ViewSonic VS11481 Manuel utilisateur

Cine5000

DLP Projector

ViewSonic®

Model No. : VS11481

- User Guide

- Guide de l’utilisateur

- Bedienungsanleitung

- Guía del usuario

- Guida dell’utente

- Guia do usuário

- Användarhandbok

- Käyttöopas

- Pyководство пользователя

- 使用手冊

iViewSonic Cine5000

Compliance Information

For U.S.A.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) The device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy, and if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Warning

To assure continued FCC compliance, the user must use grounded power supply cord and the cables

which are included with the equipment or speciﬁed. Also, any unauthorized changes or modiﬁcations

not expressly approved by the party responsible for compliance could void the user’s authority to

operate this device.

For Canada

• This Class B digital apparatus complies with Canadian ICES-003.

• Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

For European Countries

CE Conformity

The device complies with the requirements of the EEC directive 89/336/EEC as

amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic

compaty”, and 73/23/EEC as amended by 93/68/EEC Art.13 with regard to “Safety.”

User Information for all Countries

Notice: Use the cables which are included with the unit or speciﬁed.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and Electronic

Equipment Directive 2002/96/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste, but

use the return and collection systems according to local law.

iiViewSonic Cine5000

Important Safety Instructions

1. Read these instructions completely before using the equipment.

2. Keep these instructions in a safe place.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this equipment near water. Warning: To reduce the risk of ﬁre or electric shock, do

not expose this apparatus to rain or moisture.

6. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the Display” in this

guide for further instructions.

7. Do not block any ventilation openings. Install the equipment in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other devices

(including ampliﬁers) that produce heat.

9. Do not attempt to circumvent the safety provisions of the polarized or grounding-type plug.

A polarized plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade and the third prong are provided for your

safety. If the plug does not fit into your outlet, consult an electrician for replacement of the

outlet.

10. Protect the power cord from being tread upon or pinched, particularly at the plug, and the

point where if emerges from the equipment. Be sure that the power outlet is located near the

equipment so that it is easily accessible.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the equipment. When a cart is used, use caution when

moving the cart/equipment combination to avoid injury from tipping over.

13.

Unplug this equipment when it will be unused for long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Service is required when the unit has been

damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid is spilled

onto or objects fall into the unit, if the unit is exposed to rain or moisture, or if the unit does not

operate normally or has been dropped.

iiiViewSonic Cine5000

Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.

Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft

Corporation in the United States and other countries.

ViewSonic, the three birds’ logo, OnView, ViewMatch, and ViewMeter are registered trademarks of

ViewSonic Corporation.

VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC

are trademarks of VESA.

PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation.

Disclaimer:ViewSonic Corporation shall not be liable for technical or editorial errors or omissions

contained herein; nor for incidental or consequential damages resulting from furnishing this material,

or the performance or use of this product.

In the interest of continuing product improvement, ViewSonic Corporation reserves the right to

change product specifications without notice. Information in this document may change without

notice.

No part of this document may be copied, reproduced, or transmitted by any means, for any purpose

without prior written permission from ViewSonic Corporation.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes

available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic®

Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may

mail or fax to ViewSonic.

For Your Records

Product Name:

Model Number:

Document Number:

Serial Number:

Purchase Date:

Cine5000

ViewSonic DLP Projector

VS11481

Cine5000-1_UG_ENG Rev. 1A 08-10-06

The lamp in this product contains mercury.

Please dispose of in accordance with local, state or federal laws.

ENGLISH

TABLE OF CONTENTS

1. Product Overview

1-1 Features

1-2 Package Contents

1-3 Main Unit

1-4 Control Panel

1-5 Rear Terminals

2. Installation

2-1 Turning on/off the projector

2-1-1 Starting up the projector

2-1-2 Shutting down the projector

2-1-3 LED Indication Status

2-2 Adjusting the Projector Image

2-2-1 Adjusting the Projected Height

2-2-2 Adjusting the Zoom and Focus

2-2-3 Adjusting the Projected Image Size

2-3 Operation

2-3-1 Connecting to a Personal Computer

3. Control Panel and Remote Control

3-1 Control Panel and Remote Control

3-1-1 Using Control Panel

3-1-2 Using the Remote Control

3-2 On-Screen Display Menu

3-2-1 How to Operate

3-2-2 Projector's OSD

4. Appendices

4-1 Troubleshooting

4-2 Maintenance

4-2-1 Replacing the Lamp

4-2-2 Cleaning the Projector

4-3 Specifications

9LHZ6RQLF &LQH

1-1.FEATURES

PRODUCT OVERVIEW

◆250 W P-VIP lamp. Life 2000hrs at Boost

mode, 3000hrs in Eco mode (200W).

◆High efficiency cooling system with low

system acoustic noise level.

◆Lamp is easily replaceable by user.

◆Manual zoom and focus lens with a 1:1.2

zoom ratio and 100% lens offset.

