Vivo MOUNT KB05D Manuel utilisateur

Tool Required

phillips screwdriver

Package Content

Scan the QR code with your mobile device or follow the link

to helpful videos and specifications related to this product.

- -http//vivo u.com/product/mount kb05d

F (x1)

mm Allen Key

A (x2)

Clamp Bracket

D (x4)

M4 Screw

E (x8)

M Screw

B (x2)

Keyboard Rail

C (x1)

Keyboard Tray

Step 1

Mount the keyboard rails

(B) to the bottom of the

keyboard tray (C) using M

screws (E). NOTE: Make

sure long ends of rails are

facing towards the long

end of the keyboard tray.

eyboard Tray

Instruction Manual

Email: [email protected]

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

-Model MOUNT B05D

Step 2

Step 3

Step 4

Mount clamp brackets (A) to

keyboard rails (B) using M4

screws (D) at one of the four

height positions.

Clamp the

assembled

keyboard mount to

the desktop.

Adjust support pads on the back of the

mount, and secure adjusted height by

tightening the nut on each support pad

screw using mm Allen Key (F).

If you do not understand these directions, or if you have any

doubts about the safety of the installation, please call a

qualified technician. Check carefully to make sure there are no

missing or defective parts. Improper installation may cause

damage or serious injury. Do not use this product for any

purpose that is not explicitly specified in this manual. We

cannot be liable for damage or injury caused by improper

mounting, incorrect assembly, or inappropriate use.

Email: help@vivo-us.com

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

For more VIVO products, check out our

website at

www.vivo-us.com.

If any parts are received damaged or defective, please contact

us. We are happy to replace parts to ensure you have a fully

functioning product.

Safety Warning

Contact u at

Last updated: 0 /16/2018

NOTE: To ensure

keyboard tray (C)

is level, do not

over-tighten clamps.
