This manual describes the Digital Output Module 750-504(/xxx-xxx)

4 DO DC 24 V 0.5 A, High-Side Switching of the modular WAGO-I/O-

SYSTEM 750.

Handling, assembly and start-up are described in the manual of the Fieldbus

Coupler. Therefore this documentation is valid only in the connection with the

appropriate manual.

Downloaded from Elcodis.com electronic components distributor

750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching] • 7

Variations

WAGO-I/O-SYSTEM 750

I/OModules

2 I/O Modules

2.1 Digital Output Module

2.1.1 750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching]

4-Channel Digital Output Module DC 24 V 0.5 A,

short-circuit-protected, high-side switching

2.1.1.1 Variations

Item-No. Designation Description

750-504 4 DO DC 24 V 0.5 A

High-Side Switching

4-Channel Digital Output Module DC 24 V

0.5 A,

short-circuit-protected, high-side switching

750-504/025-000 4 DO DC 24 V 0.5 A,

High-Side Switching /T

4-Channel Digital Output Module DC 24 V

0.5 A,short-circuit-protected, high-side

switching extended temperature range from –

20 °C to +60 °C

2.1.1.2 View

13 14

750-504

DO 2

Power jumper contacts

Data contacts

DO 2

Status

24V

DO 4

DO 1

Status

DO 1

DO 4

DO 3

Fig. 2.1.1-1: 4-Channel Digital Output Module 750-504 g050400e

Downloaded from Elcodis.com electronic components distributor

8 • 750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching]

Description

WAGO-I/O-SYSTEM 750

I/O Modules

2.1.1.3 Description

The connected load is switched via the digital output from the control system.

The module has four output channels. Two actuators may be directly

connected to the module.

As an example, two 2-conductor actuators may be directly connected using

connection 0 V and signal output DO 1 or 0 V and signal output DO 2. The

connection of more actuators to signal outputs DO 3 and DO 4 requires a field

side connection module (750-614) for 24V and for 0V, if need be.

Note

For the connection of inductive loads a protected circuit, e. g. a recovery

diode, has to be switched parallel to this load.

The output channels are electrically short-circuit-protected and high-side

switching. Which means that the status of the output channels is "high" if the

output channels switch to the 24 V supply voltage for the field side.

The supply voltage for the field side is derived from an adjacent supply

module by means of power jumper contacts.

The status of the four output channels is indicated via green status LEDs.

An optocoupler is used for electrical isolation between the bus and the field

side.

Any configuration of the output modules is possible when designing the

fieldbus node. Grouping of module types is not necessary.

The field side supply voltage of 24 V for the output module is derived from

adjacent I/O modules or from a supply module.The supply voltage for the

field side is made automatically through the individual I/O modules by means

of power jumper contacts.

Warning

The maximum current of the internal power jumper contacts is 10 A. When

configuring the system it is important not to exceed the maximum/sum

current. However, if such a case should occur, another supply module must be

added.

Attention

In case of overloads a supply module with fuse (750-601) must be connected

on the line side to protect the output modules!

The output module 750-504 can be used with all couplers/controllers of the

WAGO-I/O-SYSTEM 750.

Downloaded from Elcodis.com electronic components distributor

750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching] • 9

Display Elements

WAGO-I/O-SYSTEM 750

I/OModules

2.1.1.4 Display Elements

LED Channel Designation State Function

off Output DO 1: not activeA

green

1 Status

DO 1 on Output DO 1: active

off Output DO 2: not activeC

green

2 Status

DO 2 on Output DO 2: active

off Output DO 3: not activeB

green

3 Status

DO 3 on Output DO 3: active

off Output DO 4: not active

13 14

Fig. 2.1.1-2: Display

Elements g050402x

green

4 Status

DO 4 on Output DO 4: active

2.1.1.5 Schematic Diagram

750-504

10nF

DO 1

DO 3

DO 2

DO 4

24V

270pF

10nF

24V

Fig. 2.1.1-3: 4-Channel Digital Output Module 750-504 g050401e

Downloaded from Elcodis.com electronic components distributor

10 • 750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching]

Technical Data

WAGO-I/O-SYSTEM 750

I/O Modules

2.1.1.6 Technical Data

Module Specific Data

Number of outputs 4

Current consumption (internal)max. 7 mA

Voltage via power jumper contacts DC 24 V (-15 % / + 20 %)

Type of load resistive, inductive, lamps

Switching rate max. 1 kHz

Reverse voltage protection yes

Output current 0.5 A short-circuit-protected

Energy dissipation Wmax.

