Viessmann Vitodens 200-W System Guide rapide
Installation and service instructions
for contractors
VIESMANN
Vitodens 200-W
Type B2HA, 45 and 60 kW
Wall mounted gas condensing boiler
Natural gas and LPG version
For applicability, see the last page
VITODENS 200-W
5623 715 GB 2/2013 Please keep safe.
2
Please follow these safety instructions closely to
prevent accidents and material losses.
Safety instructions explained
Danger
This symbol warns against the risk of injury.
!Please note
This symbol warns against the risk of material
losses and environmental pollution.
Note
Details identified by the word "Note" contain additional
information.
Target group
These instructions are exclusively intended for quali-
fied contractors.
■Work on gas installations must only be carried out by
a registered gas fitter.
■Work on electrical equipment must only be carried
out by a qualified electrician.
■The system must be commissioned by the system
installer or a qualified person authorised by the
installer.
Regulations
Observe the following when working on this system:
■Statutory regulations regarding the prevention of
accidents
■Statutory regulations regarding environmental pro-
tection
■Codes of practice of the relevant trade associations
■All current safety regulations as defined by DIN, EN,
DVGW, TRGI, TRF, VDE and all locally applicable
standards
■Gas Safety (Installation & Use) Regulations
– the appropriate Building Regulation either the
Building regulations, the Building Regulation (Scot-
land), Building Regulations (Northern Ireland),
– the Water Fittings Regulation or Water Bylaws in
Scotland,
– the current I.E.E. Wiring Regulations.
If you smell gas
Danger
Escaping gas can lead to explosions which may
result in serious injury.
■Do not smoke. Prevent naked flames and
sparks. Do not switch lights or electrical appli-
ances on or off.
■Close the gas shut-off valve.
■Open windows and doors.
■Evacuate any people from the danger zone.
■Notify your gas or electricity supply utility from
outside the building.
■Shut off the electricity supply to the building
from a safe place (outside the building).
If you smell flue gas
Danger
Flue gas can lead to life-threatening poisoning.
■Shut down the heating system.
■Ventilate the installation site.
■Close all doors in the living space.
Flue systems and combustion air
Ensure that flue systems are clear and cannot be
sealed, for instance due to accumulation of conden-
sate or other causes. Ensure a sufficient supply of
combustion air.
Instruct system users that subsequent modifications to
the building characteristics are not permissible (e.g.
cable/pipework routing, cladding or partitions).
Danger
Life-threatening poisoning caused by carbon
monoxide in the flue gas occurs as a result of
leaking or blocked flue systems or an insufficient
supply of combustion air.
Ensure the flue system is in proper working
order. It must not be possible to close apertures
for interconnected combustion air supply.
Extractors
Operating appliances that extract air to the outside
(cooker hoods, extractors, air conditioning units, etc.)
can create negative pressure. If the boiler is operated
at the same time, this can lead to reverse flow of the
flue gas.
Danger
The simultaneous operation of the boiler and
appliances that extract air to the outside can
result in life threatening poisoning due to
reverse flow of the flue gas.
Fit an interlock circuit or take suitable steps to
ensure a sufficient supply of combustion air.
Safety instructions
Safety instructions
5623 715 GB
3
Working on the system
■Where gas is used as the fuel, close the main gas
shut-off valve and safeguard it against unintentional
reopening.
■Isolate the system from the power supply (e.g. by
removing the separate fuse or by means of a mains
isolator) and check that it is no longer 'live'.
■Safeguard the system against reconnection.
!Please note
Electronic assemblies can be damaged by elec-
trostatic discharge.
Prior to commencing any work, touch earthed
objects, such as heating or water pipes to dis-
charge static loads.
Repair work
!Please note
Repairing components that fulfil a safety func-
tion can compromise the safe operation of your
system.
Defective components must be replaced with
genuine Viessmann spare parts.
Auxiliary components, spare and wearing parts
!Please note
Spare and wearing parts that have not been tes-
ted together with the system can compromise its
function. Installing non-authorised components
and making non-approved modifications or con-
versions can compromise safety and may inva-
lidate our warranty.
For replacements, use only original spare parts
supplied or approved by Viessmann.
Safety instructions
Safety instructions (cont.)
