Volvo S 60 2014 Manuel utilisateur

QUICK GUIDE

WEB EDITION

Climate system controls

Headlamp control

Combined instrument panel

Infotainment system

Phone*

Internet*

External audio device

Buttons in the centre console

Settings in the menu system

Workshop/booking service*

ECO*

Refuelling

Car care

Storage spaces

AUX/USB* and 12 V sockets

04 Functions in your car

05 Tips

Adjusting the seat

Adjusting the steering wheel

Folding the rear seat

Park Assist Pilot*

Lane Keeping Aid*

Start/Stop function*

Pedestrian protection*

02 Driver support in your car

03 Your driving environment

Remote control key

Keyless* lock system

Starting and switching off the engine

Parking brake

Wipers

01 Starting and driving

WELCOME TO YOUR NEW VOLVO!

This folder contains a selection of the most common functions in your particular car. The owner's manual and

other manuals contain safety instructions and all warning, important and note texts.

The following symbols mean:

Different parts are pointed out in the overview images.

Step–by–step instructions.

It is particularly important to read the owner's manual.

Warning, important and note texts, that must be read, are included on the last page.

Options are marked with an asterisk *.

The owner's manual is available as a printed manual and digitally in the car's screen, on the Web and as a

mobile app. The mobile app contains the whole owner's manual as well as instruction films and has several

search paths with text and illustrations. The mobile app can be downloaded to mobile devices from App Store or

Google play.

In addition, learn more about your car at www.volvocars.com.

How does the remote control key work?

Unlocks the doors and boot lid and disarms the

alarm. The function can be set in MY CAR.

Locks doors and boot lid and arms the alarm.

Approach light duration.

One press unlocks the boot lid, two presses open it

slightly.

Information*.

Panic function.

The remote control key can store settings for,

amongst other things, door mirrors and power

driver's seat* – see owner's manual.

How does the Keyless* lock system work?

The remote control key can remain in a pocket, for exam-

ple, the whole time.

Lock and arm the alarm

– Touch the rear section of one of the outer door handles

or press lightly on the smaller of the boot lid's two rub-

berised buttons.

Unlock and disarm the alarm

– Grip a door handle and open the door in the usual way

or press lightly on the larger of the boot lid's two rub-

berised buttons.

How do I start or switch off the engine?

Starting

Push the remote control key into the ignition switch

(does not apply to Keyless drive*).

Depress the clutch or brake pedal.

Briefly press the START/STOP ENGINE button.

Switching off

Briefly press the START/STOP ENGINE button.

Take the remote control key out from the ignition

switch.

How do I use the parking brake? 01

To apply

– Press the control PUSH LOCK/PULL RELEASE – the

symbol starts to flash. Once there is a constant glow

the parking brake is applied.

To disengage

Depress the foot brake pedal.

Pull the control PUSH LOCK/PULL RELEASE.

Disengage automatically

– Drive away (for cars with automatic gearbox, the seat-

belt must be buckled).

How do I start the windscreen wipers and rain

sensor*?

Move the lever downward to start the windscreen wipers

and upward for a single sweep.

Rain sensor On/Off.

Regulates the sensor sensitivity or the intermittent

delay.

How do I use Park Assist Pilot PAP*?

PAP checks the available space, and then steers in the

car. Your task is to select the gear, control the speed and

brake/stop.

Activate PAP with a press of the button. Do not drive

faster than 30 km/h.

Follow the instructions that are shown in the com-

bined instrument panel.

Be prepared to stop the car when the graphics and

text advise this.

To lift up the wiper blades they must be in service

position – see owner's manual.

What is the function of Lane Keeping Aid LKA*?

If the car is about to cross a side line the LKA will actively

steer back into the lane with a slight steering torque in the

steering wheel. If the car crosses a side line then LKA will

warn you with pulsating vibration in the steering wheel.

– Activate LKA with a press of the button.

It is important to understand this function – see

owner's manual.

Collision Warning with Auto Brake and Cyclist and Pe-

destrian Detection, which can warn, brake and/or stop for

vehicles, cyclists and pedestrians.

The function is only an aid and does not work in all situa-

tions – for example, it does not see cyclists from the side

and pedestrians who are shorter than 80 cm or who are

partially obscured.

How does the pedestrian protection work*? 02

How do I use the Start/Stop function*? 02

Manual gearbox

Stop the engine: Declutch, move the gear lever into neu-

tral position and release the clutch pedal.

Start the engine: Depress the clutch pedal.

Automatic gearbox

Stop the engine: Stop the car with the foot brake and then

maintain the brake pressure.

Start the engine: Release foot pressure on the foot brake.

Illuminated button lamp indicates that the function is

active.

How do I adjust the steering wheel?

Release the catch.

Adjust the steering wheel forward/backward and up/

down.

Activate the catch.

How do I adjust the seat?

Raise/lower the front of the seat cushion.

Raise/lower the seat.

Move the seat forward/backward.

Tilt the backrest.

Lumbar support* adjustment.

Storing settings for power seat*.

Memory buttons for power seat*.

Store setting:

Hold the button depressed to store settings while

depressing one of the memory buttons. Hold the buttons

depressed until a signal is heard and text is shown in the

combined instrument panel. This stores the position of the

seat as well as the door mirrors. The position of the lumbar

support is not stored.

The position for the door mirrors, and memory

settings (not lumbar support) for the power seat,

can also be stored in the remote control key* – see

owner's manual.

