ViewSonic VS13471 Manuel utilisateur
Model No.: VS13471
- User Guide
- Guide de l’utilisateur
- Guía del usuario
VFA724W
Digital Photo Frame
IMPORTANT: Please read this User Guide to obtain important information on install-
ing and using your product in a safe manner, as well as registering your product for
future service. Warranty information contained in this User Guide will describe your
limited coverage from ViewSonic Corporation, which is also found on our web site
at http://www.viewsonic.com in English, or in specic languages using the Regional
selection box in the upper right corner of our website.
“Antes de operar su equipo lea cuidadosamente las instrucciones en este manual”
ViewSonic VFA724W1
Compliance Information
FCC Statement
This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
For Canada
• This Class B digital apparatus complies with Canadian ICES-003.
• Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive
2006/95/EC.
Following information is only for EU-member states:
The mark is in compliance with the Waste Electrical and Electronic Equipment Directive
2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment including any spent or
discarded batteries or accumulators as unsorted municipal waste, but use the return and collection
systems available.
If the batteries, accumulators and button cells included with this equipment, display the chemical
symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of more than
0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead.
ViewSonic VFA724W2
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with Directive 2002/95/EC of the
European Parliament and the Council on restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum
concentration values issued by the European Technical Adaptation Committee (TAC) as shown
below:
Substance Proposed Maximum
Concentration Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex of the RoHS
Directives as noted below:
Examples of exempted components are:
1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other lamps not
specically mentioned in the Annex of RoHS Directive.
2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and electronic
ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or more
lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium containing
up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight.
ViewSonic VFA724W3
Copyright Information
Copyright© ViewSonic Corporation, 2010. All rights reserved.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks
of ViewSonic Corporation.
Disclaimer:ViewSonic Corporation shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages resulting from furnishing
this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specications without notice. Information in this document may change without
notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any
purpose without prior written permission from ViewSonic Corporation.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
VFA724W
ViewSonic Digital Photo Frame
VS13471
VFA724W_UG_ENG Rev. 1C 05-05-10
________________________________
________________________________
Product disposal at end of product life
ViewSonic is concerned about the preservation of our environment. Please dispose of this product
properly at the end of its useful life. Your local waste disposal company may provide information
about proper disposal.
ViewSonic VFA724W4
Important Safety Instructions
Always follow the basic safety precautions below when using your Digital Photo Frame. This will reduce
the risk of re, electric shock, and injury.
Warning: To reduce the risk of re or shock hazard, do not expose this product to rain or moisture
Warning: To prevent the risk, do not remove the cover, there are no spare parts inside, refer all product
services to professional personnel.
• Digital Photo frame is for indoor use only.
• Unplug Digital Photo frame before performing care and maintenance.
• Do not block the ventilation holes on the back of Digital Photo Frame at any time.
• Keep your Multimedia Digital Photo Frame out of direct sunlight and heat source.
• Protect the power cord. Route power cords appropriately to avoid trip over by someone else or
pinched by items placed on or against them. Pay particular attention to the point where the cord
attaches to Digital Photo Frame.
• Only use the AC adapter included with the Digital Photo Frame. Using any other power adapter
will void your warranty.
• Unplug the power cord from the outlet when the unit is not in use.
Cleaning LCD Screen
Treat the screen gently. The screen is made of glass which can be scratched or damaged
To clean ngerprints or dust from the LCD screen, we recommend using a soft / nonabrasive cloth such as
a camera lens cloth to clean the LCD screen.
I you use a commercial LCD cleaning kit, do not apply the cleaning liquid directly to the LCD screen.
Clean the LCD screen with cleaning cloth moistened with the liquid.
Clean Digital Photo Frame
Clean outer surface of Digital Photo Frame (excluding the screen) with a soft cloth dampened with water.
Package Content
•
Digital Photo Frame
•
AC power adapter
•
This User Guide
•
Quick Start Guide
ViewSonic VFA724W5
Identify the Parts
Button Action
Move the selection up or left, display the previous photo, or select the previous le
ENTER Select the highlighted option, start a Slide Show , Pause or Play
Move the selection down or right, display the next photo or select the next le.
EXIT Exit the current display, or go back a screen.
Menu Into the OSD Menu Mode
Power(On/Off)
Setup Up the Digital Photo Frame
The Digital Photo Frame is easy to set up. Just follow these steps:
1. Plug the AC Power Adapter into the Digital Photo Frame and into a wall outlet.
2. Insert a memory card into appropriate slot.
Secure Digital™ or MultiMedia Card™, Memeoy Stick™, MemoryStick Pro™, Memory
Stick Pro Duo™, Memory Stick Pro Duo™, xD Picture Card™.
3. Pull out adjustable Stand to adjust view angle.
Note: The card will only t in one direction; do not force it. The card should t snugly
when properly inserted.
4. Press the Power Button on the back of the Digital Photo frame ON. The Digital Photo
frame will automatically start a slide show of the photo on the card.
5. To display photos individually, press the EXIT button to open the Thumbnails Screen.
Use the Up and Sown arrows to choose a Photo. Press the Play button ( ) on the top of
the Digital Photo frame, or the Enter button on the remote control.
Note: Pull the plastic tab sticking out of the remote control. It protects the battery, and
the remote control will not work unless it is removed.
6. To restart the Slide Show, press the Play button ( ) again, or press the Slide Show
button on the remote control.
ViewSonic VFA724W6
Setting Up the Slideshow
You can control all Digital Photo Frame functions with the buttons on the top of the Digital Photo
Frame or with the remote control. To display the setup screen, simply hold down the Exit button
for a second or press the Setup button on the remote control.
Card Selection Screen
Use the Card Selection menu to choose between memory card and USB Drive.
1. To open the card select menu, either insert a new card or press the Exit button repeatedly
to back through the screens until you see it.
2. Press the left and Right arrows to select the desired memory card.
3. Press Enter to make the selection. The Mode Selection Screen opens.
Display a Single Photo on Full Screen
You can choose a single photo to display, without slideshow
1. With Thumbnail screen displayed, press Enter to display the selected photo on the full
screen.
2. Press the Left Arrow to return to the previous photo.
3. Press the Right Arrow to display the next photo
4. To return to the Thumbnail secren, press the Exit button.
ViewSonic VFA724W7
Setting Viewing Options
You can control all of the viewing options in the Setup menu using the buttons on the top of the frame.
1. To show the Setup menu, Press the Exit button until Select Mode or Select Card screen
shows, then press Setup button.
2. With the Setup menu open, use the Up and Down arrows to choose a display option.
3. Press Enter to select the option. A second menu opens, listing the available settings. A
white square shows the current setting.
4. Use the Up and down arrows to choose the desired setting.
5. Press Enter to select the setting. The white square moves to the selected setting.
6. You can make as many changes as you wish in the same manner. When you are nished,
press the Exit button to close the Settings Menu.
7. The Following table lists the display options in the Setup Menu, their options, and a
description of their actions.
Display Option Settings Description
Language
English
Supports 3 languages
Francais
Spanish
Magic Window ON Display 4 pictures in Slide Show
OFF
Display Image Size Original/Optimal The Digital Photo Frame can optimize
your photos to display on the screen
Slideshow Transition
Normal
Special effects shown to transition from
one photo one photo to the next in a Slide
Show
Random
Fade
Curtain
Open_Door
Cross_Comb
Slideshow Speed
Fast Determines how quickly the next photo is
displayed
Medium
Slow
Slideshow shufe ON/Off Display photos randomly
Power saving
2 Hours The Digital Photo Frame will turn itself
off after the specied period of time
4 Hours
8 Hours
No Power Saving
Factory default -Immediately rest all settings to the factory
defaults. There is no warning message.
ViewSonic VFA724W8
Technical Specication
Product VFA724W (17.8cm/7.0” LCD Screen Digital Photo Frame)
Resolution VFA724W 480 x 234 pixels
Memory Card Format Secure Digital™, MultiMedia Card™, Memory Stick Pro Duo™,
Memory Stick Duo™
File Format Standard JPEG
Feature
Slideshow mode
Multiple transitional Style for Slideshow
Variable Speed for Slide Show
Four Position Adjustable Stand for optimum view angle
USB Port USB 2.0 (Host)
Power Adapter Input 100V-240V AC, 50~60Hz
Power Adapter output VFA724W 5V DC, 1A
ViewSonic VFA724W9
Customer Support
For technical support or product service, see the table below or contact your reseller.
Note: You will need the product serial number.
Country/
Region Web Site T=Telephone
F=Fax E-mail
Australia/New
Zealand www.viewsonic.com.au AUS=1800 880 818
NZ=0800 008 822 [email protected]
Canada www.viewsonic.com
T (Toll-Free)= 1-866-463-4775
T (Toll)= 1-424-233-2533
F= 1-909-468-3757
Europe www.viewsoniceurope.com www.viewsoniceurope.com/uk/Support/Calldesk.htm
Ireland (Eire) www.viewsoniceurope.
com/uk/
www.viewsoniceurope.com/uk/
support/call-desk/
service_ie@viewsoniceurope.
com
Latin America
(Argentina) www.viewsonic.com/la/ T= 0800-4441185 [email protected]
Latin America
(Chile) www.viewsonic.com/la/ T=1230-020-7975 [email protected]
Latin America
(Columbia) www.viewsonic.com/la/ T= 01800-9-157235 [email protected]
Latin America
(Mexico) www.viewsonic.com/la/ T= 001-8882328722 [email protected]
Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS
Electroser, Av Reforma No. 403Gx39 y 41, 97000 Merida, Yucatan. Tel: 01.999.925.19.16
Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico
Latin America
(Peru) www.viewsonic.com/la/ T= 0800-54565 [email protected]
Puerto Rico &
Virgin Islands www.viewsonic.com
T= 1-800-688-6688 (English)
T= 1-866-379-1304 (Spanish)
F= 1-909-468-3757
Singapore/
Malaysia/
Thailand
United
Kingdom
www.viewsoniceurope.
com/uk/
www.viewsoniceurope.com/uk/
support/call-desk/
service_gb@
viewsoniceurope.com
United States www.viewsonic.com
T (Toll-Free)= 1-800-688-6688
T (Toll)= 1-424-233-2530
F= 1-909-468-3757
Ce manuel convient aux modèles suivants
5
Table des matières
Autres manuels ViewSonic Cadre photo numérique
ViewSonic
ViewSonic VFD1024W Manuel utilisateur
ViewSonic
ViewSonic VFA721w-50 Manuel utilisateur
ViewSonic
ViewSonic DPG807BK - Digital Photo Frame Manuel utilisateur
ViewSonic
ViewSonic DPX802 Manuel utilisateur
ViewSonic
ViewSonic VFD810-50 Manuel utilisateur
ViewSonic
ViewSonic VFM1032 Manuel utilisateur
ViewSonic
ViewSonic VFM1034W Manuel utilisateur
ViewSonic
ViewSonic DPF8-CAM Manuel utilisateur
ViewSonic
ViewSonic NO FOUND VFD725W-50P Manuel utilisateur
ViewSonic
ViewSonic DPG807BK-51P Manuel utilisateur
ViewSonic
ViewSonic VFM886-50E Manuel utilisateur
ViewSonic
ViewSonic PortraitView VFD621w-50 Manuel utilisateur
ViewSonic
ViewSonic VFD826-70 Manuel utilisateur
ViewSonic
ViewSonic VFD826-70 Manuel utilisateur
ViewSonic
ViewSonic DPG801BK Manuel utilisateur
ViewSonic
ViewSonic VFM735W-52G Manuel utilisateur
ViewSonic
ViewSonic VFM820-50 Manuel utilisateur
ViewSonic
ViewSonic VFM1035-52 Manuel utilisateur
ViewSonic
ViewSonic VFA724W Guide de démarrage rapide
ViewSonic
ViewSonic DPX1002 Manuel utilisateur
Manuels Cadre photo numérique populaires d'autres marques
Philips
Philips SPF1327 Manuel utilisateur
Philips
Philips SPF7010/10 Manuel utilisateur
Digital Spectrum
Digital Spectrum MemoryVue MV-1500 Manuel utilisateur
YURAKU
YURAKU YUR.PHOTO 7B4C Manuel utilisateur
Denver
Denver PFF-710WHITE MK2 Manuel utilisateur
Pandigital
Pandigital PAN8000DWPCF1 Manuel utilisateur
