WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Pole Mounted Luminaire
ZFT400
ZAT400
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
1
Pole Mounted Luminaire
ZFT430-FT
ZFT430 ZFT460-FT
ZFT460
ZFT440-FT
ZFT440 ZFT470-FT
ZFT470
IP66. IK08/IK09. Class I. ta = 25°C
ø 76 x 80
388
260
ø 170
ø 76 x 80
448
260
ø 170
ø 250
ø 76 x 80
388
260
ø 250
ø 76 x 80
448
260
Weight kg
for ZFT430-FT/430 5.5
for ZFT440-FT/440 5.6
for ZFT460-FT/460 7.2
for ZFT470-FT/470 7.3
Tools required
– 4 mm allen key
– wire cutter
ø 9 – 14 mm 1 – 2.5 mm2
2
ZAT430-FT
ZAT430 ZAT460-FT
ZAT460
ZAT440-FT
ZAT440 ZAT470-FT
ZAT470
IP66. IK08/IK09. Class I. ta = 25°C
Weight kg
for ZAT430-FT/430 7.7/7.8
for ZAT440-FT/440 7.8/7.9
for ZAT460-FT/460 9.7/10.5
for ZAT470-FT/470 9.9/10.6
Tools required
– 4 mm allen key
– wire cutter
ø 9 – 14 mm 1 – 2.5 mm2
3
Light Source
LED
Maintenance
Apart from cleaning the product’s exterior surfaces, no special maintenance work is required.
Do not use high-pressure cleaners.
In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out
E\DVXLWDEO\TXDOLƂHGDQGWUDLQHGSURIHVVLRQDO
Warning: Do not open luminaire while mains supply is switched on.
4
Installation
The product must be installed and maintained by a
VXLWDEO\TXDOLƂHGSURIHVVLRQDOLQFRPSOLDQFHZLWKODWHVW
building/construction and/or electrical regulations and
relevant legislation.
Warning: Switch off mains electrical supply prior to
installing and connecting the luminaire.
Notice:,IWKHOXPLQDLUHLVPRGLƂHGE\DQ\ERG\RWKHU
than the original manufacturer, then the warranty will
no longer be valid and shall become the full respon-
sibility of the modifying person/organisation. Claims
based on defects attributable to improper installation
and/or application, and the consequences thereof, are
excluded.
Attention: The luminaire is factory-sealed and does
not need to be opened during installation.
The installation on site must comply with local and/or
national health and safety regulations.
5
1) Switch off mains electrical supply.
Installation Procedure
4) Trim mains cable Ato the desired length and
connect the leads to their respective terminals
at the base of the pole (L = Phase, N = Neutral,
= Earthing)
3) Feed mains cable Ainto column B, while
setting luminaire in position by following the
orientation indicator C. Tighten set screws D.
2) Check that rating shown on luminaire label
conforms with mains electrical supply.
(example)
ZFT440 220-240V/50 Hz, 1-10
115-XXXX SOE XXXXXXX
LED 4000K 18W item no. XXX
09/19 IP66
L
N
Supply cable
www.we-ef.com
WE-EF LEUCHTEN
Germany
Tel +49 5194 909 0
Fax +49 5194 909 299
info.germany@we-ef.com
WE-EF LUMIERE
France
Tel +33 4 74 99 14 44
Fax +33 4 74 99 14 40
info.france@we-ef.com
WE-EF HELVETICA
Switzerland
Tel +41 22 752 49 94
Fax +41 22 752 49 74
info.switzerland@we-ef.com
WE-EF LIGHTING
Thailand
Tel +66 2 738 9610
Fax +66 2 175 2174
LQIRDVLDSDFLƂF#ZHHIFRP
WE-EF LIGHTING
Australia
Tel +61 3 8587 0444
Fax +61 3 8587 0499
info.australia@we-ef.com
WE-EF LIGHTING
United States of America
Tel +1 724 742 0030
Fax +1 724 742 0035
info.usa@we-ef.com
TO9265W0221 © WE-EF 2021
7HFKQLFDOVSHFLƂFDWLRQVDUH
subject to change.
