WELCOME TO YOUR NEW VOLVO!

Getting to know your car is an exciting experience.

After looking through this Quick Guide you'll like your new Volvo even

more. You can find detailed information in the Owner's Manual.

Warning texts and other important information are only available in the

Owner's Manual, not in this folder. The Owner's Manual contains the

most up-to-date information.

Options are marked with an asterisk (*).

VOLVO C30

Quick Guide

AUTOSTART (APPLIES TO 2.4I, T5 AND D5)

Turn the ignition key/dial to position III and

release. The engine starts automatically.

Diesel engines must always be preheated in

position II before the engine is started.

KEY BLADE

Used to lock/unlock the glovebox or the driver's

door lock, e.g. if car is without electrical power.

1. Automatic relocking takes place if a door/boot lid is

not opened within 2 minutes after unlocking.

2. The time is adjustable to 30, 60 or 90 seconds, see

Owner's Manual.

COLD START

NOTE

The idling speed may briefly be slightly higher

in order to achieve efficient emission control.

KEY & REMOTE CONTROL

Locks doors and boot lid and arms the

alarm*.

Unlocks doors and tailgate1and dis-

arms the alarm.

Unlocks tailgate. (Tailgate does not

open.)

Switches on lighting for 30 seconds2

in side mirrors*, in cabin, by feet and on

number plate. Indicators and parking

lamps illuminate.

"Panic" button. Press and hold for

approx. 3 seconds in an emergency to

trigger the alarm. Switch off the alarm

with the unlock button.

DIRECTION INDICATORS

A. Short sequence, three flashes.

B. Continuous flash sequence.

WARNING! Adjust the steering wheel before

setting off, never while driving.

ADJUSTING THE STEERING WHEEL

CONTROL PANEL IN DRIVER'S DOOR

L R

Adjusting the door mirrors, select L

or R. Set with the lever.

Retracting the door mirrors*. Press

Land Rsimultaneously. Press again

to extend.



Manual windows

Automatic windows

LIGHT SWITCHES

WINDSCREEN WIPERS AND RAIN SENSOR*

Headlamp levelling (automatic for

Bi-Xenon lights*)

Automatic dipped beam. Main beam

flash. Main beam cannot be activated.

Parking lamps

Dipped beam. Dipped beam switches

off when the ignition is switched off.

Main beam can be activated.

Display and instrument lighting

Front fog lamps*

Rear fog lamp (one rear lamp)

Main beam flash

Main/dipped beam switching.

Approach lighting.

Single sweep

Off

Intermittent wiping. Turn (2) to adjust.

Normal speed

High speed

Windscreen and headlamp washing

Rear window washer

Rear window wiper intermittent/normal

Activates rain sensor. Position D–F

deactivates rain sensor.

Adjust sensitivity using the thumb-

wheel.

Display symbol for rain sensor On.

AUDIO SYSTEM

REFUELLING

Diesel cars are equipped with a particle filter,

which results in more efficient emission con-

trol. The particles in the exhaust gases are

collected in the filter during normal driving.

So-called "regeneration" is started automati-

cally in order to burn away the particles and

empty the filter. Engine power may be slightly

reduced during regeneration.

DIESEL PARTICLE FILTER

Washing by hand is gentler to the paintwork

than an automatic car wash. The paintwork

is also more sensitive when it is new. For this

reason, handwashing is recommended during

the first few months with a new car.

Paint treatments such as preservation treat-

ments, sealing, protective treatments, lustre

sealing etc. may damage the paintwork.

Damage caused by such treatments is not

covered by Volvo warranty.

CAR CARE

On/Off and audio volume. Press for

On/Off. Turn to adjust the audio volume.

Radio, TP, handsfree* and RTI* volume are

stored individually.

FM1, FM2 or AM radio

MODE. CD or AUX1*

Sound pattern. Press to select e.g. BASS

and Dolby Pro Logic II*. Turn to adjust.

MENU. AUX* volume and advanced audio

settings.

RADIO

Select radio station by turning.

Search for station using Left/Right arrow

or SCAN (7). Store up to 20 stations by

holding in 0–9 on FM1 and 0–9 on FM2.

When a station has been stored it is con-

firmed in the display.

Autostoring stations

Press AUTO for approx. 2 seconds. Auto-

storing is shown in the display. The ten

strongest stations are stored. Then press

0–9 to select a station.

CD PLAYER

Change CD track using Left/Right arrow

or turn (5).

