Walker Edison D56FUL2DG Manuel utilisateur

P.1

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

Please visit our websitefor the most current instructions, assemblytips, report damage,

or request parts. www.walkeredison.com

Revised 09/10/2019(L)

Walker Edison

D56FUL2DG

VIII.Drillmaybeneededforsecuringproduct towall.

GeneralAssembly Guidelines

I. Ensure thatallpartsandhardware are available beforebeginning assembly.

II.Followeachstepcarefullytoensure theproper assembly of this product.

III.Twopeoplearerecommendedfor easeintheassembly of this product.

IV.Thethreemain typesofhardware usedtoassemblethis product are: wood

dowels,screwsandbolts.

V.Theprovidedglueistosecurewooddowelsin place.Whenfirst inserting dowels,

locatetheappropriatehole forthedowel,placeasmallamount of glue inthe hole

andinsertthedowel.Wipeawayexcessglueimmediately.

Infutureassemblystepswhendowelsarenecessary toattachassembly parts

together,placeasmallamountofglueonthe endofthedowelbeforeattaching

partstogether.Wipeawayexcessglueimmediately.

VI.APhillipsheadscrewdriverisrequiredfortheassemblyofthis product .

VII. Power toolsshould notbeusedtoassemblethis product.

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

P.2

Parts List

P.3

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

12 12

P.4

The hardware quantities listed above are required for proper assembly.

Someextrahardware may also have been included.

8x30mm Woodendowel 19 pcs

Philipsheadscrewdriverrequiredforassembly

(notincluded)

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

8x35mm Cambolt 24 pcs

15x11mm Camlock 24 pcs

Sticker

6x50mm Screw

24 pcs

E16 pcs

Handle 2 pcs

4x22mm Bolt 2 pcs

4mm HexKey 1 pc

Screw 8 pcs

Screw 24 pcs

4x32mm

3x12mm

Bolt

1/4"x25mm

HardwareList

Glasspads

12 pcs

Bolt

1/4"x10mm 16 pcs

*Note:Thispiece comes preassembled for

shippingpurposesand must bedisassembled

tocompleteassembly.

Drawerslider Set

8pcs

Gluetube 1 pc

P.5

Step 1

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

Sliderbracket

Sliderarm

Sliderbracket

Sliderarm

Pick up the Ball Bearing Slides (Q) and separate the slide Runner for the following Steps.

Extend the Slide Runner all the way forward,press the plastic release lever of the ball bearing

Slides up and pull the Slide Runner Complete out .

P.6

Step 2

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

14x2pcs 15x2pcs

17x2pcs

Secure cam bolt (B) into part (17) ,then using bolt (G) attach handle (F) into part (17) and using

screw (L) attach slider (Q) into parts (14,15),with Philips head screwdriver as per diagram.

Step 3

P.7

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

Finished edge

Use screw (L) attach slider (Q) into parts (6,7,8,9),with Philips head screwdriver as per diagram.

Step 4

P.8

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

Finished edge

Insert wooden dowel (A) into parts (6,7,8,9,) ,then secure cam bolt (B) into parts (6,9) with Philips

head screwdriver as per diagram.

P.9

Step 5

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

Insert wooden dowel (A) into part (10) ,then secure cam bolt (B) into part (3) with Philips head

screwdriver as per diagram.

P.10

Step 6

201

9, by Walker Edison Furniture Co., LLC. All rightsreserved.

Using bolt (N) attach part (5) into part (2) with hex key (H) as per diagram.

Note: Do not tighten all bolts.