5623 715 GB
4
1. Product information Intended use .......................................................................................... 7
Product information ................................................................................ 7
■Vitodens 200-W, type B2HA ............................................................... 7
2. Preparing for installation .................................................................................................................. 8
3. Installation sequence Fitting the boiler and making connections ............................................. 9
■Fitting the wall mounting bracket ........................................................ 9
■Hooking the boiler onto the wall mounting bracket and levelling it ..... 10
Connections on the heating water side .................................................. 11
Flue gas connection ............................................................................... 11
Condensate connection ......................................................................... 12
Gas connection ...................................................................................... 12
Opening the control unit casing ............................................................. 12
Electrical connections ............................................................................ 14
■Circulation pump at plug sÖ ................................................................ 15
■Circulation pump at plug sA ................................................................ 15
■External demand via switching contact .............................................. 15
■External demand via 0 – 10 V input .................................................... 16
■External blocking via switching contact .............................................. 17
■Outside temperature sensor ! .......................................................... 17
■Power supply for accessories at plug lH (230 V~) ............................. 18
■Power supply fÖ ................................................................................. 18
■Routing the connecting cables ........................................................... 19
Closing the control unit casing and inserting the programming unit ...... 20
4. Commissioning, inspec-
tion, maintenance
Steps - commissioning, inspection and maintenance ............................ 21
5. Code 1 Calling up coding level 1 ........................................................................ 45
■Calling up coding level 1 ..................................................................... 45
General/group "1" .................................................................................. 45
■Coding ................................................................................................ 46
Boiler/group "2" ...................................................................................... 47
■Coding ................................................................................................ 47
DHW/group "3" ...................................................................................... 48
■Coding ................................................................................................ 48
Solar/group "4" ....................................................................................... 48
Heating circuit 1, heating circuit 2, heating circuit 3/group "5" ............... 49
■Coding ................................................................................................ 50
6. Code 2 Calling up coding level 2 ........................................................................ 54
■Calling up coding level 2 ..................................................................... 54
General/group "1" .................................................................................. 54
■Coding ................................................................................................ 55
Boiler/group "2" ...................................................................................... 60
■Coding ................................................................................................ 60
DHW/group "3" ...................................................................................... 61
■Coding ................................................................................................ 61
Solar/group "4" ....................................................................................... 62
■Coding ................................................................................................ 62
Heating circuit 1, heating circuit 2, heating circuit 3/group "5" ............... 64
■Coding ................................................................................................ 65
7. Diagnosis and service
scans
Service level .......................................................................................... 70
Diagnosis ............................................................................................... 70
■Operating data .................................................................................... 70
■Brief scan ............................................................................................ 71
Index
Index
5623 715 GB
5
Checking outputs (relay test) ................................................................. 74
■Weather-compensated control unit ..................................................... 74
■Constant temperature control unit ...................................................... 74
8. Troubleshooting Fault display ........................................................................................... 76
■Weather-compensated control unit ..................................................... 76
■Constant temperature control unit ...................................................... 76
Fault codes ............................................................................................ 77
Repair .................................................................................................... 86
■Checking the outside temperature sensor (weather-compensated
control unit) ......................................................................................... 86
■Checking the boiler water temperature sensors, cylinder tempera-
ture sensor or flow temperature sensor for the low loss header ......... 87
■Checking the flue gas temperature sensor ......................................... 88
■Checking the fuse ............................................................................... 89
■Extension kit, mixer ............................................................................ 89
■Check Vitotronic 200-H (accessory) ................................................... 90
9. Function description Constant temperature control unit ......................................................... 91
■Heating mode ..................................................................................... 91
■DHW heating ...................................................................................... 91
Weather-compensated control unit ........................................................ 91
■Heating mode ..................................................................................... 91
■DHW heating ...................................................................................... 92
■Boosting DHW heating ....................................................................... 92
Internal extensions (accessories) .......................................................... 92
■Internal extension H1 .......................................................................... 92
■Internal extension H2 .......................................................................... 93
External extensions (accessories) ......................................................... 94
■Extension AM1 ................................................................................... 94
■Extension EA1 .................................................................................... 95
Control functions .................................................................................... 96
■External heating program changeover ............................................... 96
■External blocking ................................................................................ 97
■External demand ................................................................................ 97
■Venting program ................................................................................. 98
■Screed drying ..................................................................................... 98
■Raising the reduced room temperature .............................................. 100
■Reducing the heat-up time ................................................................. 100
Assigning heating circuits to the remote control .................................... 101
Electronic combustion control unit ......................................................... 102
10. Designs Connection and wiring diagram – Internal connections ......................... 103
Connection and wiring diagram – External connections ........................ 104
11. Parts lists Ordering parts ........................................................................................105
Overview of the assemblies ...................................................................105
Casing assembly ................................................................................... 106
Heat cell assembly .................................................................................106
Burner assembly ....................................................................................107
Hydraulic assembly ................................................................................108
Control unit assembly ............................................................................ 109
Miscellaneous assembly ........................................................................ 110
12. Commissioning/service
reports
................................................................................................................ 112
13. Specification .................................................................................................................. 113
14. Certificates Declaration of conformity ....................................................................... 114
■Declaration of Conformity for the Vitodens 200-W ............................. 114
Index
Index
5623 715 GB
7
The appliance is only intended to be installed and
operated in sealed unvented heating systems that
comply with EN 12828, with due attention paid to the
associated installation, service and operating instruc-
tions. It is only designed for the heating of water that is
of potable water quality.