How do I fold the rear seat backrests?

Lowering the head restraints – see the owner's

manual.

The two-section backrest can be folded forward – both

sections together or separately.

Pull on the required handle. They are located just

inside the hatch opening.

Fold the backrest forward. Fully lower the centre

head restraint if the wide section of the backrest

shall be folded down.

How do I defrost the windscreen? 04

How do I regulate the temperature? 04

Turn for individual temperature in the left/right-hand

area of the passenger compartment. The screen

shows the selected temperature.

Press AUTO for automatic control of air distribu-

tion and other functions. The screen shows AUTO

CLIMATE.

Press to activate the windscreen's electric heating* -

symbol (1) in the screen illuminates.

The next press also activates maximum airflow

against windscreen and side windows - symbols (1)

and (2) illuminate.

The next press switches off both of the functions –

no symbol illuminates.

Without electric heating: Press to activate/deactivate the

air flow.

How does the headlamp control's auto mode

work?

AUTO mode provides the following options:

• The daytime running lights automatically switch

between daytime running lights and dipped beam.

• Main beam can be activated when dipped beam is

switched on.

• Active high beam (AHB)* – that dims and activates main

beam automatically, or adapts the main beam pattern to

traffic conditions – can be used.

• Tunnel detection* is activated.

How is the trip computer operated?

OK opens the trip computer's menus, activates

selected option and extinguishes messages.

Thumbwheel scrolls between the trip computer op-

tions.

RESET resets data in the selected trip computer

step and goes back in the menu structure.

How do I reset the trip meter?

Turn the left-hand stalk switch thumbwheel to show

trip meter T1 or T2.

Give a long press on the RESET button in order to

reset the trip meter shown.

How do I navigate in the infotainment system?

Press RADIO, MEDIA, MY CAR, NAV*, TEL* or *to

select the main source. The normal view for the last

active source is shown in this position.

Press OK/MENU or the thumbwheel* in the steering

wheel to access the selected source's main menu.

Turn TUNE or the thumbwheel to navigate in the

menus.

Press OK/MENU or the thumbwheel to make a

selection in the menus.

Briefly press EXIT to go back in the menu system,

cancel a function or delete entered characters.

Give a long press on EXIT to go back to normal view,

or to go from normal view to the main source view.

Tips:

To go to the shortcut menu from normal view, press once

on the main source button. Press again to go back to

normal view.

How do I switch on and off the Infotainment

system?

A short press activates the system.

A long press (until the screen switches off) deacti-

vates.

To switch off the sound: Give a short press - the next

press reactivates.

Note that the whole of the Sensus system (including

navigation* and phone functions*) is started/switched off

at the same time.

For more information about operating the system –

see owner's manual.

In the normal view for the phone source, press OK/

MENU.

Select Make car discoverable and confirm with

OK/MENU.

Activate Bluetooth®in the mobile phone. Search for

and connect the car to the phone.

Follow the instructions in the phone and the screen.

The phone is now connected and can be controlled from

the car.

How do I connect a Bluetooth®phone*?

How do I connect to the Internet*? 04

What services do I get with Volvo ID*? 04

For further information about Volvo ID - see owner's

manual.

Volvo ID is your personal ID registered to the car which

can give you access to various services such as My Volvo

web and the facility to send an address from the map

service on the Internet directly to the vehicle.

Press the Connect button .

Select Apps > Settings and follow the onscreen

instructions.

If registering the phone does not succeed – see

owner's manual.

For more information about connection - see

owner's manual.

Connect the mobile phone to the car (see "How do

I connect a Bluetooth®phone?") and activate tether-

ing in the phone.

In the normal view for the MY CAR source, press

OK/MENU, select Settings > Internet settings >

Connect through.Select one of the options Car

modem,Wi-Fi or Bluetooth.

In future the car will automatically connect via the selected

Internet connection.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Volvo Automobile

Volvo

Volvo V70 SPORT Guide de démarrage rapide

Volvo

Volvo FMX 400 6x4 T RSS Prime Mover Guide d'installation

Volvo

Volvo S80 - Manuel utilisateur

Volvo

Volvo 262 Manuel utilisateur

Volvo

Volvo S60 - ANNEXE 931 Manuel utilisateur

Volvo

Volvo 240 1975 Manuel utilisateur

Volvo

Volvo B5244S4 Manuel utilisateur

Volvo

Volvo XC60 - ANNEXE 541 Manuel utilisateur

Volvo

Volvo V40 Manuel utilisateur

Volvo

Volvo XC60 RECHARGE 2021 Manuel utilisateur

Volvo

Volvo S80 - Manuel utilisateur

Volvo

Volvo S80 - Manuel utilisateur

Volvo

Volvo C70 BROCHURE 2 Manuel utilisateur

Volvo

Volvo V40 Manuel utilisateur

Volvo

Volvo 7601990 Manuel

Volvo

Volvo V70 SPORT Manuel utilisateur

Volvo

Volvo 2010 S40 Manuel utilisateur

Volvo

Volvo 2003 XC90 Manuel utilisateur

Volvo

Volvo C30 2012 Manuel utilisateur

Volvo

Volvo S90 2019 Manuel utilisateur

Volvo

Volvo V90 CROSS COUNTRY Manuel utilisateur

Volvo

Volvo 2011 S60 Manuel utilisateur

Volvo

Volvo C30 - ANNEXE 798 Manuel utilisateur

Volvo

Volvo 2001 V70 Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur
