Welldana DRYDEN AQUA SPACE Manuel utilisateur

1| Page Instructions for use [short]

SPACE

www.drydenaqua.com

Installation guide

2| Page Instructions for use [short]

SPACE

www.drydenaqua.com

SECTION 1 INSTALLATION GUIDE

1.0 USING AND SETTINGS.................................................................................................................. 3

2.0 MENUS ..................................................................................................................................... 4

3.0 MANUAL CONTROL ..................................................................................................................... 5

4.0 FILTRATION MODES .................................................................................................................... 6

5.0 AUXILIARIES .............................................................................................................................. 7

6.0 WATER AND TREATMENT........................................................................................................... 11

7.0 MAINTENANCE......................................................................................................................... 12

8.0 CONFIGURATION ...................................................................................................................... 13

9.0 SPACE CLOUD......................................................................................................................... 14

10.0 CIRCULATION MODE (WITH AUTOMATIC SUCTION VALVE)..............................................................14

Section 2 PROGRAMMING GUIDE

4.1 FILTRATION MODES MENU ......................................................................................................... 15

5.1 AUXILIARIES MENU ............................................................................................................. 16

6.0 WATER AND TREATMENT ................................................................................................... 18

6.1 WATER LEVEL CONTROL ......................................................................................................... 18

6.2 PHCONTROL ........................................................................................................................... 22

6.3 ORP CONTROL ........................................................................................................................ 23

6.4 REMNANT INJECTION (H2O2) .................................................................................................... 24

6.5 ACO INJECTION ................................................................................................................... 25

6.6 FREE CHLORINE PROBE CONFIGURATION .........................................................................26

7.0 MAINTENANCE .................................................................................................................... 27

7.1 MAINTENANCE TOOLS ...................................................................................................................

7.2 pH, Free chlorine, Conductivity Calibration...........................................................................

7.3 SENSORS REPLACEMENT ...............................................................................................................

8.0 CONFIGURATION MENU ..................................................................................................... 32

8.1 Pool data .............................................................................................................................. 32

8.2 Pump configuration............................................................................................................. 33

8.3 Filter data ............................................................................................................................. 35

8.4 CONFIGURING INPUTS ........................................................................................................ 37

8.5 FACTORY SETTINGS............................................................................................................. 39

8.6 EQUIPMENT.......................................................................................................................... 40

8.6.1 POOL COVER ........................................................................................................................ 40

8.6.2 JETSTREAM........................................................................................................................... 41

9.0 SPACE Cloud......................................................................................................................... 42

10.0 CIRCULATION MODE (WITH AUTOMATIC SUCTION VALVE).............................................44

11.0 SCHEMATIC DIAGRAMS FOR SKIMMER &OVERFLOW POOLS………………………………….46

3| Page Instructions for use [short]

SPACE

www.drydenaqua.com

1. Using and settings

BACKLIGHT

Pressing any button illuminates the backlight.

The backlight remains on for 3 minutes.

12:46:01 01/06/2014

Valve

Filter

Pump STOP

0.00

Bar

Water Temp

°C

Level

Normal

7.2

ORP

690mV

Navigate the SPACE menu

Press the MENU button.

SPACE MENU is displayed.

Use the UP and DOWN buttons to choose

the submenu (in this case Manual

Control), then press SELECT to go to that

submenu.

Repeatedly pressing QUIT to return to the

main display.

SPACE MENU

Manual control

Filtration modes

Auxiliaries

Water and Treatment

Maintenance

Configuration

SELECT

QUIT

Return to Main Display

When viewing any menu screen:

Press QUIT to go up one menu level.

Every display has a 15 second timeout to

go back to the previous menu. The

display will timeout to the main

display within approximately 1

minute.

SPACE MENU

Manual control

Filtration modes

Auxiliary

Water and treatment

Maintenance

Configuration

SELECT

QUIT

4| Page Instructions for use [short]

SPACE

www.drydenaqua.com

2. Menus

QUIT

DOWN

MENU / SELECT

Manual Control

Filtration Modes

Auxiliaries

Water and

Treatment

Maintenance

Configuration

SPACE Cloud

Circulation Modes

More information

see Page 5

More information

see Page 6

More information

see Page 7 - 10

More information

see Page 11

More information

see Page 12

More information

see Page 13

More information

see Page 14

More information

see Page 14

5| Page Instructions for use [short]

SPACE

www.drydenaqua.com

3. Manual control:

(1) Not available of Filtration set in NOPUMP Mode

(2) Not available when cleaning valve is not configured

(3) Not available when rinse valve is not configured

Manually switch the pump ON or OFF at any time (if

no freeze conditions).

