Operating Manual

Valve DV-5325 / DV5325SS

Made in Germany

V1.3 NOV 2015

OPERATING MANUAL DV-5325

Table of Contents

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page Number

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Receiving Inspection Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Valve Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Typical Dispense Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Set Up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Valve Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Cleaning and Seal Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Air Cylinder Seal Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Reassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

OPERATING MANUAL DV-5325

LIMITED WARRANTY

Manufacturer warrants this product to the original purchaser for a period of one (1) year

from date of purchase to be free from defects in material and workmanship, but not

against damages by misuse, negligence, accident, faulty installation, abrasion, corrosion, or

by not operating in accordance with factory recommendations and instructions. Manufac-

turer will repair or replace (at factory’s option), free of charge, any component of the equip-

ment thus found to be defective, on return of the component “PREPAID” to the factory

during the warranty period. In no event shall any liability or obligation of the Manufacturer

arising from this warranty exceed the purchase price of the equipment. This warranty is

only valid if the defective DV-5325 Valve is returned as a complete assembly without physi-

cal damage.

The Manufacturer’s liability, as stated herein, cannot be altered or enlarged except by a

written statement signed by an officer of the company. In no event shall Manufacturer

be liable for consequential or incidental damages. A return authorization is required from

Vieweg GmbH prior to shipping a defective unit to the factory.

Manufacturer reserves the right to make engineering or product modifications without

notice.

OPERATING MANUAL DV-5325

Introduction

To obtain Maximum performance of this valve, please read and follow these instructions

carefully before operating.

Receiving Inspection Procedures

Carefully unpack the valve and examine the items contained in the carton.

These will include:

- Valve assembly

- Accessory Pack consisting of:

- Sample Needle Kit

- Sample Fluid Line

Inspect the valve for any damage that might have occurred in transit. If such damage

has occurred, notify the carrier immediately. Claims for damage must be made by the

consignee to the carrier and should be reported to the manufacturer.

Product Description

The DV-5325 Adjustable Mini Spool Valve is designed to dispense medium to high viscos-

ity material with very precise deposits over a wide range of shot and bead sizes down to

a fraction of a micro liter. An internal spring return makes the valve fully adaptable for use

VC-1000 time/pressure controllers. A short opening stroke provides extremely fast, positive

shut-off. An external adjustment makes it easy for the operator to fine tune“Suck-Back”. The

DV-5325’s compact design allows for mounting flexibility and easy integration into auto-

mated applications.

Technical Specifications

Size: Length 4.00 Inches (101.6 mm)

Diameter 35 mm

Weight: 4.9 oz. Aluminum 4.2 oz. Delrin

Fluid Inlet: 1/8“ N.P.T.

Fluid Outlet: 1/8“ N.P.T.

Max Fluid Pressure: 500 PSI

Air Inlets: 10-32 UNF-2B

Minimum Operating Air Pressure 50 PSI

Description DV-5325 DC-5325D

Wetted Parts 303 Stainless Steel,

Anodized Aluminium, Teflon

Seals

316 Stainless Steel, Delrin,

Teflon Seals,

OPERATING MANUAL DV-5325

OPERATION

Valve Operation

The DV-5325 is a normally closed spool valve with

adjustable suck-back. Air pressure through port (1)

drives the spool assembly (2) forward opening the

material path from the material inlet (3) to the material

outlet (4). Return air (5) or return spring (6) reverses

the spool assembly travel to close the material path.

An oil cup (7) provides a moisture barrier for the seal

when dispensing a moisture sensitive material.

Typical Dispense Performance

Minimum Shot Size (water): = .002 ml

Flow Rate at 100 PSI (water): = 2700 ml/min

Operating Frequency: = 700 cycles/min

Material Viscosity Range: = Up to 1 Million CPS

Repeatability: = ±0.2%

Set-Up

Refer to illustration.

Note: This installation uses Luer Lock adapters shipped with the valve. Any

approved material line with 1/8“ N.P.T. connections will work.

1. If desired, mount the valve to the bracket included (8).

2. Connect material feed line to inlet port (3). Valve segment with inlet port can be rotated

up to 360° to provide repositioning of inlet port. Caution: Do not turn inlet

port far enough to disconnect from Air Cylinder.

3. Connect valve actuating air line to valve port (1 ) and to an approved valve

controller.

4. Pressurize material reservoir (Material pressure not to exceed 500 PSI).

5. Activate the valve until all air has been purged from Material Line. It may be helpful to

turn the valve upside down to purge air.

6. Attach desired dispense tip to the outlet Luer Lock adapter.

OPERATING MANUAL DV-5325

Valve Adjustment

Shot size and bead width are dependent on the following factors:

1. Length of actuation, set at controller (Valve open time).

2. Material supply pressure at reservoir.

3. Material viscosity.

4. Dispense tip size.

Suck-Back Adjustment

The DV-5325 Mini Spool Valve is equipped with a natural“suck-back” feature. When

closing, the valve will pull, or “suck-back” material into the material chamber thus

helping to prevent dripping. It is possible to adjust the amount of “suck-back” by turning

the adjustment knob on the back of the valve.

Note: There are two notches in the adjustment cap that mark the maximum and minimum

“suck-back” settings. Turning the adjustment knob into the valve past the minimum

mark will cause the valve to remain open. (see illustration below).

maximum suck-back

minimum suck-back

OPERATING MANUAL DV-5325

MAINTENANCE

Cleaning and Seal Replacement

Disassembly

(refer to diagram on page 10)

Tools Required O-ring removal tool (P/N TSD1597-7) and Retaining Ring Pliers

with 0.053” tip.

