WD Red is the only hard drive designed for NAS systems

that have 1-5 drive bays. The drives are designed and

extensively tested for compatibility in the unique 24x7

operating environment and demanding system requirements

of home and small office NAS.

INTERFACE

SATA 6 Gb/s

WIDTH/HEIGHT

3.5-inch/1-inch

ROTATIONAL SPEED

IntelliPower™

CAPACITIES

1 TB to 3 TB

MODEL NUMBERS

WD30EFRX

WD20EFRX

WD10EFRX

Note: Not all products may be

available in all regions of the world.

Product Features

NAS compatibility

WD eliminates the confusion.

WD Red is the only hard drive

designed for NAS systems that

have 1 to 5 drive bays. The drives

are designed and extensively tested

for compatibility in the unique 24x7

operating environment and

demanding system requirements of

home and small business NAS.

Enhanced reliability

With a 35% MTBF improvement

over standard desktop drives, the

WD Red drive is designed and

manufactured to be a more reliable

and robust solution.

The secret is in the

technology–NASware™

Advanced firmware technology built

into every WD Red drive, enables

seamless integration, robust data

protection and optimal performance

for systems operating in NAS and

RAID environments.

Energy efficient

Innovative technology reduces

power consumption and lowers the

operating temperature, resulting in a

more reliable and affordable solution

for always on 24x7 NAS

environments.

3D Active Balance Plus

Our enhanced dual-plane balance

control technology significantly

improves the overall drive

performance and reliability. Hard

drives that are not properly

balanced may cause excessive

vibration and noise in a multi-drive

system, reduce the hard drive life

span, and degrade the performance

over time.

Longer warranty coverage

The WD Red drive is backed by a

3-year limited warranty for greater

peace of mind.

Premium support

Exclusively for WD Red drive

customers, free dedicated 24x7

support line.*

* Support outside of normal business hours is available in

English only. Go to http://support.wdc.com for further

details.

Applications

WD Red NAS hard drives are recommended for use in home and small office 1-5 bay NAS systems. For systems that use more than 5 bays or are rack mount

solutions, please consider WD enterprise hard drives.*

* WD hard drives are designed and tested for use in specific applications and environments. This ensures that your hard drive is compatible with and functions properly in your application. Our

hard drives are warranted against defects in materials and workmanship in the system for which they were designed. Use in systems other than for what the hard drive was designed could

result in compatibility problems that affect proper function, unrelated to material and/or workmanship defects. For best results, be sure to select the appropriate product for your application

by consulting our product spec sheets on our website at www.wd.com or by calling our customer support line where we would be happy to help you through the selection process.

The WD Advantage

WD puts our products through extensive Functional Integrity Testing (F.I.T) prior to any product launch. This testing ensures our products consistently meet the

highest quality and reliability standards of the WD brand. WD also has a detailed Knowledge Base with more than 1,000 helpful articles as well as helpful software

and utilities. Our customer support lines have longer operational hours to ensure you get the help you need when you need it. Our toll-free customer support lines are

here to help or you can access our WD Support site for additional details.

WD Red™

Western Digital, WD, and the WD logo are registered trademarks in the U.S. and other countries; and

WD Blue, WD Green, WD Black, WD Red, NASware, and FIT Lab are trademarks of Western Digital

Technologies, Inc. Other marks may be mentioned herein that belong to other companies. Product

specifications subject to change without notice.

Western Digital

3355 Michelson Drive, Suite 100

Irvine, California 92612

U.S.A.

2879-771442-A02 Aug 2012

For service and literature:

http://support.wdc.com

www.wd.com

WD Red premium support

800.ASK.4WDC

(800.275.4932)

North America

800.832.4778 Spanish

+800.6008.6008 Asia Pacific

00800.27549338 Europe

(toll free where available)

+31.880062100 Europe/Middle East/Africa

855.55.WDRED

(855.559.3733)

North America

+800.55593733 Europe/Middle East/Africa

Asia Pacific

Canada ICES-003 Class B / NMB-003 Classe B

Specifications13 TB 2 TB 1 TB

Model number WD30EFRX WD20EFRX WD10EFRX

Interface SATA 6 Gb/s SATA 6 Gb/s SATA 6 Gb/s

Formatted capacity 3,000,592 MB 2,000,398 MB 1,000,204 MB

User sectors per drive 5,860,533,168 3,907,029,168 1,953,525,168

Advanced Format (AF) Yes Yes Yes

SATA latching connector Yes Yes Yes

Form factor 3.5-inch 3.5-inch 3.5-inch

RoHS compliant2Yes Yes Yes

Performance

Data transfer rate

Buffer to host (max)

Host to/from drive (typical)

6 Gb/s

145 MB/s

6 Gb/s

145 MB/s

6 Gb/s

150 MB/s

Cache (MB) 64 64 64

Rotational speed (RPM)3IntelliPower IntelliPower IntelliPower

Reliability/Data Integrity

Load/unload cycles4600,000 600,000 600,000

Non-recoverable read errors

per bits read

<1 in 1014 <1 in 1014 <1 in 1014

MTBF (hours)51,000,000 1,000,000 1,000,000

Limited warranty (years)6333

Power Management

12VDC (A, peak) 1.73 1.73 1.20

Average power requirements (W)

Read/write

Idle

Standby

Sleep

4.4

4.1

0.6

4.4

4.1

0.6

3.7

3.2

0.6

Environmental Specifications7

Temperature (°C, on the base casting)

Operating

Non-operating

0 to 70

-40 to 70

0 to 70

-40 to 70

0 to 70

-40 to 70

Shock (Gs)

Operating (2 ms, read/write)

Operating (2 ms, read)

Non-operating (1 ms)

250

350

Average acoustics (dBA)8

Idle mode

Seek mode

Physical Dimensions

Height (in./mm, max) 1.028/26.1 1.028/26.1 1.028/26.1

Length (in./mm, max) 5.787/147 5.787/147 5.787/147

Width (in./mm, ± .01 in.) 4/101.6 4/101.6 4/101.6

Weight (lb./kg, ± 10%) 1.40/0.64 1.32/0.60 0.99/0.45

1As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576

bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabit per second (Gb/s) = one billion bits per second. Effective maximum SATA 6 Gb/s transfer rate calculated according to the Serial ATA specification published by the SATA-

IO organization as of the date of this specification sheet. Visit www.sata-io.org for details.

2WD hard drive products manufactured and sold worldwide after June 1, 2006, meet or exceed Restriction of Hazardous Substances (RoHS) compliance requirements as mandated by the RoHS Directive 2011/65/EU.

3A fine-tuned balance of spin speed, transfer rate and caching algorithms designed to deliver both significant power savings and solid performance. For each drive model, WD may use a different, invariable RPM.

4Controlled unload at ambient condition.

5Based on a typical NAS product environment under normal operating conditions.

6The term of the limited warranty may vary by region. Visit http://support.wdc.com/warranty for details.

7No non-recoverable errors during operating tests or after non-operating tests.

8Sound power level.

WD Blue™

Desktop Hard Drives

for everyday computing.

WD Green™

Desktop Hard Drives

for energy efficient applications.

WD Black™

Desktop Hard Drives

.for performance users

WD Red™

NAS Hard Drives

for home and small office NAS systems.

WD Red is part of WD’s complete lineup of internal hard drives.

Learn more about WD Red hard drives
