Viessmann Vitodens 100-W Guide rapide
Installation and service
instructions
for contractors
VIESMANN
Vitodens 100-W
Type BPJA, 6.5 to 25.0 kW
Wall mounted gas condensing boiler
Natural gas and LPG version
Gas Council no.: 47-819-26 P25; 47-819-27 P29
For applicability, see the last page
VITODENS 100-W
5609 913 GB 2/2013 Please keep safe.
2
Please follow these safety instructions closely to prevent accidents and mate-
rial losses.
Safety instructions explained
Danger
This symbol warns against the
risk of injury.
!Please note
This symbol warns against the
risk of material losses and envi-
ronmental pollution.
Note
Details identified by the word "Note" con-
tain additional information.
Target group
These instructions are exclusively inten-
ded for qualified contractors.
■ Work on gas installations must only be
carried out by a registered gas fitter.
■ Work on electrical equipment must
only be carried out by a qualified elec-
trician.
■ The system must be commissioned by
the system installer or a qualified per-
son authorised by the installer.
Regulations
Observe the following when working on
this system:
■ Statutory regulations regarding the
prevention of accidents
■ Statutory regulations regarding envi-
ronmental protection
■ Codes of practice of the relevant trade
associations
■ All current safety regulations as
defined by DIN, EN, DVGW, TRGI,
TRF, VDE and all locally applicable
standards
aÖNORM, EN, ÖVGW-TR Gas,
ÖVGW-TRF and ÖVE
cSEV, SUVA, SVGW, SVTI,
SWKI, VKF and EKAS guideline
1942: LPG, part 2
If you smell gas
Danger
Escaping gas can lead to explo-
sions which may result in serious
injury.
■ Do not smoke. Prevent naked
flames and sparks. Do not
switch lights or electrical appli-
ances on or off.
■ Close the gas shut-off valve.
■ Open windows and doors.
■ Evacuate any people from the
danger zone.
■ Notify your gas or electricity
supply utility from outside the
building.
■ Shut off the electricity supply to
the building from a safe place
(outside the building).
Safety instructions
Safety instructions
5609 913 GB
3
If you smell flue gas
Danger
Flue gas can lead to life-threat-
ening poisoning.
■ Shut down the heating system.
■ Ventilate the installation site.
■ Close all doors in the living
space.
Flue systems and combustion air
Ensure that flue systems are clear and
cannot be sealed, for instance due to
accumulation of condensate or other
causes. Ensure a sufficient supply of
combustion air.
Instruct system users that subsequent
modifications to the building characteris-
tics are not permissible (e.g. cable/pipe-
work routing, cladding or partitions).
Danger
Life-threatening poisoning
caused by carbon monoxide in
the flue gas occurs as a result of
leaking or blocked flue systems
or an insufficient supply of com-
bustion air.
Ensure the flue system is in
proper working order. It must not
be possible to close apertures for
interconnected combustion air
supply.
Extractors
Operating appliances that extract air to
the outside (cooker hoods, extractors, air
conditioning units, etc.) can create neg-
ative pressure. If the boiler is operated at
the same time, this can lead to reverse
flow of the flue gas.
Danger
The simultaneous operation of
the boiler and appliances that
extract air to the outside can
result in life threatening poison-
ing due to reverse flow of the flue
gas.
Fit an interlock circuit or take suit-
able steps to ensure a sufficient
supply of combustion air.
Working on the system
■ Where gas is used as the fuel, close
the main gas shut-off valve and safe-
guard it against unintentional reopen-
ing.
■ Isolate the system from the power sup-
ply (e.g. by removing the separate fuse
or by means of a mains isolator) and
check that it is no longer 'live'.
■ Safeguard the system against recon-
nection.
!Please note
Electronic assemblies can be
damaged by electrostatic dis-
charge.
Prior to commencing any work,
touch earthed objects, such as
heating or water pipes to dis-
charge static loads.
Repair work
!Please note
Repairing components that fulfil a
safety function can compromise
the safe operation of your sys-
tem.
Defective components must be
replaced with genuine
Viessmann spare parts.
Safety instructions
Safety instructions (cont.)
5609 913 GB
4
Auxiliary components, spare and
wearing parts
!Please note
Spare and wearing parts that
have not been tested together
with the system can compromise
its function. Installing non-author-
ised components and making
non-approved modifications or
conversions can compromise
safety and may invalidate our
warranty.
For replacements, use only orig-
inal spare parts supplied or
approved by Viessmann.
Safety instructions
Safety instructions (cont.)
5609 913 GB
5
Installation instructions
Preparing for installation................................................................................... 6
Installation sequence
Fitting the boiler and making connections............................................................ 11
Opening the control unit casing............................................................................ 16
Electrical connections........................................................................................... 17
Service instructions
Commissioning, inspection, maintenance
Steps - commissioning, inspection and maintenance.......................................... 20
Further details regarding the individual steps....................................................... 21
Troubleshooting
Function sequence and possible faults................................................................ 35
Fault messages on the display............................................................................. 36
Repairs................................................................................................................. 40
Gas type conversion
Converting from LPG to natural gas..................................................................... 48
Designs
Connection and wiring diagram............................................................................ 50
Parts lists
Ordering parts...................................................................................................... 52
Overview of the assemblies................................................................................. 53
Sheet metal parts assembly................................................................................. 54
Heat cell assembly............................................................................................... 55
Burner assembly.................................................................................................. 56
Hydraulic assembly.............................................................................................. 58
Combi hydraulic assembly................................................................................... 60
Control unit assembly........................................................................................... 61
Miscellaneous assembly...................................................................................... 62
Specification....................................................................................................... 63
Certificates
Declaration of conformity...................................................................................... 64
Keyword index.................................................................................................... 65
Index
Index
5609 913 GB
6
Intended use
The appliance is only intended to be
installed and operated in sealed unven-
ted heating systems that comply with
EN 12828, with due attention paid to the
associated installation, service and
operating instructions. It is only designed
for the heating of water that is of potable
water quality.