Intended usage presupposes that a fixed installation in
conjunction with permissible, system-specific compo-
nents has been carried out.
Commercial or industrial usage for a purpose other
than heating the building or DHW does not comply with
regulations.
Any usage beyond this must be approved by the man-
ufacturer for the individual case.
Incorrect usage or operation of the appliance (e.g. the
appliance being opened by the system user) is prohibi-
ted and results in an exclusion of liability. Incorrect
usage also occurs if the components in the heating
system are modified from their intended function (e.g.
if the flue gas and ventilation air paths are sealed).
Product information
Vitodens 200-W, type B2HA
Preset for operation with natural gas E and natural gas
LL.
For conversion to LPG P (without conversion kit), see
the service instructions.
In principle the Vitodens 200-W may only be delivered
to countries listed on the type plate. For deliveries to
alternative countries, an approved contractor must
arrange individual approval on his own initiative and in
accordance with the law of the country in question.
Multi-boiler system
For the installation of a multi boiler system observe the
installation instructions for the multi boiler system
accessories.
Product information
Intended use
5623 715 GB
Service
8
!Please note
To prevent equipment damage,
connect all pipework free of load and torque
stress.
40
100160 160
752
1975
1690
850
380
480
875
1166
160
E
A
L
M
O
CB D F
H
P
K
N
200
G
Fig. 1
AExpansion vessel G1
BSafety valve
CHeating flow G1½
DCylinder flow G1½
EGas connection R ¾
FCylinder return G1½
GHeating return G1½
HCable entry area at the back
KAccessories (connection sets)
LWithout connection sets (accessories)
MWith connection sets (accessories)
NRecommended dimension (single boiler system)
ORecommended dimension (multi boiler system)
PCondensate drain
Note
This boiler (IP rating IP X4 D) is approved for installa-
tion in wet rooms inside safety zone 1 in accordance
with DIN VDE 0100, providing the occurrence of hosed
water can be ruled out.
Observe the requirements of DIN VDE 0100 [or local
regulations].
1. Prepare the water connections. Thoroughly flush
the heating system.
2. Prepare the gas connection according to TRGI or
TRF [or local regulations].
3. Prepare the electrical connections.
■Power cable: NYM-J 3 x 1.5 mm2, max.
fuse 16 A, 230 V~.
■Accessory cables: NYM with the required number
of conductors for the external connections.
■Allow all cables in area "H" to protrude 1200 mm
from the wall.
Preparing for installation
Preparing for installation
5623 715 GB
Installation
9
Fitting the wall mounting bracket
Note
The enclosed screws and rawl plugs are only suitable
for concrete. For other construction materials, use fix-
ing materials that are suitable for 100 kg loads.
422
480
1975
Ø 10
1.
2.
A
D
C
B
Fig. 2
AReference point: boiler top edge
BInstallation template (included with the boiler)
CTop edge finished floor
DRecommendation
Installation sequence
Fitting the boiler and making connections
5623 715 GB
Installation
10
Hooking the boiler onto the wall mounting bracket and levelling it
1.
2x
4.
3.
2.
5.
2x
Fig. 3
Note on step 4
Place the supplied circular level on the boiler and align
boiler vertically using the adjusting screws.
Installation sequence
Fitting the boiler and making connections (cont.)
5623 715 GB
Installation
