INSTRUCTIONS FOR USE

C8317 INTEGRATED

TUMBLE DRYER

IMPORTANT: PLEASE READ THESE

INSTRUCTIONS THOROUGHLY BEFORE USING

THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR

FUTURE REFERENCE.

IMPORTANT USER INFORMATION

These notes are provided in the interest of safety. You

must read them carefully before installing or using this

appliance.

- This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use

of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning

and user maintenance shall not be made by children without

supervision responsible for their safety. Children of less than 3

years should be kept away unless continuously supervised.

- This tumble dryer is intended for domestic use only.

- The room must be adequately ventilated to avoid back flow

of gases into the room from appliances burning gas or any

other fuels. This includes open fires.

- Exhaust air must not be discharged into a flue which is used

for exhausting fumes from appliances burning gas or any other

fuels.

- Any electrical work required to install the appliance should

be carried out by a qualified person.

- This tumble dryer should be serviced by an appointed service

organization and only genuine spare parts used.

- It is dangerous to alter or modify the product in any way,

other than fitting authorized accessories.

- The tumble dryer is not to be used if industrial chemicals

have been used for cleaning.

- The appliance must not be installed behind a lockable door, a

sliding door or a door with a hinge on the opposite side to that

of the tumble dryer, in such a way that a full opening of the

tumble dryer door is restricted.

- Lint must not be allowed to accumulate around the tumble

dryer.

- It is important to clean the lint filter after each drying cycle.

- Under no circumstances should anything other than the

recommended articles be placed in the tumble dryer.

- Items that have been soiled with substances such as cooking

oil, acetone, alcohol, petrol, kerosene, spot removers,

turpentine, waxes and wax removers should be washed in hot

water with an extra amount of detergent before being dried in

the tumble dryer.

- Do not place articles which have been in contact with dry

cleaning fluid or other flammable substances in the tumble

dryer.

- Do not attempt to dry dripping wet articles.

- Remove all objects from pockets such as lighters and

matches.

- Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes or

pillows fitted with foam rubber pads should not be dried in the

tumble dryer.

- Do not use the tumble dryer if you suspect that it is damaged

in any way.

Under no circumstances should you attempt to repair the

appliance yourself. Repairs carried out by inexperienced

persons may cause serious injury.

- We recommend that the appliance is switched off each time

after use. It should be disconnected from the electricity supply

if it is to be unattended for long periods, ( i.e. weekends or

holiday etc).

- DO NOT use a two-way or multi-way adapter, or

extension lead. The dryer must be connected to its own

individual socket.

- The special mains cable and plug assembly must be replaced

with a genuine part from the manufacturer or his service agent.

- When installing, position the appliance so that that the plug

is accessible.

- Fabric softeners, or similar products, should be used as

specified by the fabric softener instructions.

WARNING: The appliance must not be supplied through an

external switching device, such as a timer, or connected to a

circuit that is regularly switched on and off by a utility.

NOT SUITABLE FOR USE WITH CONDENSING BOXES

INSTALLATION

The tumble dryer is fully compatible with any 600mm deep kitchen units and complies with stringent EEC

regulations.

Your dryer is provided with a vent hose which will extend to approx 2.4m (8ft). We strongly recommend that this

is vented through the wall with the attachment provided. The position of the hole (100mm diameter) for the vent

directly behind the tumble dryer is shown in the diagram.

If the through the wall vent is to be positioned other than behind the dryer, the vent hose should be positioned at

floor level and through adjacent side panel to a relevant position. The plinth must be cut-out to accommodate the

air vent grill at the bottom front of the tumble dryer.

IMPORTANT

The air vent at the front of the appliance must never be covered or blocked in any way as this will cause the dryer

to overheat.

The dryer should not be placed directly next to ovens or cookers, as the performance of the dryer may be affected.

ELECTRICAL CONNECTIONS: We strongly recommend that any electrical work is carried out by a qualified

person complying with the IEE 17th addition of the electrical regulations.

IMPORTANT

Please remember that the tumble dryer must be capable of being switched off, (disconnected from the supply),

when fitted in position

THE FILTER

The filter is found, as seen from the diagram, by opening the door and must always be in position when drying

items in the appliance. To allow the dryer to operate efficiently it should be cleaned after each drying cycle. Do

not be alarmed by the amount of fluff deposited on the mesh. It is not due to excessive wear caused by the dryer

but more an indication of it’s efficient operation. All fabric loses fluff when drying but it goes unnoticed into the

air. In a tumble dryer it simply collects in the filter.

CONTROL PANEL GUIDE

1. PROGRAMME SELECTOR: Choose the final dryness of the load by selecting the desired dryness setting (see

the programme chart). The dryer will stop automatically when the chosen

dryness is achieved. Note: the use of an iron dry programme will use 30% less

energy than a cupboard dry programme.

2. HEAT SETTINGS: High – For fabrics insensitive to higher temperatures, such as cotton.

Low – For temperature sensitive clothes.

