panel for recommendations).

The standard cotton programme is suitable to dry normal wet cotton laundry. It is the most efficient programme in

terms of energy consumption for drying wet cotton laundry.

If your appliance is Uni-directional, a full load will typically take 90 minutes and will use approximately 2.05kWh

of electricity. A half load will typically take 55 minutes and will use approximately 1.15kWh of electricity.

If your appliance is Reversing, a full load will typically take 105 minutes and will use approximately 2.22kWh of

electricity. A half load will typically take 55 minutes and will use approximately 1.08 kWh of electricity.

The power consumption of the off-mode and the left-on mode is zero.

Turn the timer knob fully clockwise, then turn to the required time setting (see programme chart on control panel

for recommendations).

For energy labeling purposes (EN61121:2005) for a cotton dry load, use the maximum load weight for cotton and

set the timer to the recommended drying time for cotton dry as specified on the control panel.

The drum will begin rotating. Reversing drum models will stop periodically to rotate in the reverse direction for a

short time.

Should the clothes become dry before the cycle has finished, or if an excessive programme time has been selected,

the drum will continue to rotate while the thermostat will automatically switch the heater off to reduce the risk of

over drying and save energy.

If the door is opened during a cycle the dryer will stop. To restart your machine, close the door .When drying large

items such as sheets, we suggest you periodically stop the dryer to redistribute the load, and restart it immediately

afterwards.

To lengthen or shorten a timed programme, reset the timer knob.

There is an automatic 12 minute cool down period at the end of every cycle, during which the heater is switched

off. This helps to minimize creasing, and must always be used fully to avoid the risk of fire.

NEVER SWITCH THE DRYER OFF AND LEAVE A HOT LOAD IN THE DRUM. RISK OF FIRE.

ALWAYS CLEAN THE FILTER AFTER EACH USE. Failure to do so could cause the safety

cut-out to operate.

TECHNICAL DATA OVERALL DIMENSIONS:

MAXIMUM DRY WEIGHT LOADS:

Height: 67 cm

Width: 50 cm

Depth: 47 cm

For electrical ratings see plate on back of dryer.

For Model No. see serial plate inside door (needed when requesting service).

Room temperature range 5˚C to 30˚C. (Drying performance decreases as room temperature falls).

Your washing machine should have a spin speed of not less than 1000rpm for maximum efficiency.

- Pull the filter upwards and away from the appliance.

- Remove any threads or fluff by hand or with a soft brush.

- Slide the filter back.

- Wash the filter occasionally in detergent solution using a soft

brush to remove small particles.

- If your filter becomes damaged, replace it to ensure no damage is

caused to the dryer.

SAFETY CUT

OUT

MAXIMUM DRY WEIGHT LOADS:

Cotton 3kg

‘Easycare’ polyester/cotton 3kg

(For minimum creasing 1.5kg)

Delicates 3kg

THIS APPLIANCE MUST BE EARTHED

This label, positioned on the rear of your dryer,

indicates the surface is hot when in operation - avoid touching. CAUTION HOT SURFACE

This appliance is marked according to the European Directive 2012/19/EU on Waste

Electrical and Electronic Equipment (WEEE).

This guideline is the frame of a European wide validity of return and

recycling on Waste Electrical and Electronic Equipment.

798 Wall / Window Vent Kit

Note: To make a remote connection e.g. more than 30cm (12ins.)

from the dryer you will require the vent hose CL001. S.

VENT HOSE ASSEMBLY

One end of the vent hose is fitted with an adaptor which can be pushed into the exhaust outlet at the bottom rear of

the tumble dryer. The free end should be led to a suitable outlet. It may simply be hung through an open window or

a more permanent connection made using the four holes in the adapter flanges.

Note: Do not obstruct or add a mesh to the vent hose outlet during use and ensure that

it cannot be blocked or bent sharply which may obstruct the air flow. It is

recommended that the interior of the hose be periodically inspected and cleaned if

necessary.

X 3

1 2

CUSTOMER ADVICE – BEFORE CALLING FOR ASSISTANCE

If the clothes are not dry after normal drying time:

–Check that you used the correct heat setting.

–Check that you have not set the timer within a cool down period.

–Check that the lint filter has been cleaned. A blocked filter will restrict the airflow.

–Check that your dryer is heating - below the door to the left side, should feel warm to the touch after the first 10-

15 minutes of its programme.