Caution: Disconnect all material and air pressure lines before performing any mainte-

nance on this valve.

Note: To prevent possible damage to seal components, following these instructions

in the following sequence is recommended. Refer to diagram on

page 10.

1. Remove all hoses and fittings from Valve Body (6).

2. Unscrew the End Cap (17). Remove retaining ring (24) and remove the Spring (11).

Carefully remove the Spool Assembly (12) by pulling straight out.

3. Hold the Valve Body (6) and rotate the Air Cylinder (15) counterclockwise. When com-

pletely un-threaded, pull the two valve segments straight apart to separate.

4. Using Retaining Ring Pliers, remove Retaining Ring (22). Remove Stainles Steel Washer

(5) from valve body.

5. Note orientation of the Seal (4) in Valve Body (6) prior to removal. Remove Seal.

6. Remove four [4] Socket Cap Screws (2) in Outlet Block (1) and separate Outlet Block (1)

from Valve Body (6).

7. Note orientation of Seal (4) in outlet block (1) and remove.

8. Clean and inspect Spool (12), Seal surface and Seals (4, 4 & 5) for wear and damage.

Replace parts as necessary.

Reference Valve Repair Kit #1: P/N 5325-000-009

9. Reassemble valve per instructions in Reassembly section page 8.

OPERATING MANUAL DV-5325

Air Cylinder Seal Replacement (If Necessary)

Tools required: Internal retaining ring pliers with 0.035” tip.

O-ring tool P/N TSD1597-7.

Disassembly

Note: Refer to diagram on page 10.

1. Follow steps 1 through 3 of the disassembly section on page 7.

2. Remove Retaining Ring (7) with Retaining Ring Tool, then remove Nylon Washer (8)

from Air Cylinder (15).

3. Remove O-ring (10) using O-ring tool .

4. Clean and visually inspect all parts for damage. Replace as necessary. Reference Valve

Repair Kit #2: P/N 5325-000-010.

5. Lubricate O-ring (10) using approved lubricant and insert O-ring (10) into Air

Cylinder (15).

6. Insert Nylon Washer (8) and using Retaining Ring Pliers, secure Retaining Ring (7).

7. Reassemble valve per instructions in the reassembly section below.

Reassembly

Note: Make sure seals are oriented properly.

1. Insert Seal (4) into Valve Body (6) using a soft rod (such as a wooden dowel or a

pencil) to insure Seal is fully seated.

2. Insert Stainless Steel washer (5) and secure with Retaining Ring (22) using Retaining

Ring Pliers.

3. Thread the Air Cylinder (15) into the Valve Body (6) taking care not to cross thread

or over tighten.

4. Insert Seal (4) into the Outlet Block (1) and reassemble Outlet Block (1) to Valve Body

(6).

5. Install Spring (11).

6. Insert Spool Assembly (12) into Air Cylinder (15) and secure with retaining ring (24)

7. Thread end cap (17) into air cylinder assembly (15). Adjust to first mark in cap.

OPERATING MANUAL DV-5325

TROUBLESHOOTING

Problem Check & Correction

No Material Flow • Material pressure too low - Increase material pres

sure.

• Operating air pressure too low - Increase air pressure

to 50 PSI.

• Material cure clogged in valve - Clean Valve

Inconsistent Material Flow • Inconsistant operating air pressure

• Inconsistant material pressure

• Operating air pressure too low - Increase air pressure

to 50 PSI.

• Air trapped in fluid housing - Purge Valve

• Length of actuation too short - Increase shot time

Material continues to flow after

the valve is closed, but eventu-

ally stops.

• Air trapped in material line or fluid housing - Purge

Valve

Steady Drip • Suck Back Cap fully closed - Unscrew cap until drip-

ping stops

• Damaged spool and/or seals - Replace worn or dam-

aged parts

• Material pressure exceeds 500 PSI - Lower Material

Pressure

• Valve reassembled incorrectly after cleaning -

Reassemble following instructions

• Actuating air pressure not properly exhausted -

Check pneumatic circuit

• Return spring missing or damaged - Replace spring.

OPERATING MANUAL DV-5325

Parts List DV-5325

15 5320-000-012 Cylinder 1

16 TSD1400-019A O-Ring 1

17 5320-000-007 End Cap 1

18 TSD931-47 Luer Lock Adapter #17 1

19 TSD126-318 Fluid Line (not shown) 1*

20 5320-000-008 Tubing Assy (not shown) 1

22 TSD1120-6 Retaining Ring 1

24 TSD1120-15 Retaining Ring 1

25 TSD1106-32 ¼-20 x 3/8 Fixing screw 1

26 TSD918-000-48 Mounting Bracket 1

* Not Included

Autres manuels pour DV-5325

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels VIEWEG Unité de contrôle

VIEWEG

VIEWEG DV-5370 Manuel utilisateur

VIEWEG

VIEWEG DV-5425 Series Manuel utilisateur

VIEWEG

VIEWEG DV-5625 Series Manuel utilisateur

VIEWEG

VIEWEG DV-5625 Series Manuel utilisateur

VIEWEG

VIEWEG DV-5325 Manuel utilisateur

VIEWEG

VIEWEG DV-5005DFS Manuel utilisateur

VIEWEG

VIEWEG DV-5625-U Manuel utilisateur

VIEWEG

VIEWEG DV-5120 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
