Wasp WPL304 Manuel utilisateur

WPL304

WPL 304 User Manual

Contents

1. Introduction ............................................................................................................................. 1

1.1 Product Introduction.............................................................................................................. 1

1.2 Compliances ........................................................................................................................... 1

2. Operations Overview..................................................................................................................... 3

2.1 Unpacking and Inspection...................................................................................................... 3

2.2 Printer Overview .................................................................................................................... 4

2.2.1 Front View ....................................................................................................................... 4

2.2.2 Interior view .................................................................................................................... 6

2.2.3 Rear View ........................................................................................................................ 7

3. Setup............................................................................................................................................. 8

3.1 Setting up the Printer............................................................................................................. 8

3.2 Open / Close the Top Cover ................................................................................................... 9

3.3 Loading the Ribbon .............................................................................................................. 10

3.4 Loading the Media ............................................................................................................... 13

3.4.1 Loading the media......................................................................................................... 13

3.4.2 External Label Roll Mount Installation (Option) ........................................................... 15

3.4.3 Loading Media in Peel-off Mode (Option) .................................................................... 16

3.4.4 Loading Media in Cutter Mode (Option)....................................................................... 16

3.5 Diagnostic Tool ...................................................................................................................... 18

3.5.1 Start the Diagnostic Tool............................................................................................... 18

3.5.2 Printer Function (Calibrate sensor, Ethernet setup, RTC setup )............................... 19

3.6 Setting Ethernet by Diagnostic Utility..................................................................................... 20

3.6.1 Using USB interface to setup Ethernet interface.......................................................... 20

3.6.2 Using RS-232 interface to setup Ethernet interface ..................................................... 21

3.6.3 Using Ethernet interface to setup Ethernet interface .................................................. 22

3.7 Install SD Memory Card ....................................................................................................... 24

4. LED and Button Functions.......................................................................................................... 26

4.1 LED indicator ........................................................................................................................ 26

WPL 304 User Manual

4.2 Regular button function....................................................................................................... 26

4.3 Power on utilities ................................................................................................................. 26

4.3.2 Gap/Black Mark Calibration, Self-test and Dump Mode .............................................. 28

4.3.3 Printer Initialization....................................................................................................... 31

4.3.4 Set Black Mark Sensor as Media Sensor and Calibrate the Black Mark Sensor ........... 32

4.3.5 Set Gap Sensor as Media Sensor and Calibrate the Gap Sensor .................................. 32

5. Troubleshooting......................................................................................................................... 34

5.1 LED Status............................................................................................................................. 34

5.2 Print Quality .......................................................................................................................... 35

6. Maintenance ............................................................................................................................... 36

WPL 304 User Manual

No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without

permission in writing from Wasp Technologies. This includes electronic or mechanical means, such as photocopying,

recording, or information storage and retrieval systems. The material in this manual is subject to change without notice.

The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on a licensed

basis. Wasp Technologies grants to the user a non-transferable and nonexclusive license to use each software or firmware

program delivered hereunder (licensed program). Except as noted below, such license may not be assigned, sublicensed, or

otherwise transferred by the user without prior written consent of Wasp Technologies. No right to copy a licensed program

in whole or in part is granted, except as permitted under copyright law. The user shall not modify, merge, or incorporate any

form or portion of a licensed program with other program material, create a derivative work from a licensed program, or use

a licensed program in a network without written permission from Wasp Technologies. The user agrees to maintain Wasp

Technologies’ copyright notice on the licensed programs delivered hereunder and to include the same on any authorized

copies it makes, in whole or in part. The user agrees not to decompile, disassemble, decode, or reverse engineer any licensed

program delivered to the user or any portion thereof.

Wasp Technologies reserves the right to make changes to any software or product to improve reliability, function, or design.

Wasp Technologies does not assume any product liability arising out of, or in connection with, the application or use of any

product, circuit, or application described herein. No license is granted, either expressly or by implication, estoppel, or

otherwise under any Wasp Technologies, intellectual property rights. An implied license only exists for equipment, circuits,

and subsystems contained in Wasp Technologies products.

Wasp Technologies is a registered trademark of Wasp Technologies. Other product names mentioned in this manual may be

trademarks or registered trademarks of their respective companies and are hereby acknowledged.

Wasp Technologies

1400 10th St.

Plano TX 75074

http://www.waspbarcode.com

WPL 304 User Manual

1. Introduction

1.1 Product Introduction

Thank you for purchasing the WPL304 barcode printer. Although the printer is compact, it

delivers reliable, superior performance.

This printer provides both thermal transfer and direct thermal printing at user selectable speed

of: 2.0, 3.0, 4.0 or 5.0 ips. It accepts roll feed, die-cut, and fan-fold labels for both thermal

transfer and direct thermal printing. All common barcodes formats are available. Fonts and

barcodes can be printed in 4 directions, 8 different alphanumeric bitmap fonts and a build-in

true type font capability. You will enjoy high throughput for printing labels with this printer.

