Technical Manual

Scandinavia’s largest webshop for scales

Hantverksvägen 15,

76493 Vaddo, Sweden

Tel. +46 (0)176-208920

Web www.vetek.com Email [email protected]

ELECTRONIC CRANE SCALE : CALIBRATION

MODELS: OCS-M & OCS-L

TABLE OF CONTENTS

DISPLAY ILLUSTRACTION 2

KEY FUNCTION IN PARAMETER SETTING/CALIBRATION 3

PARAMETER SETTING 3

CALIBRATION 4

TROUBLESHOOTING GUIDE 5

Technical_Manual_OCS-M_V1

user manual

www.vetek.com info@vetek.com 2

DISPLAY ILLUSTRATION

You can use remote controller to operate parameter setting and cabibration.

DISPLAY ILLUSTRATION REMARKS

[ CALSP ] Enter zero point calibration

[ SCALE ] Enter weight calibration

[ SEtUP ] Enter parameter setting

[ UAdJ ] Enter voltage calibration

[ LoAd1 ] First calibration point LoAd1<LoAd2<LoAd3

[ LoAd2 ] Second calibration point

[ LoAd3 ] Third calibration point

[ ¯¯¯¯¯ ] Exceeds high limit Tare weight can’t exceed full capacity

[ _____ ] Exceeds low limit Tare weight can’t be negative

[ ----- ] Waiting

[ Err10 ] Weight less than Min. Capacity Can’t accumulate the value

[ Err11 ] Accumumated times overow Can’t accumulate after 30times

[ Err12 ] Accumulated weight overow Can’t accumulate after 99999)

[ Err13 ] Error in repeat accumulation Can’t accumulate one weight repeatedly

[ no*** ] Current accumulation times

[ H**** ] Front four digit of accumulated weight Total weight=front four digit + rare four digit

[ L**** ] Rare four digit of accumulated weight Total weight=front four digit + rare four digit

[ CLr ] Ask if you really want to delete

accumulated weight In case of accidental deletion

[ noCLr ] Cancel deletion

[ 88888 ] Conrm deletion

[ SHIFt ]Switch

[ ¯¯¯ ] Input value is too large When you input tare or weight value

[ ___ ] Input value is too small When you input tare or weight value

[ noACC ] No any accumulated content when you

check accumulation

[ -oL- ] Overload warning Tare + Net weight exceed full capacity + 9e

[ -Lb- ] Low battery warning Turn off automatically one minute later

[ U*.** ] The voltage of current battery

[ End ] End when parameter setting or calibration ready

[ OFF ] Turn off

user manual

www.vetek.com info@vetek.com 3

ITEM OPERATION DISPLAY SETTING RANGE & EXPLAIN

Enter Setting [ P---- ] Press[ F1 ] [ F2 ]together, 2 seconds

[ P0258 ] Press[ TARE ] [ →0← ] together, then input parameter

setting password

[ MR ] [ SETUP ] Enter parameter setting

Capacity [ MR ] [ FS=** ] Display 02/03/05/10/15/20/30/50/75 circularly

[ →0← ] [ FS=05 ] e.g. choose capacity 5000kg

Division [ TARE ] [ 1d=** ] Display 01/02/05/10/20 circularly

[ →0← ] [ 1d=02 ] e.g. choose 2kg as division

Decimal

position

[ TARE ] [ PT= * ] 0=no, 1=X.X, 2=X.XX, 3=X.XXX

[ →0← ] [ PT= 0 ] e.g. no decimal position

Zero-setting

manually &

automatically

[ TARE ] [ Ab=** ] **: manual zero range, **: automatical zero range.

0-4, 0=0%F.S., 1=2%F.S., 2=4%F.S., 3=20%F.S.,

4=100%F.S.

[ →0← ] [ Ab=22 ] Parameter set in factory, 4%F.S.