Intended usage presupposes that a fixed
installation in conjunction with permissi-
ble, system-specific components has
been carried out.
Commercial or industrial usage for a pur-
pose other than heating the building or
DHW does not comply with regulations.
Any usage beyond this must be
approved by the manufacturer for the
individual case.
Incorrect usage or operation of the appli-
ance (e.g. the appliance being opened
by the system user) is prohibited and
results in an exclusion of liability. Incor-
rect usage also occurs if the components
in the heating system are modified from
their intended function (e.g. if the flue
gas and ventilation air paths are
sealed).
Product information
Vitodens 100-W, type BPJA
Preset for operation with natural gas.
Conversion to LPG P requires a gas con-
version kit.
Conversion for other countries
The Vitodens 100-W should generally
only be delivered to those countries
specified on the type plate. For deliveries
to alternative countries, an approved
contractor must arrange individual
approval on his/her own initiative and in
accordance with the law of the country in
question.
Product description
The Vitodens 100-W is available as a
gas condensing combi boiler with inte-
gral plate heat exchanger for DHW heat-
ing. For the connection of heating circuits
and the DHW line, see from page 10.
The Vitodens 100-W is set up for opera-
tion with constant boiler water tempera-
ture.
The following are integrated: one sealed
unvented hydraulic system with 2 con-
nections for heating flow and return and
2 connections for DHW heating.
If the Vitodens 100-W is installed in an S
plan or Y plan system, the DHW primary
connections are not used and must be
capped off.
Preparing for installation
Preparing for installation
5609 913 GB
7
The following components are integra-
ted into the hydraulic system:
■ Circulation pump
■ 3-way diverter valve
■ Safety valve
■ Diaphragm expansion vessel
■ Plate heat exchanger for DHW heating
Accessory connection
A time switch is connected with low volt-
age to the control unit.
Preparing for boiler installation
Dimensions and connections
34
5
250
68
400
700
58 58
123123
B
AC E
F
D
156
350
125
860
175
150
Shown without fittings
AHeating flow 7 22 mm
BDHW 7 15 mm
CGas connection 7 22 mm
DCold water 7 15 mm
Preparing for installation
Preparing for installation (cont.)
5609 913 GB
Installation
8
EHeating return 7 22 mm
FCondensate drain/safety valve
drain: Plastic hose 7 22 mm
Preparing for installation
Preparing for installation (cont.)
5609 913 GB
9
Fitting the wall mounting bracket
250
A
Ø10
145
AVitodens installation template
Preparing for installation
Preparing for installation (cont.)
5609 913 GB
Installation
10
1. Position the supplied installation tem-
plate on the wall.
2. Mark out the rawl plug holes.
3. Drill 7 10 mm holes and insert the
rawl plugs supplied.
4. Fit wall mounting bracket with screws
supplied.
Fitting installation aid or mounting
frame
Installation aid or mounting frame
installation instructions
Preparing the connections
!Please note
To prevent equipment damage,
connect all pipework free of load
and torque stress.
1. Prepare the water connections. Flush
the heating system.
2. Prepare the gas connection.
3. Prepare the electrical connections.
■Power cable NYM-J 3 x 1.5 mm2.
■ Accessory cables:
NYM-O 2-core min. 0.5 mm2.
Preparing for installation
Preparing for installation (cont.)
5609 913 GB
Autres manuels pour Vitodens 100-W
41
Table des matières
Autres manuels Viessmann Chaudière
Viessmann
Viessmann Vitodens 222-F Guide rapide
Viessmann
Viessmann VITOCROSSAL 300 Mode d'emploi
Viessmann
Viessmann VITORADIAL 300-T Mode d'emploi
Viessmann
Viessmann VITODENS 200 WB2 Series Manuel utilisateur
Viessmann
Viessmann VITODENS 333 Mode d'emploi
Viessmann
Viessmann Vitodens series Manuel utilisateur
Viessmann
Viessmann Vitodens 100-W B1HA 26Vitodens 100-W B1HA 35Vitodens 100-W B1KA... Guide rapide
Viessmann
Viessmann Vitogate 300 Manuel utilisateur
Viessmann
Viessmann VITOPLEX 100?LS Guide rapide
Viessmann
Viessmann Vitopend 100-W Guide rapide
Viessmann
Viessmann Vitomax HW Series Manuel de formation
Viessmann
Viessmann VITODENS 200 WB2A Note de version
Viessmann
Viessmann Vitodens 100-W Manuel utilisateur
Viessmann
Viessmann VITOLIGNO 300-C Guide rapide
Viessmann
Viessmann VITOCELL 300B Manuel utilisateur
Viessmann
Viessmann VITODENS 050-W Manuel utilisateur
Viessmann
Viessmann Vitodens 100-W Manuel utilisateur
Viessmann
Viessmann VITOPLEX 100 Mode d'emploi
Viessmann
Viessmann Vitorond 200 Type VR2 Mode d'emploi
Viessmann
Viessmann VITORADIAL 300-T Manuel utilisateur
Manuels Chaudière populaires d'autres marques
Vaillant
Vaillant uniSTOR VIH SW GB 500 BES Manuel utilisateur
Radijator
Radijator BIO max 23.1 Manuel utilisateur
Brunner
Brunner BSV 20 Manuel utilisateur
Buderus
Buderus Logamax GB062-24 KDE H V2 Manuel utilisateur
Potterton
Potterton 50e Fiche technique
UTICA BOILERS
UTICA BOILERS TriFire Manuel utilisateur
