Vig535b

Motherboard

Manual

Vig535b Motherboard Manual 1

Viglen,EMCandthe‘CE’mark

CE Marking

European standards are being harmonised across borders. If products comply with the same standards in all

European countries, product exporting and importing is made simple - paving our way to a common market. If

you buy a product with a 'CE' mark on it (shown below), on the box, in the manual, or on the guarantee - it

complies with the currently enforced directive(s).

Introduction to EMC

EMC (Electromagnetic Compatibility) is the term used to describe certain issues with RF (Radio Frequency)

energy. Electrical items should be designed so they do not interfere with each other through RF emissions. E.g.

If you turn on your microwave, your television shouldn't display interference if both items are CE marked to the

EMC directive.

If emitted RF energy is not kept low, it can interfere with other electrical circuitry - E.g. Cars Automatic Braking

Systems have been known to activate by themselves while in a strong RF field. As this has obvious

repercussions ALL electrical products likely to cause RF related problems have to be 'CE' marked from 1st

January 1996 onwards.

If a product conforms to the EMC directive, not only should its RF emissions be very low, but its immunity to RF

energy (and other types) should be high. The apparatus has to resist many 'real world' phenomena such as

static shocks and mains voltage transients.

Viglen’s Environment laboratory

To gain a 'CE' mark, the Viglen computer range has had to undergo many difficult tests to ensure it is

Electromagnetically Compatible. These are carried out in the in-house 'Environment lab' at Viglen Headquarters.

We have made every effort to guarantee that each computer leaving our factory complies fully with the correct

standards. To ensure the computer system maintains compliance throughout its functional life, it is essential you

follow these guidelines.

Install the system according to Viglen’s instructions

If you open up your Viglen:

Keep internal cabling in place as supplied.

Ensure the lid is tightly secured afterwards

Do not remove drive bay shields unless installing a 'CE' marked peripheral in its place

The clips or ‘bumps' around the lips of the case increase conductivity - do not remove or damage.

Do not remove the ferrite ring from the L.E.D cables.

Only use your Viglen computer with 'CE' marked peripherals

This system has been tested in accordance with European standards for use in residential and light industrial

areas-this specifies a 10 meter testing radius for emissions and immunity. If you do experience any adverse

affects which you think might be related to your computer, try moving it at least 10 meters away from the affected

item. If you still experience problems, contact Viglen’s Technical Support department who will put you straight

through to an EMC engineer - s/he will do everything possible to help. If modifications are made to your Viglen

computer system, it might breach EMC regulations. Viglen take no responsibility (with regards to EMC

characteristics) of equipment which has been tampered with or modified.

Vig535b Motherboard Manual 2

CopyrightsandTrademarks

Please note

The material in this manual is subject to change without notice.

Trademarks

Microsoft, Windows, Windows NT, Windows 95,Windows 98, Windows ME,

Windows 2000 Pro, Windows XP Pro and MS-DOS are registered trademarks of

Microsoft Corporation. IBM PC, XT, AT and PS/2 are trademarks of International

Business Machines Corporation. Pentium® and Pentium® Pro are registered

trademarks of Intel® Corporation. AMI BIOS is a registered trademark of American

Megatrends. All other trademarks are acknowledged. JAC-UP, Genie, Contender,

Dossier, Vig, Viglen, and Envy are trademarks of Viglen Limited.

This manual and all accompanying software and documentation are copyrighted and

whole or in part, be copied, photocopied, translated or reduced to any electronic or

machine-readable form, without prior written consent except for copies retained by

the purchaser for backup.

VIG535B Manual Version 1.0

Printed in the United Kingdom

Liability

No warranty or representation, either expressed or implied, is made with respect to

this documentation, its quality, performance, merchantability or fitness for a particular

purpose. As a result the documentation is licensed as is, and you, the licensee, are

assuming the entire risk as to its quality and performance. The vendor reserves the

right to revise this operation manual and all accompanying software and

documentation and to make changes in the content without obligation to notify any

person or organisation of the revision or change.

In no event will the vendor be liable for direct, indirect, special, incidental or

consequential damages arising out of the use or inability to use this product or

documentation, even if advised of the possibility of such damages. In particular, the

vendor shall not have liability for any hardware, software or data stored or used with

the product, including the costs of repairing, replacing or recovering such hardware,

software or data.