Select CD disc2using Up/Down arrow.

Ejecting a CD disc. One short press

ejects the current disc. One long press

ejects all2.

Direct selection CD disc2.Press 1–6.

1. AUX* input for e.g. MP3 player.

2. Only CD changer*.

AUTOMATIC CONTROL

In AUTO mode the ECC system controls all

functions automatically making driving simpler

with optimum air quality.

Automatic

Press AUTO for automatic control of set

temperature and other functions.

Temperature

Press for individual adjustment of left L

or right-hand Rside. Turn to required

temperature. The set temperature is shown

in the display.

1. Rear window 12 minutes. Mirrors 6 minutes.

ELECTRONIC CLIMATE CONTROL, ECC*

WARNING

Incorrect use can endanger life. Consult the

Owner’s Manual in the event of the smallest

uncertainty regarding usage.

MANUAL CONTROL

Fan speed

Air distribution

Defroster to quickly remove misting

from the windscreen and side windows.

Air quality system* On A.

Recirculation On M.

Air conditioning On/Off

Rear window and door mirror defrost-

ers. Automatic deactivation1

PACOS*, DEACTIVATINGTHE AIRBAG

PACOS (Passenger Airbag Cut Off Switch)

Use the ignition key to switch ON/OFF.

ON: The airbag is activated.

Passengers taller than 140 cm can sit in the

front seat but never a child on a booster

cushion or child seat.

OFF: The airbag is deactivated.

PASSENGER AIRBAG OFF is shown in the

warning lamp above the interior rearview mirror.

A child can sit on a booster cushion or child

seat in the front seat but never passengers

taller than 140 cm.

FUEL

Low fuel level

8 litres petrol (7 litres diesel) remain.

Fuel gauge

The arrow indicates that the fuel cap is on

the right-hand side.

TRIP METERS

Display shows two independent trip

meters, T1 & T2.

Switch between T1 & T2 with one short

press. Reset the current meter with one

long press.

CLOCK

Turn to stop and hold to set the clock (6).

TRIP COMPUTER ANDTRIP METERS

INDICATOR AND WARNING LAMPS

Read in information display ABS fault. Stop safely. Restart the

engine1.

Stop safely. Rectify in accordance

with the information display.

Fault in brake system. Stop safely.

Check the brake fluid2.

Low oil pressure. Stop safely.

Check the oil level2.

DSTC* Stability system. Flashes

when the system is operating.

TRIP COMPUTER

Press to clear a message.

Turn to show e.g. KILOMETRES TO

EMPTY TANK in the display (7).

Reset the current function. One long

press resets all functions.

IMPORTANT

KILOMETRES TO EMPTY TANK is an esti-

mate based on earlier driving conditions.

1. Contact a Volvo workshop if the symbol illuminates after restart. 2. Have the car towed if the symbol

remains visible.

CARGO COVER*

HARD CARGO COVER*

Installation

Pull all four lock buttons backwards to their

end positions. Carefully lift in the cargo cover,

position the front section on the two supports

behind (A) on both sides.

HOLDER FOR FLOOR HATCH

Fasten the hooks at the floor (A).

Press together the spring-loaded rail and affix

the brackets at (B) on both sides.

Affix the brackets at (C) in the same way.

Fasten the hooks at (D).

Undo the attachment points (D), and (C) if

necessary, on both sides during loading.

Undo (D), (C), (B) and (A) and roll up the cargo

cover when not in use.

Floor hatch in open position without/with cargo

cover.

Align one rear lock at (B) and press the lock

button forwards. Lock the three remaining ones

in the same way.

Removal

First pull the lock buttons at (A), then at (B),

backwards to their end positions. Take out the

cargo cover.

LOWERINGTHE BACKREST

ADJUSTING THE FRONT SEAT

STORAGE SPACES, 12 V SOCKET & AUX*

Lumber support

Backrest rake

Raise/lower seat

Seat cushion front edge raise/lower

Forwards/backwards

Using the AUX* output the car's audio system

can playback music from an MP3 player etc.

12 V socket front/rear works in

ignition position I or II.

Easy entry & seatbelt guide

Manual seat

A. Remove the seatbelt from the belt guide.

B. Pull the handle and move the seat forwards.

Move the seat backwards, pull the handle

and fold back the backrest.

Power seat*

A. Remove the seatbelt from the belt guide.

B. Pull the handle and fold up the backrest.

C. Hold the button in while the seat travels

forwards.

Hold the button in again so that the seat

moves back.