The programmed pump speed can be changed

manually for the rest of the filtration cycle.

Programmed speed will revert for the next cycle

APPLICABLE TO VARIABLE SPEED PUMP TYPE.

Manually switch auxiliary equipment ON or OFF at

any time

Manual Control

Pump (1)

Switch Pump

ON or OFF

Change

Pump Speed

Auxiliaries Switch

ON or OFF

Level Adjust Get water level

Clean Filter (2) Command Cleaning

Cycle

Valve Position (2)

Filter

Backwash

Rinse

Equipment Command Equipement

Ask for water level update which can lead to water

refill or a level reduction. Will stop refilling when

refill in ON.

APPLICABLE IF LEVEL CONTROL

Carries out a cleaning cycle (backwash) at any time.

Manually sets the valve to RINSE position at any

time.

Manually sets the valve to FILTER position at any

time.

Manually sets the valve to BACKWASH position at

any time

Manually command equipment such as Pool Cover

or JetStream pump

6| Page Instructions for use [short]

SPACE

www.drydenaqua.com

4. Filtration modes :

Filtration Modes

Stopped

Cycle1 =00:00-

00:00

Cycle2 =00:00-

00:00

Timer

Cycle1 =xx:xx-xx:xx

Cycle2 =xx:xx-xx:xx

ECO+

Cycle1 =xx:xx-xx:xx

Cycle2 =xx:xx-

CALC

Volume

Cycle1 =xx:xx-xx:xx

Cycle2 =xx:xx-

CALC

Continuous

Cycle1 =xx:xx-

CALC

Cycle2 =CALC-

CALC

Force 24H

Cycle1 =CALC-

CALC

Cycle2 =xx:xx-

yy:yy

Force 48H

Cycle1 =CALC-

CALC

Cycle2 =xx:xx-

yy:yy

Force 72H

Cycle1 =CALC-

CALC

Cycle2 =xx:xx-

yy:yy

24/24

Cycle1 =00:00-

00:00 V1

Cycle2 =00:00-

00:00 - V2

NO PUMP

Filtration is stopped. Both Cycle1 and Cycle2 timers are set to

00:00-00:00.

Filtration will run 23 hours per day for 24 hours and then revert

to normal filtration times. Cycle1 timer settings will be changed

when entering the forced mode and restored at the end of

period.

Cycle1 is free to be set at any value you may choose.

Choose Cycle2 start time, duration is calculated in accordance

with pool needs based on turnovers. Cycle1 duration is taken into

account.

Filtration will run 23 hours per day for 48 hours and revert to

normal filtration times. Cycle1 timer settings will be changed

when entering the forced mode and restored at the end of

period.

Pump is not controlled by SPACE. When the pump is detected as

running features will function automatically.

Pump is controlled and will run continuously except if priming is

lost.

The pH will be read once every hour.

Waterlevel every 20 minutes

Cycle1 is free to be set at any value you may choose.

Choose Cycle2 start time, duration is calculated in accordance

with pool needs based on temperature. Cycle1 duration is taken

into account.

Choose Cycle1 start time. Cycle1 and Cycle2 duration are

11:30min fixed value allowing a 23 hour per day filtration

duration.

Cycle1 and Cycle2 are free to be set at any value you may choose.

Make sure there is at least 30 min break between Cycle1 and

Cycle2.

Filtration will run 23 hours per day for 72 hours and then revert

to normal filtration times. Cycle1 timer settings will be changed

when entering the forced mode and restored at the end of

period.

See page 15

7| Page Instructions for use [short]

SPACE

www.drydenaqua.com

5. Auxiliaries

SPACE DCCU

Auxiliaries

Aux 1

Mode

OFF/Dur

Slave

Day of Week

Speed Ctrl

Aux 2

See Aux1

Speed Ctrl

Aux 3

See Aux1

Speed Ctrl

Aux 4

See Aux1

Suction valve

Aux 5

Besgo valve

Backwash

Aux 6

See Aux1

ORP

AUX 2 functionality is the same as AUX 1

If SPACE controls a multi-speed pump, AUX 2 is not available

(is reserved for speed 2)

See, Configuration - Filter data – (backwash setting)

(is reserved for the backwash valve)

See, Configuration – ORP regulation

(is reserved for ORP regulation)

Set ID

Set Mode

Set ON time HH:MM in timer and pulse modes

Set OFF time HH:MM in timer mode, or duration in pulse mode

Slave AUX to filtration; the auxiliary will only be ON if the pump is

primed

Set AUX to operate on selected days of the week

If SPACE controls a multi-speed pump, AUX 1 is not available.

PUMP

See, Configuration – pH regulation

(is reserved for pH regulation)

AUX 3 functionality is the same as AUX 1

If SPACE controls a multi-speed pump, AUX 3 is not available.

(is reserved for speed 3)

AUX 4 functionality is the same as AUX 1

If a suction valve is configured, AUX 4 is not available.

(is reserved for the Suction valve)

Aux 7

See Aux1

8| Page Instructions for use [short]

SPACE

www.drydenaqua.com

SPACE DCCU - Auxiliaries (outputs)

Output Function

Default

setting

Standard Outputs

Pump

Relay pump

Pump

Single speed pump configured by default. If a multi-speed

pump is declared in the settings, the AUX1, AUX2, AUX3

outputs are

automatically assigned to speed control;

otherwise AUX1, AUX2, AUX3 are free to use.

AUX1

Speed 1

Free

AUX2

Speed 2

Free

AUX3

Speed 3

Free

AUX4 Besgo 3-way

Suction valve

Free

If a suction valve is declared in the settings, it is

automatically assigned to Aux4, otherwise Aux4 is free to

use.

AUX5 Besgo 5-way

Backwash valve Backwash

If a backwash valve is declared in the settings it is

automatically assigned to Aux5. Otherwise, Aux5 is free to

use.

AUX6 Disinfection Disinfection

If ORP disinfection is declared in the settings, the dosage

is automatically assigned to Aux6. Otherwise Aux6 is free

to use.

AUX7

pH Minus

AUX7 is reserved in all cases.

9| Page Instructions for use [short]

SPACE

www.drydenaqua.com

Auxiliaries Extension Modules:

Auxiliaries

Aux 8

See Aux1

APF

Aux 9

See Aux1

Heating

Aux 10

See Aux1

pool Light

Aux 11

See Aux1

colour change

Aux 12

See Aux1

ACO

Aux 13

See Aux1

Jet Stream

Rince valve

Aux 14

See Aux1

Pool Cover

Aux 15

See Aux1

Pool Cover

AUX 8 functionality is the same as AUX 1

If the APF pump is configured, AUX 8 is not available.

(is reserved for APF pump)

AUX 9functionality is the same as AUX 1

If “heating”is configured, AUX 9 is not available.

(is reserved for heating)

AUX 10 functionality is the same as AUX 1

If “lighting”is configured, AUX 10 is not available.

(is reserved for Pool lighting)

AUX 11 functionality is the same as AUX 1

If “color change” is configured, AUX 11 is not available.

(is reserved for pool lights color change)

AUX 12 functionality is the same as AUX 1

If “ACO” is configured, AUX 12 is not available.

(is reserved for the ACO pump)

AUX 13 functionality is the same as AUX 1

If the Jet Stream or Rinse valve is configured, AUX 13 is not available.

(is reserved for Jet Stream or Besgo Rinsing valve)

AUX 14 functionality is the same as AUX 1

If the Pool Cover is configured, AUX 14 is not available.

(is reserved for opening the pool cover)

AUX 15 functionality is the same as AUX 1

If the Pool Cover is configured, AUX 15 is not available.

(is reserved for closing the pool cover)

10 | Page Instructions for use [short]

SPACE

www.drydenaqua.com

SPACE Extension module

AUX (outputs)

Output Function

Default

setting Comments

SPACE Extension Module

AUX8 Dosage APF APF

If APF is declared in the settings it is automatically

assigned to Aux8, otherwise Aux8 is free to use.

AUX9 Heating Heating

The heating system can be assigned to any available Aux.

It will be assigned to Aux9 by factory setting but can be

reassigned.

AUX10 Pool lights Pool lights

ON/OFF

The lights can be assigned to any available Aux. It will be

assigned to Aux10 by factory setting but can be

reassigned.

AUX11 Pool lights Colour change

The colour change can be assigned to any available Aux. It

will be assigned to Aux11 by factory setting but can be

reassigned.

AUX12 ACO ACO

If ACO dosing is declared in the settings, it is automatically

assigned to Aux12. Otherwise, Aux12 is free to use.

AUX13 Besgo 3-way

rinsing valve

Free

If a Besgo rinsing valve is declared in the settings it is

automatically assigned to Aux13, in which case Aux13 can

no longer be assigned to manage countercurrent

jetsteams.

AUX14

Pool cover

Free

AUX15

Pool cover

Free

Table des matières

Autres manuels welldana Unité de contrôle

welldana

welldana 34-150221 Manuel

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur

welldana DRYDEN AQUA SPACE Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques
