M1+

Portable LED Projector

User Guide

Model No. VS18242

P/N: M1+

IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in

a safe manner, as well as registering your product for future service. Warranty information contained in this User

Guide will describe your limited coverage from ViewSonic®Corporation, which is also found on our web site at

http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right

corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic®

As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding

the world’s expectations for technological evolution, innovation, and simplicity.

At ViewSonic®, we believe that our products have the potential to make a positive

impact in the world, and we are confident that the ViewSonic® product you have

chosen will serve you well.

Once again, thank you for choosing ViewSonic®!

Safety Precautions

Please read the following Safety Precauons before you start using the projector.

• Keep this user guide in a safe place for later reference.

• Read all warnings and follow all instrucons.

• Allow at least 20“ (50 cm) clearance around the projector to ensure proper

venlaon.

• Place the projector in a well-venlated area. Do not place anything on the

projector that prevents heat dissipaon.

• Do not place the projector on an uneven or unstable surface. The projector may

fall over, causing personal injury or projector malfuncon.

• Do not use if the projector is lted at an angle of more than 10° degrees le or

right, nor at an angle of more than 15° degrees forwards or backwards.

• Do not look straight at the projector lens during operaon. The intense light

beam may damage your eyes.

• Always open the lens shuer or remove the lens cap when the projector lamp is

on.

• Do not block the projecon lens with any objects when the projector is under

operaon as this could cause objects to become heated and deformed or even

cause a re.

• The lamp becomes extremely hot during operaon. Allow the projector to

cool for approximately 45 minutes prior to removing the lamp assembly for

replacement.

• Do not use lamps beyond the rated lamp life. Excessive use of lamps beyond the

rated life could cause them to break on rare occasions.

• Never replace the lamp assembly or any electronic component unless the

projector is unplugged.

• Do not aempt to disassemble the projector. There are dangerous high voltages

inside which may cause death if you should come into contact with live parts.

• When moving the projector, be careful not to drop or bump the projector on

anything.

• Do not place any heavy objects on the projector or connecon cables.

• Do not stand the projector on end vercally. Doing so may cause the projector to

fall over, causing personal injury or projector malfuncon.

• Avoid exposing the projector to direct sunlight or other sources of sustained

heat. Do not install near any heat sources such as radiators, heat registers,

stoves, or other devices (including ampliers) that may increase the temperature

of the projector to dangerous levels.

• Do not place liquids near or on the projector. Liquids spilled into the projector

may cause it to fail. If the projector does become wet, disconnect it from the

power supply and call your local service center to have the projector serviced.

• When the projector is under operaon, you may sense some heated air and odor

from its venlaon grill. It is a normal operaon and not a defect.

• Do not aempt to circumvent the safety provisions of the polarized or

grounding-type plug. A polarized plug has two blades with one wider than the

other. A grounding-type plug has two blades and a third grounding prong. The

wide and third blade are provided for your safety. If the plug does not t into

your outlet, obtain an adapter and do not aempt to force the plug into the

outlet.

• When connecng to a power outlet, DO NOT remove the grounding prong.

Please ensure grounding prongs are NEVER REMOVED.

• Protect the power cord from being treaded upon or pinched, parcularly at the

plug, and at the point where it emerges from the projector.

• In some countries, the voltage is NOT stable. This projector is designed to

operate safely within a voltage between 100 to 240 volts AC, but could fail if

power cuts or surges of ±10 volts occur. In areas where voltage may uctuate

or cut out, it is recommended that you connect your projector through a power

stabilizer, surge protector, or uninterruptable power supply (UPS).

• If smoke, an abnormal noise, or a strange odor is present, immediately switch

the projector o and call your dealer or ViewSonic®. It is dangerous to connue

using the projector.

• Use only aachments/accessories specied by the manufacturer.

• Disconnect the power cord from the AC outlet if the projector is not being used

for a long period of me.

• Refer all servicing to qualied service personnel.

Contents

Safety Precautions....................................................... 3

Introduction ................................................................ 8

Package Contents ...................................................................................................8

Product Overview...................................................................................................9

Projector.................................................................................................................. 9

Remote Control..................................................................................................... 10

Remote Control - Effective Range ......................................................................... 11

Remote Control - Replacing the Batteries............................................................. 11

Initial Setup............................................................... 12

Choosing a Location - Projection Orientation.......................................................12

Projection Dimensions..........................................................................................13

Making Connections.................................................. 14

Connecting to Power ............................................................................................14

DC Power (Power Outlet)...................................................................................... 14

Power on by Power Bank Function ....................................................................... 15

Using the Battery..................................................................................................15

Battery Usage Time Information........................................................................... 15

Connecting to External Devices............................................................................16

HDMI Connection.................................................................................................. 16

USB Connection..................................................................................................... 16

Micro SD................................................................................................................ 16

Wireless Screen Mirroring..................................................................................... 17

Connecting to Bluetooth ......................................................................................18

Bluetooth Speaker................................................................................................. 18

Bluetooth Out........................................................................................................ 20

Connecting to Networks.......................................................................................21

Wi-Fi Connection................................................................................................... 21

Custom SSID .......................................................................................................... 23

Using the Projector.................................................... 25

Starting Up the Projector......................................................................................25

Adjusting the Projected Image .............................................................................26

Adjusting the Projector's Height and Projection Angle......................................... 26

Adjusting the Focus ............................................................................................... 26

First Time Activation.............................................................................................27

Preferred Language............................................................................................... 27

Projection Orientation .......................................................................................... 28

Network Settings................................................................................................... 28

Shutting Down the Projector................................................................................29

Input Source Selected - On-Screen Display (OSD) Tree......................................... 30