3. START BUTTON: Press to start the drying cycle.

4. ANTI-CREASE ACTIVE When lit constantly, the neon indicates that the drying

NEON cycle is completed and clothes can be removed. To

reduce creasing of clothes, anti-crease will

automatically start once the drying cycle is complete.

PROGRAMME DESCRIPTIONS

1. extra dry 5. iron dry

2. cupboard dry 6. damp dry

3. mid dry 7. timed dry

4. extra iron dry 8. 30 mins airing

Program 1 – Extra dry: clothes are dry enough to be put away

Program 2 – Cupboard dry: clothes are dry enough to be put away

Program 3 – Mid dry: depending upon fabric, clothes are generally dry enough to be put away

Program 4 – Extra iron dry: clothes are almost dry but can be easily ironed

Program 5 – Iron dry: clothes are slightly damp and ready to be ironed

Program 6 – Damp dry: clothes are damp and ready to be ironed

Program 7 – 30 minute timed drying program

Program 8 – 30 minute timed ‘airing’ program; useful for freshening up clothing.

Programs 1-7 can be operated on either full heat or half heat setting and have a 12 minute cool-down period at the

end of the cycle

Program 8 operates without the heater (regardless of the heat switch setting), circulating air through the dryer at the

ambient temperature.

PLEASE NOTE: THE DRYER WILL CONTINUE TO RUN IN ANTI-CREASE

MODE UNTIL THE DOOR IS OPENED.

BEFORE DRYING

Check care labels inside the garments

CARE LABELS YOU

MAY FIND ON YOUR FABRICS

Do not tumble dry woolen or wool mixture articles unless the article is labeled to be suitable due to possibility of

shrinkage.

Place delicate articles, e.g. tights and scarves, inside a pillowcase.

Sort out the clothes into groups of similar fabrics and colours.

Check the care label inside the garment.

We suggest that a fabric conditioner be used to reduce static electricity.

Delicate articles e.g. tights should be placed inside a pillowcase.

It is better to dry small and large articles together.

Do not dry unwashed items in the tumble dryer.

Remove all objects from pockets such as lighters and matches.

To avoid the need to iron easy care polyester/cotton items it is better to only dry small loads (i.e. half fill the drum).

It is better to dry small and large articles together.

Do not overload the dryer or dry large bulky items such as duvets or sleeping bags as it is important that the air

flow through the dryer is not obstructed.

RUNNING THE MACHINE

Open the door.

Load clothes loosely into the drum.

Load sheets first starting with one corner.

Close the door.

Dry your hands

Switch on the machine at the socket.

Select correct heat position (See programme chart on facia panel).

For energy labeling purposes (EN61121:2005) for a cotton dry load, use the maximum load weight for cotton and

set the timer to the recommended drying time for cotton dry as specified on the control panel.

The standard cotton programme is suitable to dry normal wet cotton laundry. It is the most efficient programme in

terms of energy consumption for drying wet cotton laundry.

Your appliance is a reversing, small door opening. A full load will typically take 135 minutes and will use

approximately 4.39kWh of electricity. A half load will typically take 76 minutes and will use approximately 2.38

kWh of electricity.

The power consumption of the off-mode and the left-on mode is zero.

Set the programme to the required dryness setting (See programme chart on facia panel).

Press the start button.

The drum will rotate in anticlockwise direction for a short period of time.

The drum will then begin to rotate clockwise and will stop automatically when your clothes are dry. The drum will

stop and rotate anti-clockwise every few minutes to reduce creasing.

There is an automatic 12-minutes cool down period at the end of every cycle, during which the heater is switched

off. This is to help minimize creasing.

The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are left at a

temperature that ensures that the items will not be damaged.

After each of the programmes, the machine goes into anti-crease. This feature rotates the drum for briefly every 6

minutes until the dryer is stopped or the door is opened.

NOTE: NEVER SWITCH THE DRYER OFF AND LEAVE A HOT LOAD IN THE DRUM – RISK OF FIRE.

When drying large items such as sheets, we suggest you periodically stop the dryer to redistribute the load, and

restart it immediately afterwards.

To stop the machine during a programme, simply open the door, the drum will stop rotating automatically and

restart when you close the door. Press the start button to restart the machine.

WARNING: Never stop a tumble dryer before the end of a drying cycle unless all items are quickly removed and

spread out so that heat is dissipated.

AFTER REMOVING THE DRIED CLOTHES: ALWAYS CLEAN THE FILTER.

Failure to clean the filter will extend drying times and cause the safety cut-out to operate.

Pull the filter upwards and away from the appliance.

Remove threads or fluff by hand or with a soft brush.

Slide the filter back.

Wash the filter occasionally in detergent solution and with a soft brush to remove small particles.

CUSTOMER ADVICE – BEFORE CALLING FOR ASSISTANCE

If the clothes are not dry after normal drying time:

–Check that you used the correct heat setting.

–Check that you have not set the timer within a cool down period.

–Check that the lint filter has been cleaned. A blocked filter will restrict the airflow.