◆33" to 255" diagonal image size.

◆16.7million true colors.

◆PC compatibility: VGA / SVGA / XGA / SXGA /

MAC.

◆Video compatibility: NTSC / PAL / SECAM /

Composite / S-video / Component (YPbPr /

YCbCr) / SDTV (480i) / EDTV (480p) / HDTV

(576i, 576p, 720p, 1035i, 1080i).

◆Auto image synchronization (auto-tracking /

frequency / position adjustment / source

detect).

◆Automatically saves adjustments for future

use.

◆On-screen menu with a choice of 8 languages.

◆Built-in 2W x 1 speaker

◆Self-protection timer prevents hot re-strike of

compact P-VIP lamp.

◆Security feature: Kensington Lock.

1-2.PACKAGE CONTENTS

◆Projector x 1

◆Component Video Cable x 1

◆Remote Control x 1

◆Power Cord (US/EU)

◆AAA Batteries x 2

◆PC Audio Cable x 1

◆Owner's Manual x1

◆Soft Carry Bag x 1

◆CD Wiazrd x 1

&LQH 9LHZ6RQLF

ENGLISH

PRODUCT OVERVIEW

1-3.MAIN UNIT

DRAWING 1

DRAWING 2

DRAWING 3

DRAWING 4

DRAWING 5

IR Receiver (Front)

Projection Lens

Hot Air Exhaust

I/O Connection Panel

IR Receiver (Back)

AC Power Inlet

Power Switch

Elevator Button

Focus Ring

Zoom Ring

Control Panel

Elevator Feet

Ceiling Mount Screw Holes

Adjustable Foot

9LHZ6RQLF &LQH

1-4.CONTROL PANEL

Source

Vol+

Vol-

Boost Mode Indicator

Boost

Thermal Indicator

Power

Power Indicator

Keystone

Aspect

Cursor

DRAWING 6

PRODUCT OVERVIEW

1-5.REAR TERMINALS

Kensington Lock

Composite Video Input

Audio Input (R / L)

Component Video Input

Trigger for Screen Relay (12V)

Audio Output

S-Video Input

HDMI Input

VGA Input

DRAWING 7

Source

Vol+

Vol-

Boost

Thermal

Power

Keystone

Aspect

&LQH 9LHZ6RQLF

ENGLISH

INSTALLATION

2-1.TURNING ON/OFF THE PROJECTOR

2-1-1.STARTING UP THE PROJECTOR

1. Ensure that the supplied power cord is

securely connected at the AC inlet of the

projector (Drawing 8) and power outlet.

2. Remove the lens cap.

3. Turn on the power switch. Ensure the "Power"

indicator on the Control Panel is flashing blue,

indicating the projector is in Standby mode.

4. Turn on the Lamp by pressing the "Power"

button on the Control Panel or the "Power"

button on the Remote Control. Ensure that

the "Power" indicator is continuous blue,

indicating the projector is on.

5. The start-up screen appears on the screen

and starts to count down for 10 seconds.

6. The projector will

detect the input source

automatically.

7. Play your source

device. AC inlet

Power switch

DRAWING 8

2-1-2.SHUTTING DOWN THE

PROJECTOR

1. Turn off your source device first.

2. Press the "Power" button on the Control

Panel or press the "Power" button on

Remote Control, and a message "Power off

the projector?" will show on the screen.

3. Promptly press the "Power" button again to

confirm turning off the projector. Otherwise

the message will disappear after 5 seconds.

4. The projector will begin a 100 seconds

cooling down phase.

Note: Please don't turn off the power switch

or disconnect the power cord during the

cooling down period.

5. When the projector has cooled down, the

"Power" indicator on the Control Panel will be

flashing blue, indicating the projector is in

Standby mode.

6. Turn off the power switch. Replace the lens

cap.

7. Disconnect the power cord from the AC inlet

of the projector and power outlet.

2-1-3.LED INDICATION STATUS

Condition

1. Standby

2. Operating

3. Cooling

4. Boost Mode in Use

5. Fan Failure

6. Overheating

7. Overheating While Starting

8. Lamp Cover Open

Power

Indicator

Flashing

Blue

(1sec interval)

Blue

Thermal

Indicator

Red

(0.5sec interval)

Red

(0.5sec interval)

Red

(0.5sec interval)

Red

Normal/Boost

Indicator

Green

Note

Waiting for power on

Normal operation

Cool lamp down for

100 sec

Boost mode is being

used

Fan failure.

There is a warning

message displayed

on the screen then the

projector will turn

itself off.

Overheating

in the projector:

There is a warning

message displayed

on the screen then the

projector will power

itself off.

The system will cool

itself down for 8 sec

automatically.

If the lamp cover is not

properly seated after

changing a new lamp,

the power can't be

turned on.

