Western Digital OpenFlex Data24 DCS0010 Manuel utilisateur

EcoDesign

Disclosures

OpenFlex™ Data24

Regulatory Model: DCS0010

1ET2362

Version 1.0

December 2020

EcoDesign Disclosures Table of Contents

Table of Contents

Revision History......................................................................................................................................ii

Notices................................................................................................................................................... iii

Chapter 1. EU EcoDesign Disclosures............................................................................ 1

EcoDesign Overview............................................................................................................................2

OpenFlex Data24 EcoDesign Specifications...................................................................................... 2

Secure Erasing a Storage Device....................................................................................................... 2

Chassis Disassembly............................................................................................................................ 3

IO Module (IOM) Disassembly........................................................................................................... 27

EcoDesign Disclosures Revision History

Revision History

Date Revision Comment

November 2020 1.0 Initial release

EcoDesign Disclosures Notices

Notices

Western Digital Technologies, Inc. or its affiliates' (collectively “Western Digital”) general policy does not

recommend the use of its products in life support applications wherein a failure or malfunction of the product

may directly threaten life or injury. Per Western Digital Terms and Conditions of Sale, the user of Western

Digital products in life support applications assumes all risk of such use and indemnifies Western Digital

against all damages.

This document is for information use only and is subject to change without prior notice. Western Digital

assumes no responsibility for any errors that may appear in this document, nor for incidental or consequential

damages resulting from the furnishing, performance or use of this material.

Absent a written agreement signed by Western Digital or its authorized representative to the contrary,

Western Digital explicitly disclaims any express and implied warranties and indemnities of any kind that may,

or could, be associated with this document and related material, and any user of this document or related

material agrees to such disclaimer as a precondition to receipt and usage hereof.

Each user of this document or any product referred to herein expressly waives all guaranties and warranties

of any kind associated with this document any related materials or such product, whether expressed or

implied, including without limitation, any implied warranty of merchantability or fitness for a particular

purpose or non-infringement. Each user of this document or any product referred to herein also expressly

agrees Western Digital shall not be liable for any incidental, punitive, indirect, special, or consequential

damages, including without limitation physical injury or death, property damage, lost data, loss of profits or

costs of procurement of substitute goods, technology, or services, arising out of or related to this document,

any related materials or any product referred to herein, regardless of whether such damages are based on

tort, warranty, contract, or any other legal theory, even if advised of the possibility of such damages.

This document and its contents, including diagrams, schematics, methodology, work product, and

intellectual property rights described in, associated with, or implied by this document, are the sole and

exclusive property of Western Digital. No intellectual property license, express or implied, is granted by

Western Digital associated with the document recipient's receipt, access and/or use of this document or the

products referred to herein; Western Digital retains all rights hereto.

Western Digital, the Western Digital logo, and OpenFlex are registered trademarks or trademarks of Western

Digital Corporation or its affiliates in the US and/or other countries. Linux® is the registered trademark of

Linus Torvalds in the U.S. and other countries. The NVMe and NVMe-oF word marks are trademarks of NVM

Express, Inc. All other marks are the property of their respective owners. Product specifications subject to

change without notice. Pictures shown may vary from actual products. Not all products are available in all

regions of the world.

Western Digital

5601 Great Oaks Parkway

San Jose, CA 95119

iii

Western Digital

EU EcoDesign

Disclosures

This document provides information and instructions related

to the OpenFlex Data24's disclosures for the EU's ecodesign

requirements.

In This Chapter:

- EcoDesign Overview......................................2

- OpenFlex Data24 EcoDesign

Specifications...................................................2

- Secure Erasing a Storage Device..................2

- Chassis Disassembly.......................................3

- IO Module (IOM) Disassembly..................... 27

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.1 EcoDesign Overview

This document provides information about the OpenFlex Data24 related to its manufacturing and operation,

and instructions for secure data deletion and disassembly.

1.2 OpenFlex Data24 EcoDesign Specifications

Product Type Online Data Storage Product

Manufacturer's Name Western Digital

Manufacturer's Registered Trade Name Western Digital®

Manufacturer's Registered Trade Address 5601 Great Oaks Parkway

San Jose, CA 95119

USA

Product Model Number DCS0010

Starting Year of Manufacture 20201

PSU efficiency at 20%, 50%, 100%

of rated output power

20% load = 93.01%

50% load = 94.31%

100% load = 92.02%

Power Factor at 50% Rated Load Level Minimum Power Factor (at 50%) = 1.0

Declared Operating Condition Class A2

Neodymium Content in HDDs N/A

Cobalt Content in Batteries N/A

1.3 Secure Erasing a Storage Device

This task provides instructions for performing a Secure Erase on an OpenFlex Data24 storage device using

NVMe-CLI.

Before you begin: The Secure Erase feature provides the following options for securely erasing the storage

device:

•No Secure Erase – initializes the number of storage pools on the device

•User Data Secure Erase – deletes the mapping table and all user content present on the device

•Crypto Secure Erase – deletes the encryption key, making the data unrecoverable

This procedure assumes prior knowledge of the device names that will be deleted.

Step 1 : From a terminal, use NVMe-CLI to issue a format command to the target drive. Use the --ses

command modifier with a value set to 2 (crypto secure erase).

nvme format /dev/<device ID> --namespace-id=1 --ses=2

1. This value is the original date of product manufacture. For the specific manufacture date of your platform, check the

agency label attached to the platform. There will be a 4 digit date code on that label.

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.4 Chassis Disassembly

Note: Crypto Secure Erase may not be available on all drives.

Step 2 : Verify data cannot be accessed by attempting reads to the drive. The data that exists on the

drive will no longer be accessible, because the encryption key has been deleted.

1.4 Chassis Disassembly

This procedure provides instructions for disassembling an OpenFlex Data24 Chassis.

Table 1: Replacement Procedure Info

Required Tools # of People Required

•T7 Torx screwdriver

•T8 Torx screwdriver

•T10 Torx screwdriver

•Tweezers or needle-nose pliers

(recommended)

•2 for removal of the Chassis from the rack

•1 for the disassembly of the Chassis

Step 1 : Follow the instructions for removing the enclosure from the rack (see the Chassis Disassembly

section of the OpenFlex Data24 User Guide).

Step 2 : Place the OpenFlex Data24 on an ESD-safe work surface, and ensure ESD safety equipment is

installed and working properly.

Step 3 : Uninstall the Drive Assemblies.

a. At the front of the enclosure, press the release button on the front of a Drive Assembly. The

release handle will rotate outward:

Figure 1: Drive Assembly Release Button and Handle Operation

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.4 Chassis Disassembly

b. Pull down slightly on the release handle to unseat the Drive Assembly. Then pull the handle

to remove the Drive Assembly from the enclosure:

Figure 2: Drive Assembly Removal

c. Repeat these steps to remove the remaining Drive Assemblies.

Step 4 : Uninstall the Power Supply Units (PSUs).

a. At the rear of the enclosure, grasp the ring handle of a Power Supply Unit (PSU) with your

index finger, and use your thumb to press the latch release with a pinching motion:

Figure 3: Power Supply Unit (PSU) Release Latch Operation

b. Pull the Power Supply Unit (PSU) out of its slot:

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.4 Chassis Disassembly

Figure 4: Power Supply Unit (PSU) Removal

c. Repeat these steps to remove the remaining Power Supply Unit (PSU).

Step 5 : Uninstall the IO Modules (IOMs).

a. Unlock an IO Module (IOM) by turning its thumbscrew counterclockwise until the threads are

disengaged. The location of the thumbscrew is shown in the following image:

Figure 5: IO Module (IOM) Thumbscrew Operation

b. Pull the release handle down until the IO Module (IOM) is unseated from its slot:

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.4 Chassis Disassembly

Figure 6: IO Module (IOM) Release Handle Operation

c. Use the handle to pull the IO Module (IOM) out of the enclosure:

Figure 7: IO Module (IOM) Removal

d. Repeat these steps to remove the remaining IO Module (IOM).

Step 6 : Remove the rear chassis cover.

a. Using a T7 Torx screwdriver, remove the sixteen (16) screws securing the rear chassis cover:
