Watts Tekmar 562 Manuel utilisateur

U - 10/16

562

10/16

Zoning

Replaces: New

WiFi Thermostat 562

User Manual

The WiFi Thermostat 562 provides precise temperature control of a heating and

cooling system. When connected to the Internet, the mobile app and website allow

you to control the thermostat remotely. The thermostat and mobile app include an

away feature that overrides the schedule to lower the temperature and increase

energy savings. The thermostat is designed to support radiant floor heating and

optional floor sensors can be installed to enhance comfort and protect floor coverings.

Introduction

2 of 8

U - 10/16

Home Screen

User Interface

Current time

Current temperature

Equipment operation

(Heat or Cool On)

Change operating mode

Touch or to

adjust temperatures

Select either

Heat To or Cool To

Hold overrides the

programmed schedule

until the time shown

'Save to schedule' applies

the new temperature to the

current schedule event.

Go to settings

Swipe to view:

• Weather

• Outdoor temperature

• Floor temperature

• Heat To setting

• Cool To setting

Go to schedule

After 60 seconds of inactivity, the thermostat home screen displays only the time and

the temperature.

Save

Cancel

Mode

Heat

Cool

Auto Heat-Cool

Off

Temperature Adjustment

Hold Until 5:00 PM

Save to Schedule

Heat To

Cool To

MENU SELECTION

AWAY SCHEDULE

DISPLAY TIME

WIFI SETUP

FAN

WIFI: Connected

U - 10/16

3 of 8

Away

Schedule

User Settings

Set heating temperature

Set cooling temperature

Select skip if you don't want

a temperature change.

Set schedule start time

Operates normally

Operates using the Away

temperature selected in

the Setup menu

Use the Away setting to save

energy when the building is

unoccupied

•

The Away temperature can

be adjusted in the Setup /

Temps menu.

• Selecting the Away

setting on a thermostat or

the mobile app will affect

all devices linked to that

location through the app.

Save Info

Home / Away

At Home

Away

Heating temperature

Go to the next group

of program days.

Current group of

program days.

Early Start anticipates the

time required to heat or cool

a room and starts early.

Set to On to follow the

schedule. Set to Off to use

the same temperature all

of the time.

Creates a new schedule.

Cooling temperature

New

Schedule

Early Start

Schedule

Wake 6:00 AM 70° 75°

Leave 8:00 AM 65° 78°

Return 6:00 PM 70° 75°

Sleep 10:00 PM 65° 78°

Schedule

Mon Tue Wed Thu Fri

Skip

Wake

Schedule Setup

Mon Tue Wed Thu Fri

6:00 AM

Cool to 75°

Heat to 70°

4 of 8

U - 10/16

Display

Daily Usage

Monthly

Usage

Today 0 hrs 0 hrs

Yesterday 0 hrs 0 hrs

Tue 0 hrs 0 hrs

Mon 0 hrs 0 hrs

Sun 0 hrs 0 hrs

Sat 0 hrs 0 hrs

Fri 0 hrs 0 hrs

View each day's run

time for both heating

and cooling.

Toggle between Daily

and Monthly Usage.

Energy Use

Select °F or °C

Brightness when

touching the display

Choose the

background color

Select English, French

or Spanish

10 second count down

to allow the screen

to be cleaned with a

moist cloth.

Brightness after 60 second

timeout of no use

Energy use. See below.

DISPLAY OPTIONS 2/2

Clean Screen: OFF

DISPLAY 1/2

Temperature Units: °F

Brightness - Active: 80%

Theme: Light

Energy Use: Monthly

Brightness - Inactive: 50%

Language: English

U - 10/16

5 of 8

Time

When connected to the Internet, the time can be set

automatically.

The time and date can be manually set by highlighting

a field and then using the or buttons.

Incorrectly setting the time and date manually may prevent the thermostat from

communicating to the mobile app. Automatic time source is recommended when using

an Internet connection.

Fan

The fan is normally off when

set to auto but turns on when

needed for the heating or

cooling equipment.