–Check that your dryer is heating - below the door to the left side, should feel warm to the touch after the first 10-

15 minutes of its programme.

Failure to heat may indicate the safety cut-out has operated. To reset, simply press the red button at the rear of the

machine. If it has operated then a sharp “click” will be heard.

This cut-out only operates if the airflow is severely restricted so make sure the filter is clean, the air inlets and

outlets at the side and back are not blocked, and that all other restrictions are removed before re-starting.

If the cut-out continues to operate after checking the above points, you should contact your service agent.

Check that the machine has the correct weight load in the drum before starting the appliance.

If your machine does not work check the following before calling a service engineer:-

- Check that there is a supply of electricity.

- Check that the door has been properly closed and the machine is switched on.

- Check the fuse in the moulded plug.

A call out charge will be applied for a service visit, if the call could have been

avoided by following these instructions.

ESSENTIAL CONTACT INFORMATION FOR “IN GUARANTEE” AND

“OUT OF GUARANTEE” REPAIRS.

If problems continue after checking the above points you should contact our service

agent. Please ensure that you have your serial number and model number to hand

when you make the call. To locate the serial number on your dryer, open the door and

look for a white label inside the door opening. This will indicate the appliance model

number along with the serial number.

APPROVED SERVICE AGENTS: UK & SOUTHERN IRELAND

Call White Knight ON 0800 988 1323 (calls are free from landlines however calls from mobiles may be charged at

your network provider’s rates) OR 0344 8797422 (Calls charged at basic rate.)

APPROVED SERVICE AGENT: NORTHERN IRELAND

Call: Service Network 2000 ON 028 90365222 (Daytime calls cost up to 17p plus 10.5p per minute from BT lines

Monday-Friday. Mobile and other providers’ charges may vary).

Room temperature range 5˚C to 30˚C. (Drying performance decreases as room temperature falls).

Your washing machine should have a spin speed of not less than 1000rpm for maximum efficiency.

DOOR REVERSAL

APPLIANCE DOOR

The door on the dryer can be positioned either with the left or right hand hinging.

Please follow illustrations below to change the door position.

THE DECOR DOOR

The hinges can be fastened through the pre-drilled holes on either the left or right hand with the door stops being

fitted on the other side.

TECHNICAL DATA

Overall dimensions : height 86.5 – 89cm width 59.5cm depth 53cm

Maximum dry weight of cotton, linen 7.0kg synthetics 7.0kg.

For electrical ratings see plate on rear of machine.

Fuse rating: 13amp.

DON’TS….

Do not – Overload the dryer.

Do not – Dry articles singly as they tend to roll up and so increase drying time.

Do not – Dry woolen or wool mixture articles unless the article is labeled as suitable. This should avoid shrinkage.

Do not – Allow venting hose (where applicable) or filter to become blocked.

Do not – Allow fluff to accumulate around the tumble dryer.

NEVER SWITCH THE DRYER OFF AND LEAVE A HOT LOAD IN THE DRUM – RISK OF FIRE.

ANY PROBLEMS

If the clothes are not dry after normal drying time:

- Check that the filter is clean.

- Check that you used the correct heat setting.

- Check that the venting hose is not blocked (sometimes a strong wind may cause a back

pressure).

- Check that you have not set the timer within a cool down period.

This appliance is marked according to the European Directive

2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).

This guideline is the frame of a Europen wide validity of return and

Recycling on Waste Electrical and Electronic Equipment

Table des matières

Autres manuels White Knight Séchoir

White Knight

White Knight C38AW Manuel utilisateur

White Knight

White Knight 28007T Manuel utilisateur

White Knight

White Knight B96M8W Manuel utilisateur

White Knight

White Knight B96G8W Manuel utilisateur

White Knight

White Knight SV847 Manuel utilisateur

White Knight

White Knight BG 43A Guide rapide

White Knight

White Knight 44AW Manuel utilisateur

White Knight

White Knight 0312 44C 15003 - C45CW Manuel utilisateur

White Knight

White Knight CL42 Manuel utilisateur

White Knight

White Knight 28007 T Manuel utilisateur

White Knight

White Knight TUMBLE DRYERS Manuel utilisateur

White Knight

White Knight 44AW Manuel utilisateur

White Knight

White Knight C36AW Manuel utilisateur

White Knight

White Knight B96G8W Manuel utilisateur

White Knight

White Knight 831 WV Manuel utilisateur

White Knight

White Knight 0312 83A 15100 Manuel utilisateur

White Knight

White Knight 0312 44C 15001 - C45CWUK Manuel utilisateur

White Knight

White Knight 767c - 0312 767 15009 Manuel utilisateur

White Knight

White Knight C44A7WL Manuel utilisateur

White Knight

White Knight 0312 85A 15000 - 85AW Manuel utilisateur

White Knight

White Knight ECO 43A Manuel utilisateur

White Knight

White Knight CL447 SERIES Manuel utilisateur

White Knight

White Knight 72AW Manuel utilisateur

White Knight

White Knight eco 86A Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