Operating the Projector............................................. 40

Home Screen ........................................................................................................40

Home Screen - On-Screen Display (OSD) Menu Tree ...........................................41

Menu Operations .................................................................................................45

File Management .................................................................................................. 45

How to Use the Media Control Bar Buttons.......................................................... 47

Supported File Formats......................................................................................... 48

Apps Center........................................................................................................... 49

Aptoide.................................................................................................................. 50

Bluetooth .............................................................................................................. 52

Setting ................................................................................................................... 53

Screen Mirroring ................................................................................................... 67

Appendix................................................................... 70

Specifications........................................................................................................70

Timing Chart .........................................................................................................71

HDMI/USB C Video Timing .................................................................................... 71

HDMI/USB C Support PC Timing............................................................................ 72

3D Support Timing................................................................................................. 73

LED Indicators.......................................................................................................74

Troubleshooting ...................................................................................................75

Maintenance.........................................................................................................77

General Precautions.............................................................................................. 77

Cleaning the Lens .................................................................................................. 77

Cleaning the Case.................................................................................................. 77

Storing the Projector............................................................................................. 77

Regulatory and Service Information .......................... 78

Compliance Information.......................................................................................78

FCC Compliance Statement................................................................................... 78

FCC Radiation Exposure Statement....................................................................... 79

IC Warning Statement........................................................................................... 79

Country Code Statement....................................................................................... 79

IC Radiation Exposure Statement.......................................................................... 80

CE Conformity for European Countries ................................................................. 80

Declaration of RoHS2 Compliance......................................................................... 81

Indian Restriction of Hazardous Substances ......................................................... 82

Product Disposal at End of Product Life................................................................ 82

Customer Service .................................................................................................. 84

Limited Warranty .................................................................................................. 85

Mexico Limited Warranty...................................................................................... 88

Introduction

Package Contents

56 7

234

Item Descripon

[1] Projector

[2] Power Cord

[3] USB Type C Cable

[4] Power Adapter

[5] Remote Control with Batteries

[6] Carrying Bag

[7] Quick Start Guide

Product Overview

Projector

USB-CDC

19V

Micro

USB READER

5V/1A OUT

HDMI

ENTER

Item Descripon Item Descripon

[1] Speaker [11] Enter1/ Power Button2

[2] IR Receiver [12] Volume Down3

[3] Tripod mount [13] Volume Up4

[4] Focus Ring [14] Return5

[5] Micro SD slot [15] Speaker PR

[6] DC IN [16] IR Receiver

[7] USB-C [17] Battery Indicator

[8] HDMI [18] Smart Stand

[9] Audio Out [19] Lens

[10] USB Type A

1 Enacts the selected On-Screen Display (OSD) menu item.

2 Press and hold for three (3) seconds to Power On/O the projector.

3 Decrease the volume level when the OSD menu doesn’t enable; Down.

4 Increase the volume level when the OSD menu doesn’t enable; Up.

5 Press and hold for three (3) seconds to view the source list.

Remote Control

Buon Descripon

[1] Power Turns the projector On or O

[2] Source Displays the input source selecon menu

[3] Focus Automacally focus the image1

[4] Bluetooth Mode Enable Bluetooth

[5] Up/Down/Le/Right Navigate and select menu items;

Keystone adjustment

[6] OK Conrms the selecon

[7] Seng Displays the Seng menu

[8] Return Returns to the previous screen

[9] Home Access the Home screen

[10] Volume Control Increase or decrease the volume level

[11] Mute Mute the volume

[12] Next/Previous Move to next/previous

[13] Play/Pause Play or pause media

1 NOTE: This model doesn’t support this feature.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ViewSonic Projecteur

ViewSonic

ViewSonic CINE1000 - DLP Home Theater Projector Manuel utilisateur

ViewSonic

ViewSonic CP-RX78 Manuel utilisateur

ViewSonic

ViewSonic PJ458D - XGA DLP Projector Manuel utilisateur

ViewSonic

ViewSonic PJD6543w Manuel utilisateur

ViewSonic

ViewSonic PLED-W200 Manuel utilisateur

ViewSonic

ViewSonic PJD5353 Manuel utilisateur

ViewSonic

ViewSonic M1 mini Manuel utilisateur

ViewSonic

ViewSonic PJ359w - WXGA LCD Projector Manuel

ViewSonic

ViewSonic PJ556D Manuel utilisateur

ViewSonic

ViewSonic PJD8333s Manuel utilisateur

ViewSonic

ViewSonic PJD5112 - s SVGA DLP Projector Manuel utilisateur

ViewSonic

ViewSonic BRILLIANTCOLOR PJD6241 Manuel utilisateur

ViewSonic

ViewSonic PLED-W600 Manuel utilisateur

ViewSonic

ViewSonic PJL9371 Manuel utilisateur

ViewSonic

ViewSonic PJD6683w Manuel utilisateur

ViewSonic

ViewSonic BRILLIANTCOLOR PJD6241 Manuel utilisateur

ViewSonic

ViewSonic PJ766D-1 Manuel utilisateur

ViewSonic

ViewSonic PX701HD Manuel utilisateur

ViewSonic

ViewSonic VS11542 Manuel utilisateur

ViewSonic

ViewSonic PJL9371 Manuel utilisateur

ViewSonic

ViewSonic PJD6253 Manuel utilisateur

ViewSonic

ViewSonic PJD5234 Manuel utilisateur

ViewSonic

ViewSonic VS10897 Manuel utilisateur

ViewSonic

ViewSonic PJD6381 - 2500 Lumens XGA DLP Ultra Short-Throw... Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