Failure to heat may indicate the safety cut-out has operated. To reset, simply press the red button at the rear of the

machine. If it has operated then a sharp “click” will be heard.

This cut-out only operates if the airflow is severely restricted so make sure the filter is clean, the air inlets and

outlets at the side and back are not blocked, and that all other restrictions are removed before re-starting.

If the cut-out continues to operate after checking the above points, you should contact your service agent.

Check that the machine has the correct weight load in the drum before starting the appliance.

If your machine does not work check the following before calling a service engineer:-

- Check that there is a supply of electricity.

- Check that the door has been properly closed and the machine is switched on.

- Check the fuse in the moulded plug.

A call out charge will be applied for a service visit, if the call could have been avoided by

following these instructions.

ESSENTIAL CONTACT INFORMATION FOR “IN GUARANTEE” AND

“OUT OF GUARANTEE” REPAIRS.

If problems continue after checking the above points you should contact our service

agent. Please ensure that you have your serial number and model number to hand

when you make the call. To locate the serial number on your dryer, open the door and

look for a white label inside the door opening. This will indicate the appliance model

number along with the serial number.

APPROVED SERVICE AGENTS:

White Knight (Whirlpool) 0800 988 1323 (calls are free from landlines however calls from mobiles may be

charged at your network provider’s rates)

White Knight (0800 Repair): 0344 8797422 (Calls charged at basic rate).

Northern Ireland Only: (Service Network 2000) 028 90365222 (Daytime calls cost up to 14p plus 8p per minute

from BT lines Monday-Friday. Mobile and other providers’ charges may vary).

Compact SDO Uni

Suppliers name or trade mark WHITE KNIGHT

Model identifier 372, 371, 37A, 36A - TYPE

Rated capacity at full load 3kg

Appliance type Air Vented

Energy efficiency class C

Energy consumption of the appliance* 248kWh

The figures above is based on 160 drying cycles of the standard cotton programme at full and partial load and the

consumption of the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used.

Automatic/non-automatic Non-automatic

EU Ecolabel N/A

Edry 2.05kWh

Edry½ 1.15kWh

Egdry N/A

Egdry½ N/A

Egdry,a N/A

Egdry½,a N/A

Off mode power (Po) 0W

Left on mode power (Pl) 0W

Duration of left-on mode N/A

The standard cotton programme used at full and partial load is the standard drying programme to which the information

in the label and the fiche relates. This programme is suitable for drying normal wet cotton laundry. It is the most efficient

programme in terms of energy consumption for cotton.

Tt70mins

Tdry 90mins

Tdry½ 55mins

Condensing efficiency class N/A

CtN/A

Cdry N/A

Cdry½ N/A

Sound power level 64dBA

Built in/not built in This appliance is not intended to be built in.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels White Knight Séchoir

White Knight

White Knight 42AW Manuel utilisateur

White Knight

White Knight 0312 85A 15000 - 85AW Manuel utilisateur

White Knight

White Knight BG 43A Guide rapide

White Knight

White Knight 767c - 0312 767 15009 Manuel utilisateur

White Knight

White Knight C38AW Manuel utilisateur

White Knight

White Knight CL677WV Manuel utilisateur

White Knight

White Knight B96M8W Manuel utilisateur

White Knight

White Knight 0312 44C 15003 - C45CW Manuel utilisateur

White Knight

White Knight C38AW-S Manuel utilisateur

White Knight

White Knight 93AW Manuel utilisateur

White Knight

White Knight CL447 SERIES Manuel utilisateur

White Knight

White Knight 437 Manuel utilisateur

White Knight

White Knight 44AS Manuel utilisateur

White Knight

White Knight 76AS Manuel utilisateur

White Knight

White Knight 44A7S Manuel utilisateur

White Knight

White Knight 42AW Manuel utilisateur

White Knight

White Knight C8317 Manuel utilisateur

White Knight

White Knight TUMBLE DRYERS Manuel utilisateur

White Knight

White Knight CL372 Manuel utilisateur

White Knight

White Knight C44A7WL Manuel utilisateur

White Knight

White Knight 44AW Manuel utilisateur

White Knight

White Knight 0312 427 15310 Manuel utilisateur

White Knight

White Knight 72AW Manuel utilisateur

White Knight

White Knight 0312 727 15003 - 727c Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
