Vyyo V284 Manuel utilisateur

Document Version 1.05

November 2004

A Vyyo Inc. Technical Document

V284

IRELESS

ODEM

NIT

User’s Guide

ö V284 WMU User’s Guide

www.vyyo.com

DOCUMENT DETAILS

Vyyo Inc. reserves the right to alter the equipment specifications and descriptions in

this publication without prior notice. No part of this publication shall be deemed part

of any contract or warranty unless specifically incorporated by reference into such

contract or warranty.

The information contained herein is merely descriptive in nature, and does not

constitute a binding offer for the sale of the product described herein. Any use of

the Vyyo Inc. logo or trademarks is forbidden without prior written approval from

Vyyo Inc.

All trademarks mentioned herein are the property of their respective owners. Vyyo

Inc.’s trademarks include, but are not limited to, “Vyyo” and “Wireless liberty for all.”

Details:

Product Name: V284 WMU (Wireless Modem Unit)

Software Version:

Document Type: User’s Guide

Document Number:

Document Version:

Author:

Document File Name:

Date:

Total Pages:

Status: Production

Change History:

# Date Changed By Update

1 2004-11-04 Doug Broussard

2 2004-11-15 Doug Broussard

3 2004-12-14 Doug Broussard Added FCC Comp.

Statement

Distribution and Approval:

Approved By Approval Type Date √

Baruch Leiman Content √

Yoel Halimi Technical √

Aharon Avrahami Overall

ö V284 WMU User’s Guide

www.vyyo.com

FCC Compliance Statement

NOTE: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules.

These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the distance between the equipment and

receiver.

•-Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

•-Consult the dealer or an experienced radio/TV technician

for help.

Warning!

Changes or modifications to this equipment not expressly approved by

Vyyo, Inc. could void the user’s authority to operate the equipment.

Warning!

This product was tested and shipped with shielded coaxial cable and

Category 5 Ethernet cable equipped with a shielded RJ-45 connector.

These cables must be used with the unit to ensure compliance.

ö V284 WMU User’s Guide

www.vyyo.com

iii

CONTENTS

1Overview and Purpose ..................................................... 1

1.1 Purpose of This User’s Guide .......................................... 1

1.2 Target Audience............................................................... 1

1.3 Vyyo ................................................................................. 1

2Modem Features and Components ................................. 2

2.1 Front Panel Indicators ...................................................... 2

2.2 Back Panel Ports.............................................................. 1

3Using the Modem .............................................................. 2

4Technical Specifications .................................................. 3

5Problem Troubleshooting ................................................ 5

6Warranty Information........................................................ 7

7FCC Declaration of Conformity........................................ 9

8Contacting Vyyo................................................................ 10

ö V284 WMU User’s Guide

www.vyyo.com

1 O

VERVIEW AND

URPOSE

Welcome to the User’s Guide for the Vyyo Inc. V284 Modem.

Figure 1. The Vyyo V284 Wireless Modem Unit

1.1 Purpose of This User’s Guide

The purpose of this User’s Guide is to provide clear and

concise instructions for operating the Vyyo Inc. V284 modem.

1.2 Target Audience

This User’s Guide is intended for users of the V284 modem.

1.3 Vyyo

Vyyo Inc. provides fixed wireless broadband end-to-end

telephony and high-speed data connections to business and

residential subscribers. Vyyo Inc. technology uses point-to-

multipoint architecture to deliver circuit-switched telephony

and data over IP to commercial and private customers

throughout the world.

ö V284 WMU User’s Guide

www.vyyo.com

2 M

ODEM

EATURES AND

OMPONENTS

The V284 modem offers the following features:

•Point-to-multipoint broadband wireless Internet access

•Superior operations over a wide range of modulation formats

and IF bandwidths, including noisy channels

•Easy installation

•Robust RF performance

•Internal radio for UHF bands

2.1 Front Panel Indicators

Four Light Emitting Diode (L.E.D.) indicators are located at

the front of the modem.

The L.E.D.s provide information about the type and status of

modem operations, as described in Table 1.

Figure 2 – V284 WMU Front Panel L.E.D. Indicators

ö V284 WMU User’s Guide

www.vyyo.com

Table 1. L.E.D. Status and Functions

L.E.D. Indicator Function

POWER •On = Power On

•Off = Power Off

•Flashing = Fatal Error

STATUS •On = Modem is connected to the Internet

•Off = Modem is not connected to the Internet

RF LINK When Status L.E.D. is Off:

•RF On = The downstream link is operational

•RF Off = The modem has not yet begun

downstream acquisition, the

downstream link is idle, or there is a

problem with data reception

•RF Flashing = Downstream link is being acquired

When Status L.E.D. is On:

•RF Flashing = Data is transferring in either in the

Upstream or Downstream direction

LAN&

USB

•On = The LAN link is operational

•Off = The LAN link is not operational

•Flashing = Data is transferring to or from the LAN

ö V284 WMU User’s Guide

www.vyyo.com

2.2 Back Panel Ports

There are four ports and one button located at the back panel

of the V284 modem.