When a programmable schedule

is used, there is a fan setting for

each time period.

Fan

Auto

TIME & DATE

1 30 PM

Aug 25 2016

OPTIONS

Fan

Leave Auto

Wake On

Return On

Sleep Auto

Time options are:

• 12 hour or 24 hour time format

• Automatic or manual time setting

• Time zone

• Daylight savings time

6 of 8

U - 10/16

WiFi

The thermostat includes a step by step tutorial to setup the WiFi connection.

Step 1

Agree to Terms of Use

Step 2

Turn on WiFi

Step 3

Enter wireless network

name. It must support

WPA2 security encryption.

Step 4

Enter WiFi password.

Step 6

Select if the time is set

automatically from the

Internet or manually.

Step 5

Enter ZIP or postal code.

This determines your location

for weather information.

Before using the WiFi features of this product, you must accept the Terms of Use, as

amended from time to time and available at tekmarConnect.com/terms. If you do not

accept these terms, this product can still be used without WiFi features.

Tutorial

DISAGREE AGREE

Before first using wi-fi features

of this product, you must accept

the Terms of Use available at

http://tekmarConnect.com/terms

by pressing AGREE below.

If you do not accept these terms.

this product can still be used

without wi-fi features.

WIFI

Off

Time Source

Automatic

Manual

NETWORK SSID

CONNECT

Select a network

from the list:

Your House

A C EB D F

M O QN P R

Y A/1ZShft Del

G I KH J L

S U WT V X

Enter Password

CONNECT

135246

: ( $; ) &

' A/1\Shft Del

7 9 -8 0 /

@ . ?" , !

ZIP/Postal

U - 10/16

7 of 8

tekmar Connect Web and Mobile App

To view and adjust the WiFi Thermostat using a mobile phone or tablet, download the

tekmar Connect mobile app from the Apple® iTunes® Store or from the Google Play® Store.

Alternatively, go to tekmarConnect.com for web browser access.

Step 1

Create a new account. Then

password.

Step 2

Add a Device Step 3

On the thermostat, go

to WiFi menu and press

Step 4

Enter the 8 digit number

from the thermostat into the

mobile app. Then enter the

thermostat's room name. The

app supports multiple site

locations. Enter the location

for the thermostat.

Step 5

Edit your account and save.

The thermostat is

now listed on the My

Devices page.

Add Thermostat to App

----------------------------------------------

Password

Forgot Password

Terms and conditions

Don't have an account?

My Devices Account

ADD A DEVICE

You don't have any devices associated with this location.

HOME

Home

REGISTRATION

To finish registering

your thermostat,

enter the code

displayed below at

tekmarConnect.com

12345678

My Devices Account

12345678

WiFi Thermostat 562

ADD DEVICE

Activation Number

Device Name

Location

Add a Device

Home

My Devices Account

SAVE

First & Last Name

Username

[email protected]

Email Address

Edit Your Account

(###)###-####

Phone

Logout

Change Password

Units

My Devices Account

WiFi Thermostat 562 78 °F

Auto

HOME

Home

562

Tel: (250) 545-7749 • Fax: (250) 984-0815

tekmarControls.com

All specications are subject to change without notice

Using the App

-------------------------------------------------------

Set to AWAY to save

energy when you are

away for a day or more.

Choose a location.

Edit location info

Edit account info

Edit device info

View energy usage

Change from Heat,

Cool, Auto or Off mode

Change heating and

cooling setting

Save temperature

change to the schedule

Return to home view

Temperature change hold

until schedule change

View and edit schedule

View and change

thermostat

Add a device

My Devices Account

WiFi Thermostat 562

WiFi Thermostat 561

WiFi Thermostat 562

Off

75 °F

Heat

78 °F

Heat

HOME

Home

SAVE TO

PROGRAM CANCEL

HOLD

My Devices Account

WiFi Thermostat 562

Auto

HEAT TO

70°

TEMP

72°

40° 100°

76°

COOL TO
