Wali 011ARM Manuel utilisateur

75x75/100x100 8kg

(17.6lbs)

RATED

32"

MAX

Use with products heavier than the rated weights indicated may result in instability causing possible injury.

Please closely follow the assembly instructions. Improper installation may result in damage or serious personal injury.

Safety gear and proper tools must be used. This product should only be installed by professionals.

Make sure that the supporting surface will safely support the combined weight of the equipment and all attached hardware and components.

Use the mounting screws provided and DO NOT OVER TIGHTEN mounting screws.

This product contains small items that could be a choking hazard if swallowed. Keep these items away from children.

This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.

Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, contact your place of

purchase for a replacement.

Check that the product is secure and safe to use at regular intervals (at least every three months). Pole Mount Monitor Arm

INSTALLATION MANUAL

011ARM

[email protected]

Press on the screw from the bottom to take it

minØ28-maxØ45mm

minØ46-maxØ60mm

6mm

F(x1)

A (x1)

C (x1)

B (x1)

M8x70

D (x2)

M-E (x4) M-F (x4)

M5x12

M-C(x4)

M5x16

M-D (x4)

M4x16

M-B (x4)

M-C

M-E

M-B

M-D

M-E

M-F

±90°

±180°

+30°

-30°

E (x1)

Notice: The mounting pole in the image is not included.

off and replace it with M8x70 Bolt D.

M4x12 Bolt

M-A (x4)

M-A

M-E