(unique switching off)

0.3 J

Lmax. = 2 Wmax. /I²

Isolation 500 V (System/Field)

Current consumption typ.(field side) 30 mA (per module) + load

Internal bit width 4 Bit out

Dimensions (mm) W x H x L 12 x 64* x 100

* from upper edge of 35 DIN rail

Weight ca. 50 g

Standards and Regulations (cf. Chapter 2.2 of the Coupler/Controller Manual)

EMC-Immunity to interference (CE) acc. to EN 61000-6-2 (01)

EMC-Emission of interference (CE) acc. to EN 61000-6-3 (01)

EMC-Immunity to interference (Ship building) acc. to Germanischer Lloyd (01)

EMC-Emission of interference (Ship building) acc. to Germanischer Lloyd (01)

Approvals (cf. Chapter 2.2 of the Coupler/Controller Manual)

CULUS (UL508)

ABS (American Bureau of Shipping)

BV (Bureau Veritas)

DNV (Det Norske Veritas) Cl. B

GL (Germanischer Lloyd) Cat. A, B, C, D

KR (Korean Register of Shipping)

LR (Lloyd's Register) Env. 1, 2, 3, 4

NKK (Nippon Kaiji Kyokai)

RINA (Registro Italiano Navale)

CULUS (UL1604) Class I Div2 ABCD T4A

KEMA II 3 G EEx nA II T4

Conformity Marking

Downloaded from Elcodis.com electronic components distributor

Autres manuels pour I/O-SYSTEM 750

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels WAGO Système d'E/S

WAGO

WAGO I/O-SYSTEM 750 Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 750 Manuel utilisateur

WAGO

WAGO 750-842 Manuel de l'opérateur

WAGO

WAGO WAGO-I/O-SYSTEM 750-424 Manuel utilisateur

WAGO

WAGO 750-626/040-000 Manuel utilisateur

WAGO

WAGO 750 Series Manuel utilisateur

WAGO

WAGO 750-643 Manuel utilisateur

WAGO

WAGO 750-650 Manuel utilisateur

WAGO

WAGO 750-454 Manuel utilisateur

WAGO

WAGO 750-496 Manuel utilisateur

WAGO

WAGO I/O SYSTEM 750 750-635 Manuel utilisateur

WAGO

WAGO 750 Series Manuel utilisateur

WAGO

WAGO 750-468 Manuel utilisateur

WAGO

WAGO 750-464 Manuel utilisateur

WAGO

WAGO 750-8 Series Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 750 Manuel utilisateur

WAGO

WAGO 750 Series Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 750 753-501 Manuel utilisateur

WAGO

WAGO 750 Series Manuel utilisateur

WAGO

WAGO I/O System 750 750-622 Manuel utilisateur

WAGO

WAGO I/O System 750 Series Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 750 Manuel utilisateur

WAGO

WAGO IO-SYSTEM 750-415 Manuel utilisateur

WAGO

WAGO I/O System 750 Series Manuel utilisateur

Manuels Système d'E/S populaires d'autres marques

Teknim

Teknim TWM-1887 Mode d’emploi

Intelligent Appliance

Intelligent Appliance IA-2662-E Manuel utilisateur

BERGHOF

BERGHOF ECC DIO 16/16 Mode d’emploi

Advantech

Advantech PCM-27J3AU Manuel d'installation et d'exploitation

Festo

Festo CP-E08-M12-CL Manuel utilisateur

Measurement Computing

Measurement Computing PCI-DAS64/M1/16 Manuel utilisateur

Hitachi

Hitachi HX-RIO3 Series Manuel utilisateur

NUUO

NUUO SCB-A08 Manuel utilisateur

M-system

M-system R3Y-RS8 Manuel utilisateur

jablotron

jablotron JB-110N Manuel utilisateur

Omron

Omron SYSMAC C200H Manuel utilisateur

DOLD

DOLD SAFEMASTER M Manuel utilisateur

ABB

ABB OPT-MF-001 Manuel utilisateur

Omron

Omron SYSMAC C2000H Manuel utilisateur

Helmholz

Helmholz TB20 Manuel utilisateur

ICP DAS USA

ICP DAS USA tM-AD2 Manuel utilisateur

Automationdirect.com

Automationdirect.com DL305 Manuel utilisateur

Contec

Contec PIO-16L(PCI)H Manuel utilisateur
