WELCOME TO YOUR NEW VOLVO!

Getting to know your car is an exciting experience.

After looking through this Quick Guide you'll like your new Volvo even

more. You can find detailed information in the Owner's Manual.

Warning texts and other important information are only available in the

Owner's Manual, not in this folder. The Owner's Manual contains the

most up-to-date information.

Options are marked with an asterisk (*).

VOLVO S40

QUICK GUIDE

AUTOSTART (APPLIES TO 2.4i, T5 AND D5)

Turn the ignition key/dial to position III and

release. The engine starts automatically.

Diesel engines must always be preheated in

position II before the engine is started.

KEY BLADE

Used to lock/unlock the glovebox or the driver's

door lock, e.g. if car is without electrical power.

COLD START

NOTE

The idling speed may briefly be slightly higher

in order to achieve efficient emission control.

KEY & REMOTE CONTROL

Locks doors and boot lid and arms the

alarm*.

Unlocks doors1and boot lid and dis-

arms the alarm.

Unlocks boot lid. (Boot lid does not

open.)

Switches on lighting for 30 seconds2

in side mirrors*, in cabin, by feet and on

number plate. Indicators and parking

lamps illuminate.

"Panic" button. Press and hold for

approx. 3 seconds in an emergency to

trigger the alarm. Switch off the alarm

with the unlock button.

DIRECTION INDICATORS

A. Short sequence, three flashes.

B. Continuous flash sequence.

WARNING! Adjust the steering wheel before

setting off, never while driving.

ADJUSTINGTHE STEERING WHEEL

1. Automatic relocking takes place if a door/boot lid is

not opened within 2 minutes after unlocking.

2. The time is adjustable to 30, 60 or 90 seconds, see

Owner's Manual.

CONTROL PANEL IN DRIVER'S DOOR

L R

Adjusting the door mirrors, select

L or R. Set with the lever.

Retracting the door mirrors*, press

Land Rsimultaneously. Press again

to extend.



Manual windows

Automatic windows

Locking the rear windows and

doors*, child safety locks.

LIGHT SWITCHES

Headlamp levelling, automatic for

Bi-Xenon lights*.

Automatic dipped beam and main

beam flash. Main beam cannot be

activated.

Parking lamps

Dipped beam, switches off when the

ignition is switched off. Main beam can

be activated.

Active Bi-Xenon Lights*, the headlamp

pattern follows the movement of the

steering wheel.

Display and instrument lighting

Front fog lamps*

Rear fog lamp, one lamp

Main beam flash

Main/dipped beam switching and

approach lighting.

Washing by hand is gentler to the paintwork

than an automatic car wash. The paintwork

is also more sensitive when it is new. For this

reason, handwashing is recommended during

the first few months with a new car.

Leather upholstery requires regular cleaning.

Treat with leather care products, once to four

times per year or as necessary. Leather care

products are available at your Volvo dealer.

CAR CARE

A B

On/Off and audio volume. Press for

On/Off. Turn to adjust the volume. Radio,

TP, handsfree* and RTI* volume are stored

individually.

FM1, FM2 or AM radio

Display, clock set via personal settings.

MODE. CD or AUX1

Sound pattern, press to select sound

pattern e.g. BASS and Dolby Pro Logic II*

or SUBWOOFER*. Turn to adjust.

MENU, AUX, volume and advanced audio

settings. Activate/deactivate SUB-

WOOFER*.

RADIO

Select radio station by turning.

Search for station using Left/Right arrow

or SCAN (8). Store up to 20 stations by

holding in 0–9 on FM1 and 0–9 on FM2.

When a station has been stored it is con-

firmed in the display.

Autostoring stations.

Press AUTO for approx. 2 seconds.

Autostoring is shown in the display. The

ten strongest stations are stored. Then

press 0–9 to select a station.

CD PLAYER

Change CD track using Left/Right arrow

or turn (6).

Select CD disc2using Up/Down arrow.

Ejecting a CD disc. One short press

ejects the current disc. One long press

ejects all2.

Direct selection CD disc2. Press 1–6.

1. AUX input for e.g. MP3 player (set volume at me-

dium for optimum audio reproduction).

2. Only CD changer*.

AUDIO SYSTEM

WINDSCREEN WIPERS AND RAIN SENSOR*

Single sweep

Off

Intermittent wiping, turn (B) to adjust.

Normal speed

High speed

Windscreen and headlamp washing

Activates rain sensor. Position D–F

deactivates rain sensor.

Adjust sensitivity using the thumb-

wheel.

Display symbol for rain sensor On.