Vig535b Motherboard Manual 3

Contents

Chapter 1: Motherboard Overview 5

Introduction 5

Feature Summary 6

System Board Components 15

Overview of System Board Components 16

Back Panel Connectors 20

Chapter 2: System Board Options 22

Overview of Jumper Settings 24

System Board Jumper Settings 25

Motherboard Connectors 27

Front Panel Connectors 28

Upgrading the CPU 29

Installing & Removing Memory Modules 30

Expansion Slots (PCI & AGP) 31

Replacing the Clock/CMOS RAM Battery 33

Chapter3:SolvingProblems 34

ResettingtheSystem 34

Troubleshooting Procedures 35

Problems Operating Add-in Boards 36

Problems & Suggestions 37

Chapter4:SystemBIOS 39

What is the BIOS? 39

The Power-On Sequence 39

Phoenix BIOS – Introduction 40

BIOSUpgrades 40

Using AWDFALSH to Update the BIOS 40

Configuring the Motherboard using BIOS Setup 42

BIOSSetupProgram 43

BIOS Menu Screen 44

MainMenu 45

Vig535b Motherboard Manual 4

Main Menu items 45

Standard CMOS Features 46

Advanced BIOS Features 49

Advanced Chipset Features 51

DRAMTimingControl 51

AGP & P2P Bridge Control 52

OnChipAGPControl 53

VGAShareMemorySize 53

Integrated Peripherals 54

OnChipIDEDevice 54

OnChipPCIDevice 55

Onboard Super I/O Device 56

Onboard PCI Device 57

Power Management Setup 58

PMWakeupEvents 59

PnP/PCI Configurations 60

IRQResources 60

PCHealthStatus 62

Frequency/Voltage Control 63

Main Menu Additional Options 64

Chapter 5: Technical Information 65

Enhanced IDE 65

Operating Systems and Hard Drives 65

Power Supply Connector 67

Other Useful Connectors 67

OtherInformation 71

Reliability 71

Temperature 71

Chapter6:Glossary 72

Notes 74

Chapter7:Suggestions 75

Vig535b Motherboard Manual 5

Chapter1:MotherboardOverview

Introduction

This manual describes the Viglen VIG535B motherboard inside your computer. The

motherboard is the most important part of your computer. It contains all of the CPU,

memory and graphics circuitry that make the computer work.

The motherboard contains the very latest CPU design that supports the Intel®

Pentium® 4 family including Hyper-Threading enabled CPU’s and the very latest

Extreme Edition CPU’s. All of the supported CPU’s include Intel’s® MMX

Technology. MMX technology adds a total of 57 new instructions to the CPU, all of

which are designed to vastly improve both multimedia and communications on your

PC. The combination of the Intel® processor, MMX technology and Viglen expertise

make this a formidable computer.

This manual contains technical information about the Viglen VIG535B motherboard

and other hardware components inside your computer. If you are new to computers

we recommend that you read the user guide first. If you are an experienced

computer user this manual should provide all the information you will need to

perform simple upgrades and maintenance.

We hope that this manual is both readable and informative. If you have any

comments for suggestions about how we could improve the format then please fill

out the form at the back of the manual and send it to us.

Above all we hope that you enjoy using your Viglen computer.

Vig535b Motherboard Manual 6

Feature Summary

The Vig535b motherboard supports Intel® Pentium® 4 and Celeron® processors

with up to 1MB of second-level cache integrated in a micro PGA 478 Socket

package operating at speeds up to 3.4GHz.

The motherboard features:

Form factor:

•Micro ATX Form Factor: 243mm by 230mm

Processor:

•Single Pentium 4 CPU

•400/533/800MHz Quad-pumped bus

•Integrated 128, 256, 512 and 1000KB second-level cache

•Socket 478 connector.

Main memory:

•Four 184-pin DDR DIMM sockets.

•Support for up to 2GB of DDR DIMM memory.

Chipset

•SiS 661FX

•800Hz Front Side Bus (FSB)

•AGP 8x

•Support for 266/333/400MHz DDR RAM

•Advanced System Power Management features

•Integrated Super I/O Controller

•DirectSound AC97 Audio

•Dual bus master IDE Ultra DMA33/66/100/133

Audio

Audio Codec ’97 (AC ’97) compatible audio subsystem

LAN

Realtek 10/100 Mbit/sec Platform LAN Connect (PLC) device

Vig535b Motherboard Manual 7

Peripheral Interfaces

•Support for two Universal Serial Bus (USB) ports

•One serial port

•One parallel port

•Two IDE interfaces with Ultra DMA 33, ATA66/100/133 support.

•One diskette drive interface

•PS/2 keyboard and mouse ports

Expansion Capabilities

•Three PCI bus add-in card connectors

•One AGP Pro connector

Instantly Available PC

•Support for PCI Local Bus Specification Revision 2.2

•Suspend to RAM support

•Wake on PS/2 keyboard and USB ports

Wake on LAN Technology Connector

•Support for system wake up using an add-in network interface card with

remote wake up capability

Microprocessor

The motherboard supports a single Pentium 4 processor with HT technology. The

processor’s VID pins automatically program the voltage regulator on the

motherboard to the required processor voltage. In addition, the front side bus speed

is automatically selected. The motherboard currently supports processors that run

internally up to 3.4GHz and have a 128KB, 512KB or 1MB second-level cache

running at full CPU Speed.