Figure 3 – V284 WMU rear Panel Ports

Port or Button Function

POWER Connect the 9 volt external power source to this port.

RESET Press this button to reset the modem to its default

settings.

Note: Use a straightened paper clip or a straight pin

to depress the Reset button.

LAN Connect an RJ-45 Ethernet cable to this port.

The other end of the cable can be connected to the

subscriber’s computer or an Ethernet hub or switch.

USB Use a USB A-B cable to connect this Universal

Serial Bus port to the customer’s computer. Use this

port when the customer’s computer is not equipped

with an Ethernet port.

Note: The USB port is not currently supported.

Cable Connect this F-type connector to the UHF antenna.

Table 2. V284 Rear Panel Ports

ö V284 WMU User’s Guide

www.vyyo.com

3 U

SING THE

ODEM

Follow the steps below to use the modem properly.

To use the modem:

1 Check that the computer with which you are using the V284

modem contains a working Ethernet network card, and has

the following software installed and operational:

•Microsoft Windows 95 operating system or later

•Access to the Internet

•A standard Internet browser application

•The Telnet communications utility

2 Attach your computer to the modem’s LAN port with the

included RJ-45 Ethernet cable.

3 Connect the antenna cable to the CABLE port at the back

of the modem.

4 Plug the 9-Volt modem power supply jack into the POWER

port at the back of the modem, and plug the power supply

transformer unit into a standard electrical wall outlet.

Note: As with any household electrical device, avoid the risk of accidental

electrical shock. Make sure that your hands are completely dry and that there is

no moisture on the floor or other surfaces in the immediate area of the electrical

wall outlet.

After connecting the power adapter to the modem, verify that

the three green front panel LEDs light up for approximately 2

seconds before going out.

The orange POWER LED at the left of the front panel lights

up and remains lit, indicating that the modem is powered up.

WARNING: To comply with FCC RF exposure compliance requirements, the

modem should be located in a distance of at least 20 cm from all persons during

normal operation. The antennas used for this product must be outdoor or

indoor, fixed mounted on permanent structures, providing a separation distance

of at least 20 cm from all persons during normal operation.

ö V284 WMU User’s Guide

www.vyyo.com

4 T

ECHNICAL

PECIFICATIONS

General

Dimensions 5.25 x 4.25 x 1.00 in. (13 x 11 x 2.5 cm)

Operating Temperature 32 to 112° F (0 to 45° C)

Power 800 mA at 9V

Power Supply 110 - 220 VAC

LED Indicators (4) Power, Status, RF/Link, LAN/USB

Interface

Data Interface RJ45 – 10/100 baseT Ethernet full/half duplex

USB [Not currently supported]

IF Interface 75 ohm Type F Female Connector

IF /RFCharacteristics

Downstream

Frequency Range 740 – 746 MHz Downstream Receive

Channel Bandwidth 6, 3.5, 2.75, 1.75 MHz

Modulation Format QPSK, 16QAM, & 64 QAM

Data Rates 3-30 Mbps

Rx Sensitivity (dBm) BW (MHz) 64 QAM 16 QAM QPSK

6 -75 -81 -87

3.5 -78 -84 -90

1.75 -81 -87 -93

IF /RFCharacteristics

Upstream

Frequency Range 710 – 716 MHz

Channel Bandwidth 400, 800, 1600, & 3200 kHz

Modulation Fomat QPSK & 16QAM

Data Rates 640 kbps – 10.24 Mbps

RF Output P1dB 27 dBm

Linear Output Power 22.3 dBm

Service

Network Management Protocol: SNMP

MIB: RFC1213, RFC1493,

RFC2233, RFC2669,

RFC2670, DOCSIS Privacy

MIB

Provisioning: As per DOCSIS

Security Link Layer Encryption: DES CBC, 40 and 56 Bits

per user

Key Distribution: Two-layer key distribution

protocol, which include DES-

ECB and RSA public key

encryption and HMAC-SHA1

authorization

Upstream QoS Committed Information

Rate (CIR) per user:

32 Kbps - 2 Mbps (up to 4

Mbps best effort)

Peak Information Rate

(PIR) per user:

32 Kbps - 2 Mbps

Downstream QoS Supported by an add-on packet-shaping device at the

Base Station

IP Protocols Network Protocols: IP, ICMP, ARP, PPPoE,

802.1Q/p, IP Multicast

VoIP: G711, G729, G723

Transport Protocols: TCP, UDP, RTP

Application Protocols: SNMP, TFTP, DHCP

# IP Data Services 64 CPE MAC Addresses

Table des matières

Autres manuels Vyyo Modem

Vyyo

Vyyo V284+C Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
