VOLT®Low Voltage Landscape Lighting

VOLT®Shine Stone 6x9 LED Paver Light

VHS-605-4-FPG

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

reserved. [email protected] • 813.978.3700

–1–

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT®Shine Stone 6x9 LED Paver Light

VHS-605-4-FPG

Important: Please Read Before Installation

INSTALLATION INSTRUCTIONS

www.voltlighting.com [email protected] • 813.978.3700

Package Contents

A. (1) Fixture

Product Dimensions

9”

6”

2.25”

Important Safety Instructions

LIGHTED LAMP IS HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before reducing lamp.

2. Lamp gets HOT quickly!

3. Do not touch the hot lens, guard or cowl.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time.

6. Use a soft cloth.

7. Oil from skin may damage lamp.

8. Do not operate the xture with a damaged or missing lens or shield.

Wire Connections

Install Fixture

Strip both leads from the luminaire pigtail. Using two wire

connectors (sold seperately), connect the leads from the luminaire

to the main supply cable leads.

Determine the location for the

xture. Leave a rectangular slot

in pavers (size: 6”W x 9”L x 2.5”

Deep) and place the xture into

the the slot. It will take the place

of a single paver of equal size.

Pigtail

Fixture

Main Supply Cable

Paver

Wire Connectors

(sold seperately)

–2– –3–

This xture is intended for installation in accordance with local codes

and the National Electric Code (NEC). Failure to adhere to these codes

and instructions may result in serious injury, property damage and void

the warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situation.

1. Make sure that the power is turned OFF before installing or servicing

this xture.

2. Warning: this xture is not intended to be installed within 10 feet [3

meters] of a pool, spa or fountain.

3. This xture is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in

order to connect to the main low voltage cable.

5. Wiring connections must be made with UL Listed wire connectors that

are suitable for outdoor use.

6. Position the wire connector so that it is located within 6 inches (15.2

cm) from a building structure, a luminaire, or tting.

is-VHS-605-FPG-ver2.pdf

Specications and product details subject to change without notice.

reserved. [email protected] • 813.978.3700

www.voltlighting.com

–4–

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
