Westinghouse LTV-20V2 Instructions de montage

POWER INDICATOR

KEYPAD CONNECTION PANEL

CONGRATULATIONS on pur-

chasing a state of the art LCD

TV! This Quick Connect Guide

will help you get started in 3

easy steps. On the back you will

find information to maximize

your LCD TV experience. For

complete installation, usage

instructions, and safety precau-

tions please refer to the User’s

Manual.

20”

QUICK

CONNECT

GUIDE

CONNECT THE

POWER

Remove the dust cover for

the connection panel on the

back of the LCD. Use the

enclosed A/C power cable

to connect A/C power to the

back of the LCD TV.

CONNECT THE

TUNER

Connect either analog cable

or TV antenna wire to the

cable ready NTSC tuner input

labeled “TV” on the connec-

tion panel.

Note: this step can be

skipped if you do not use

these options.

CONNECT A DVD

PLAYER

Connect a DVD player to the

component YPbPr input (Red,

Green, Blue) and the corre-

sponding component audio

inputs labeled “Audio In”

located on the connection

panel.

Press Power on the key-

pad to turn on the LCD.

The power indicator on

the front panel of the LCD

glows blue.

123GO!

www.westinghousedigital.com

REMOVABLE STAND FOR OPTIONAL WALL MOUNTING

LTV-20v2 LCD TV

Digital Cable/

Satellite Receiver Good Better Best

DVD Player Good Better Best

Game Console Good Better Best

VCR Good Better Best

YPbPr

AV S-VideoTV Tuner

VIDEO INPUTS

MAXIMIZE

YOUR LCD TV

EXPERIENCE

You can attach your LCD TV to

a variety of electronic devices

including a digital cable or

satellite set top box, a game

console, or a VCR. The chart

shows our recommendations

for the best quality picture for

these commonly used devices.

If you have trouble connecting

these or other devices, please

refer to the User’s Manual.

Audio In 2

(R/L)

Audio In 1

(R/L)

YPbPr

Video In

(Component)

S-Video In

Service Port

TYPICAL SETUP

•Progressive scan DVD players with YPbPr

•Game console action using AV

•VCR viewing and editing with S-Video

DID YOU KNOW THAT

YOUR LCD TV ALSO HAS:

• Picture-in-Picture

• Favorite channel memory

CHECK OUT

www.westinghousedigital.com for our:

• Versatile Wall Mounting options

reserved. Specifications subject to change without notice.

, and are

trademarks of Westinghouse Electric Corporation and are used

under license.

MA-PS-0107-0401 www.westinghousedigital.com

Use the Source

button on the remote

control or keypad to

cycle between the

TV, S-Video, AV, or

YPbPr.

AV In

Note: The audio input is shared between AV and S-Video.

A/C In

(Power)