The processor implements MMX ™ technology and maintains full backward

compatibility with the 8086, 80286, Intel386 ™, Intel486 ™, Pentium, Pentium Pro,

Pentium II & Pentium III processors. The processor’s numeric coprocessor

significantly increases the speed of floating-point operations and complies with

ANSI/IEEE standard 754-1985.

Microprocessor Packaging

The Pentium 4 processor comes in a FC-PGA package that connects to the

motherboard through a socket 478 connector. The package consists of:

•Processor card including the processor core and the second-level cache,

burst pipelined synchronous static RAM (BSRAM) and tag RAM.

•Thermal plate.

Vig535b Motherboard Manual 8

•Back cover.

Second Level Cache

The second-level cache is located on the die of the CPU itself. The cache includes

burst pipelined synchronous static RAM (BSRAM) and tag RAM. All supported

onboard memory can be cached.

Processor Upgrades

The motherboard can be upgraded with a Pentium 4 processor that runs at higher

speeds.

Memory

Main Memory

The motherboard has two DDR DIMM sockets. Minimum memory size is 128MB;

maximum memory size is 2GB. The BIOS automatically detects memory type, size,

and speed.

The motherboard supports the following memory features:

•184-pin DIMMs.

•266/333/400Mhz

•Un-Buffered Non-ECC DIMM.

RDRAM

Synchronous DRAM (SDRAM) improves memory performance through memory

access that is synchronous with the memory clock. This simplifies the timing design

and increases memory speed because all timing is dependent on the number of

memory clock cycles.

Chipset

The SiS 661FX chipset is the latest generation of desktop PCI set, it includes new

features such as –

•8x AGP Support

•ATA-133 IDE Hard drive support

•800MHz Front Size Bus support

•ACPI & On-Now

Vig535b Motherboard Manual 9

Accelerated Graphics Port (AGP)

The Vig535b features both integrated graphics and an AGP port. When using the

integrated graphics then a dynamic portion of the main system memory is used as

video memory. There is an optional GPA (Graphics Performance Accelerator)

modules which has a dedicated 4MB of video memory. You can also use any AGP

video card, with 4x/8x AGP performance.

The Accelerated Graphics Port (AGP) is a high-performance interconnect for

graphic-intensive applications, such as 3D applications. AGP is independent of the

PCI bus and is intended for exclusive use with graphical-display devices. AGP

overcomes certain limitations of the PCI bus related to handling a large amount of

graphics data with the following performance features:

•Pipelined-memory read and write operations that hide memory access

latency.

•Demultiplexing of address and data on the bus for near 100 percent bus

efficiency.

•AC timing for 133 MHz data transfer rates, allowing data throughput of 500

MB/sec.

Realtek 8100C Platform LAN Connect Device

The Realtek 8100C component provides an interface to the back panel RJ-45

connector with integrated LEDs. This physical interface may alternately be provided

via the CNR connector.

The Realtek 8100C provides the following functions:

•Basic 10/100 Ethernet LAN Connectivity

•Supports RJ-45 connector with status indicator LEDs

•Full driver compatibility

•Advanced Power Management support

•Programmable transit threshold

•Configuration EEPROM that contains the MAC address

Table des matières

Autres manuels Viglen Carte mère

Viglen

Viglen PMPGF001 Manuel utilisateur

Viglen

Viglen Vig770S Manuel utilisateur

Viglen

Viglen PMPLM001 Manuel utilisateur

Viglen

Viglen Vig850G Manuel utilisateur

Viglen

Viglen Vig750s Manuel technique

Viglen

Viglen Vig627M Manuel utilisateur

Viglen

Viglen VIG615M Manuel utilisateur

Viglen

Viglen Vig625M Manuel utilisateur

Viglen

Viglen Vig660W Manuel utilisateur

Viglen

Viglen Vig646M-V2/W8 Manuel utilisateur

Viglen

Viglen Vig710W Manuel utilisateur

Viglen

Viglen vig830s Manuel utilisateur

Viglen

Viglen Intel D925XECV2 Manuel utilisateur

Viglen

Viglen Vig396M Manuel utilisateur

Viglen

Viglen Vig870G Manuel utilisateur

Viglen

Viglen N440BX Manuel utilisateur

Viglen

Viglen Vig410p Manuel utilisateur

Viglen

Viglen VIG610M Manuel utilisateur

Viglen

Viglen Vig860S Manuel utilisateur

Viglen

Viglen Vig430p Manuel utilisateur

Viglen

Viglen Vig580s Manuel utilisateur

Viglen

Viglen VIG590M Manuel utilisateur

Viglen

Viglen Vig642M Manuel utilisateur

Viglen

Viglen D965GF Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