9LHZ6RQLF &LQH

INSTALLATION

2-2.ADJUSTING THE PROJECTED


2-2-1.ADJUSTING THE PROJECTED

HEIGHT

1. Press the Elevator buttons. (Drawing 3)

2. Raise the projector to the desired display

angle, allowing the legs to extend, release

the buttons to lock them in position.

3. Use the Adjustable foot (Drawing 5) at the

rear of the unit to fine-tune the display angle.

4. Use the "Keystone" button on the Remote

Control or in the projector's OSD to correct

any distortion caused by tilting the projector.

5. There are two adjustable directions shown on

the screen, one is vertical keystone

correction, the other is horizontal keystone

correction, use the cursor buttons to select

the Vertical or Horizontal Keystone correction.

(Drawing 10 and Drawing 11)

Press "Right" cursor for increasing the value.

Press "Left" cursor for decreasing the value.

(Drawing 9)

DRAWING 9

DRAWING 10

DRAWING 11

Keystone

Ver. Keystone

Hor. Keystone

2-2-2.ADJUSTING THE ZOOM and FOCUS

Rotate the Zoom ring to adjust the image size. Rotate the Focus ring to focus the image. The projector will

focus at distances from 1.5m (60in. / 5 ft.) to 10m (394 in. / 32.9 ft.). The optimum distance is from 1.5 m to 5

m (197 in. / 16.5 ft.).

DRAWING 12

Zoom Ring

Focus Ring

Ver. Keystone

Hor. Keystone

2-2-3.ADJUSTING THE PROJECTED IMAGE SIZE

38"

51"

77"

128"

179"

33" 44" 66" 109"

153"

175"

219"

204"

255"

1.5m 2.0m 3.0m 5.0m 7.0m 8.0m 10.0m

Distance To Screen (Meter/Inch)

Max. Screen Diagonal (Meter/Inch)

Min. Screen Diagonal (Meter/Inch)

1.5/60

0.98/38

0.83/33

2.0/79

1.30/51

1.11/44

3.0/118

1.94/77

1.67/66

5.0/197

3.24/128

2.78/109

7.0/276

4.54/179

3.89/153

8.0/315

5.18/204

4.44/175

10.0/394

6.48/255

5.55/219

2-3-1.CONNECTING TO A PERSONAL COMPUTER

1. Use the cable to connect your Notebook to the projector. (Drawing 14)

2. Press the "Monitor Output" function key of your Notebook.(Fn+ or or or )

3. The projector will automatically detect the source. If not, please press the "Source" button on the Control

Panel of the projector or on the Remote Control to select the computer source.

VGA

DRAWING 13

◆Connecting to a Notebook

DRAWING 14

Computer signal input

VGA cable

LCD

2-3.OPERATION

&LQH 9LHZ6RQLF

Autres manuels pour VS11481

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ViewSonic Projecteur

ViewSonic

ViewSonic PJ1158 - XGA LCD Projector Manuel utilisateur

ViewSonic

ViewSonic PJD5111 - SVGA DLP Projector Manuel utilisateur

ViewSonic

ViewSonic PJ759 - 63 Tft LCD Projector Manuel utilisateur

ViewSonic

ViewSonic M1 mini Manuel utilisateur

ViewSonic

ViewSonic PJ650 Manuel utilisateur

ViewSonic

ViewSonic VS10897 Manuel utilisateur

ViewSonic

ViewSonic PJ506D - SVGA DLP Projector Guide de démarrage rapide

ViewSonic

ViewSonic DP503D Manuel utilisateur

ViewSonic

ViewSonic PX727-4K Manuel utilisateur

ViewSonic

ViewSonic DLP PROJECTOR PJD7400W Manuel utilisateur

ViewSonic

ViewSonic PJ513D Manuel utilisateur

ViewSonic

ViewSonic VS18176 Manuel utilisateur

ViewSonic

ViewSonic PJD6381 - 2500 Lumens XGA DLP Ultra Short-Throw... Manuel utilisateur

ViewSonic

ViewSonic PJ552 Manuel utilisateur

ViewSonic

ViewSonic BRILLIANTCOLOR PJ560D Manuel utilisateur

ViewSonic

ViewSonic PJD6221 - 2700 Lumens XGA DLP Projector Manuel utilisateur

ViewSonic

ViewSonic PS501X Manuel utilisateur

ViewSonic

ViewSonic PJ510 - SVGA LCD Projector Manuel utilisateur

ViewSonic

ViewSonic VS17679 Manuel utilisateur

ViewSonic

ViewSonic PJD2121 - SVGA DLP Projector Manuel utilisateur

ViewSonic

ViewSonic PJ452 - LCD XGA Projector-4.9LBS Manuel utilisateur

ViewSonic

ViewSonic PRO7827HD Manuel utilisateur

ViewSonic

ViewSonic PJD7333 Manuel utilisateur

ViewSonic

ViewSonic PJD5123p Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