Zero-tracking

range & display

speed

[ TARE ] [ Cd=** ] **: zero-tracking, 0-5, 0=0d, 1=0.5d, 2=1d, 3=1.5d,

4=2d, 5=2.5d;**: display speed, 0-2, 0=slow,

1=average, 2=fast

[ →0← ] [ Cd=21 ] Parameter set in factory

Stable effect [ TARE ] [ LL= * ] 0-2, 0: minimum, 1: average, 2: maximum

[ →0← ] [ LL= 1 ] Parameter set in factory

Unit [ TARE ] [ Un= * ] 0-2, 0=kg, 1=lb, 2=other

[ →0← ] [ Un= 0 ] Parameter set in factory, kg

Turn off

method

[ TARE ] [ oFF=* ] 0-2, 0=turn off manually, 1=stable, after 15 minutes,

scale display [ - ], 3= stable, after 15 minutes, scale

display [ - ],after 60 minutes, turn off automatically.

[ →0← ] [ oFF=1 ] Parameter set in factory

[ MR ] [ End ] Parameter setting nished

KEY FUNCTION

[TARE] → Shift (choosen digit glitter)

[→0←] ↑ Parameter setting

[ MR ] ← Conrm

KEY FUNCTION IN PARAMETER SETTING/CALIBRATION

PARAMETER SETTINGS

user manual

www.vetek.com info@vetek.com 4

ITEM OPERATION DISPLAY SETTING RANGE & EXPLAIN

Enter Setting [ P---- ] Press[ F1 ] [ F2 ]together, 2 seconds

[ P8416 ] Press [ TARE ] [ →0← ]together, then input calibration

password

[ MR ] [ SCALE ] Enter calibration

Calibration with

no load

[ MR ] [ CALSP ] Make sure no load and let scale stable

[ MR ] [ ----- ] Calibration ok

First load [ MR ] [ LoAd1 ] Start rst load point calibration

[ MR ] [ ***** ] Last calibration value or default value

[ TARE ]

[ →0← ]

[ 1000 ] Input weight, e.g. 1000kg

Hanging weight, waiting stable

[ MR ] [ ----- ] First load calibration ok

Second load [ MR ] [ LoAd2 ] Start second load point calibration

[ MR ] [ ***** ] Last calibration value or default value

[ TARE ]

[ →0← ]

[ 3000 ] Input weight, e.g. 3000kg Hanging weight, waiting

stable

[ MR ] [ ----- ] Second load calibration ok

Third load [ MR ] [ LoAd3 ] Start third load point calibration

[ MR ] [ ***** ] Last calibration value or default value

[ TARE ] [ 5000 ] Input weight, e.g. 3000kg

Hanging weight, waiting stable

[ MR ] [ ----- ] Third load calibration ok

[ End ] Calibration nished, return

CALIBRATION

ATTENTION:

1. Scale tare weight can’t exceed 50%F.S., the range between load1, load2, load3 can’t less than

20%F.S., if the range less than 20%F.S., calibration nished automatically and return.

2. LOAD1 < LOAD2 < LOAD3

user manual

www.vetek.com info@vetek.com 5

TROUBLE REASON SOLUTION

No display when turn on Battery Damaged Check Battery

No display when turn on Loose battery contact Tighten the contact

Flashing display Low battery Recharge the battery

Can’t turn On & Off OFF/ON button is damaged Check and clean the button

Can’t Tare TARE button is damaged Check the adaptor

Recahrge indicator light can’t turn on The adaptor is damage Check the adaptor

Recahrge indicator light can’t turn on The adaptor is not plugged

ready Insert plug again

Display isn’t stable The load is unstable Stabilize the load

Display isn’t stable Loadcell cable damaged Check and replace loadcell

Display isn’t stable The scale has been in a damp

environment for a long time

Put the scale in a dry

environment

The display doesn’t show “ 0 “ on an

empty load

Have not allowed enough time

for scale heating after turn on

After turning the scale on,

allow 3 - 5 minutes for

heating

The display doesn’t show “ 0 “ on an

empty load

The scale has been on the

ground for too long Scale should be hung

The error is large The scale isn’t hung prperly Check the scale and sling

Battery can’t recharge Battery is damaged Replace battery

Battery can’t recharge Outlet is damaged Replace the outlet

Remote distance shortened Receiver window is too dirty Check and clean

Remote distance shortened Controller has low battery Replace controller battery

TROUBLESHOOTING GUIDE