1.2 Compliances

CE Class B:

EN55022: 1 998+A1: 2000+A2: 2003

EN55024: 1998+A1: 2001 +A2: 2003 IEC 61 000-4 Series

EN61 000-3-2: 2006 & EN61 000-3-3: 1 995+A1: 2001

FCC Part 15, Class B

UL, CUL

C-Tick:

CFR 47, Part 15/CISPR 22 3

Edition: 1997, Class B

ANSI C63.4: 2003

Canadian ICES-003

TÜV/Safety: EN60950: 2000

Wichtige Sicherheits-Hinweise

1. Bitte lesen Sie diese Hinweis sorgfältig durch.

2. Heben Sie diese Anleitung fűr den späteren Gebrauch auf.

3. Vor jedem Reinigen ist das Gerät vom Stromentz zu trennen. Verwenden Sie keine

Flüssig-oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur

Reinigung.

4. Die Netzanschluß-Steckdose soll nahe dem Gerät angebracht und leicht zugänglich

sein.

5. Das Gerät ist vor Feuchtigkeit zu schűtzen.

6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder

Fallen könnte Beschädigungen hervorrufen.

7. Beachten Sie beim Anschluß ans Stromnetz die Anschlußwerte.

1. Dieses Gerät kann bis zu einer Außentemperatur von maximal 40 betrieben werden.

WPL 304 User Manual

1. HAZARDOUS MOVING PARTS IN CUTTER MODULE. KEEP FINGER AND OTHER BODY

PARTS AWAY.

2. THE MAIN BOARD INCLUDES REAL TIME CLOCK FEATURE HAS LITHIUM BATTERY

CR2032 INSTALLED. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN

INCORRECT TYPE.

3. DISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER INSTRUCTIONS.

WARNUNG!

GEFÄHRLICHE BEWEGLICHE TEILE –FINGER UND ANDERE KÖRPERTEILE

FERNHALTEN!

VORSICHT!

EXPLOSIONSGEFAHR BEI ERSATZ DER

BATTERIE DURCH UNZULÄSSIGEN TYP.

VERBRAUCHTE BATTERIEN IMMER

VORSCHRIFTSGEMÄSS ENTSORGEN!

B 급급 급

(급급급 급급급급급급)

급급급급 급급급급급 급급급 급급급급급 급급급급급

급급급급급급급 급급 급급 급급급급 급급급 급급급급급.

Note

* Continuous printing will cause the printer motor to overheat. The printer will stop printing

automatically for approximately 10~15 minutes while the motor is cooling down. Please don’t turn

off power when the printer pauses or the data transferred to the printer buffer will be lost.

* The maximum printing ratio per dot line is 15% for this printer. To print the full web black line, the

maximum black line height is limited to 40 dots, which is 5mm for 203 DPI resolution printer and

3.3mm for 300 DPI resolution printers.

* The max. full web black bar is limited to 5 mm only, otherwise this may damage the power supply.

WPL 304 User Manual

2. Operations Overview

2.1 Unpacking and Inspection

This printer has been specially packaged to withstand damage during shipping.

Please carefully inspect the packaging and printer upon receiving the barcode printer.

Please retain the packaging materials in case you need to reship the printer.

Unpacking the printer, the following items are included in the carton.

•One printer unit

•One Windows labeling software/Windows driver CD disk

•One quick installation guide

•One power cord

•One auto switching power supply

•One USB interface cable

If any parts are missing, please contact the Customer Service Department of your

purchased reseller or distributor.

WPL 304 User Manual

2.2 Printer Overview

2.2.1 Front View

1. Ribbon access cover

2. Top cover open lever

3. Media view window

4. LED indicator

5. Feed button

6. SD card socket

* Recommended SD card specification.

SD card spec SD card capacity Approved SD card manufacturer

V1.0, V1.1 128 MB SanDisk, Transcend

V1.0, V1.1 256 MB SanDisk, Transcend, Panasonic

V1.0, V1.1 512 MB SanDisk, Transcend, Panasonic

V1.0, V1.1 1 GB SanDisk, Transcend, Panasonic

V2.0 SDHC CLASS 4

4 GB

V2.0 SDHC CLASS 6

4 GB SanDisk, Transcend, Panasonic

V1.0, V1.1 microSD 128 MB Transcend, Panasonic

V1.0, V1.1 microSD 256 MB Transcend, Panasonic

WPL 304 User Manual

V1.0, V1.1 microSD 512 MB Panasonic

V1.0, V1.1 microSD 1 GB Transcend, Panasonic

V2.0 SDHC CLASS 4

microSD 4 GB Panasonic

V2.0 SDHC CLASS 6

microSD 4 GB Transcend

V1.0, V1.1 miniSD 128 MB Transcend, Panasonic

V1.0, V1.1 miniSD 256 MB Transcend, Panasonic

V1.0, V1.1 miniSD 512 MB Transcend, Panasonic

V1.0, V1.1 miniSD 1 GB Transcend, Panasonic

V2.0 SDHC CLASS 4

miniSD 4 GB Transcend

V2.0 SDHC CLASS 6

miniSD 4 GB

- The DOS FAT file system is supported for the SD card.

- Folders/files stored in the SD card should be in the 8.3 filename

format - The miniSD/microSD card to SD card slot adapter is required.

WPL 304 User Manual

2.2.2 Interior view

1. Ribbon rewind hub

2. Ribbon rewind gear

3. Gap sensor (receiver)

4. Media holder

5. Media holder lock switch

6. Gap sensor (transmitter)

7. Printhead

8. Ribbon supply hub

9. Top cover support

10. Media guide adjustment knob

11. Black mark sensor

12. Platen roller