AUTOMATIC CONTROL

In AUTO mode the ECC system controls all

functions automatically making driving simpler

with optimum air quality.

Automatic

Press AUTO for automatic control of set

temperature and other functions.

Temperature

Press for individual adjustment of left L

or right-hand Rside. Turn to required

temperature. The set temperature is shown

in the display.

ELECTRONIC CLIMATE CONTROL, ECC*

WARNING

Incorrect use could endanger life. Consult

the Owner's Manual if you have the slightest

doubt about its use.

MANUAL CONTROL

Fan speed

Air distribution

Defroster to quickly remove misting

from the windscreen and side windows.

Air quality system* On A.

Recirculation On M.

Air conditioning On/Off.

Rear window and door mirror defrost-

ers. Automatic deactivation1.

PACOS*, DEACTIVATING THE AIRBAG

PACOS (Passenger Airbag Cut Off Switch)

Use the ignition key to switch ON/OFF.

OFF: The airbag is deactivated.

PASSENGER AIRBAG OFF is shown in the

warning lamp above the interior rearview mirror.

A child can sit on a booster cushion or child

seat in the front seat but never passengers

taller than 140 cm.

ON: The airbag is activated.

Passengers taller than 140 cm can sit in the

front seat but never a child on a booster

cushion or child seat.

1. Rear window 12 minutes. Mirrors 6 minutes.

FUEL

Low fuel level

8 litres petrol (7 litres diesel) remain.

Fuel gauge.

The arrow indicates that the fuel filler flap

is on the right-hand side.

TRIP METERS

Display shows two independent trip

meters, T1 & T2.

Switch between T1 & T2 with one short

press. Reset the current meter with one

long press.

TRIP COMPUTER ANDTRIP METERS

INDICATOR AND WARNING LAMPS

Read in information display ABS fault. Stop safely. Restart the

engine1.

Stop safely. Rectify in accordance

with the information display.

Fault in brake system. Stop safely.

Check the brake fluid2.

Low oil pressure. Stop safely. Check

the oil level2.

DSTC* Stability system. Flashes

when the system is operating.

TRIP COMPUTER

Press to clear a message.

Turn to show e.g. KILOMETRES TO

EMPTY TANK in the display (4).

Reset the current function. One long

press resets all functions.

IMPORTANT

KILOMETRES TO EMPTY TANK is an esti-

mate based on earlier driving conditions.

1. Contact a Volvo workshop if the symbol illuminates after restart. 2. Have the car towed if the symbol

remains visible.

LOWERINGTHE REAR SEAT BACKRESTS

A. Hang the seatbelt up in the coat hanger.

B. Fold up the seat cushion.

C. Disengage the catch in the backrest and fold

forward.

D. Disengage the catch in the head restraint.

E. Transfer the head restraint to the sleeves on

the underside of the seat cushion.

F. Lower the backrest.

The front passenger seat can also be lowered. See

ADJUSTING THE FRONT SEAT in point (6).

Press the button to open the fuel filler flap.

Hang up the fuel filler cap during refuelling.

REFUELLING DIESEL PARTICLE FILTER

BLIS – BLIND SPOT INFORMATION

SYSTEM* EMERGENCY BRAKE ASSIST, EBA

If the BLIS indicator lamp illuminates despite

there being no vehicle within the blind spot,

the cause could be for example, reflection

from shiny wet road surface, own shadow on

light road surface or low sun in the camera.

In the event of a direct fault in the system

the display shows the text BLIS SERVICE

REQUIRED.

Diesel cars are equipped with a particle

filter, which results in more efficient emission

control. The particles in the exhaust gases are

collected in the filter during normal driving.

So-called "regeneration" is started automati-

cally in order to burn away the particles and

empty the filter. Engine power may be slightly

reduced during regeneration.

Emergency Brake Assistance helps to

increase brake force and so reduce braking

distance. EBA is activated when the driver

brakes suddenly. When EBA is activated the

brake pedal lowers slightly more than usual,

depress (hold) the brake pedal as long as

necessary. If the brake pedal is released then

all braking ceases.

ADJUSTINGTHE FRONT SEAT

STORAGE SPACES, 12 V SOCKET & AUX

Lumber support

Backrest rake

Raise/lower seat

Seat cushion front edge raise/lower

Forwards/backwards

Lowering the passenger seat backrest

12 V socket in centre console front/rear

works in ignition position Ior II. 12 V socket on

right-hand side in cargo area* is always active.

The car's audio system can playback music

from an MP3 player etc. using the AUX output.

BAG HOLDER*

IMPORTANT

Using the 12 V socket in the cargo area when

the engine is switched off could discharge

the battery.
